1996 FORD MUSTANG CD player

145
*
[AS24500(MBC )08/95]
Speaker features and operation
*
[AS24600(MBC )10/95]
q
Adjusting speaker balance
*
[AS24750(MBC )06/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the right
speakers, and push the left (s) side to shift
the sound to the left speakers.
*
[AS24800(MBC )10/95]
q
Adjusting speaker fader
*
[AS24950(MBC )06/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the left (s) side to shift
the sound to the rear speakers.
*
[AS24960(MBC )10/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble, and
positions of speaker balance and fader
functions (left to right, front to rear).
%*
[AS25000(MBC )08/95]
Using the Controls of Your Cassette Tape
Player
*
[AS25400(M )08/95]
NOTE: Radio power must be on to use the
cassette tape player.
*
[AS25500(MBC )08/95]
How to insert a tape
*
[AS25600(MBC )08/95]
Insert a cassette (with the open edge to the
right) firmly into the tape door opening, making
sure the cassette is completely in and ªseated.º
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

147
*
[AS27500(MBC )08/95]
Push thek/memory preset #3 button to
activate. Push again to deactivate.
*
[AS27600(MBC )08/95]
Tips on Caring for the Cassette Player and
Tapes
*
[AS27700(MBC )08/95]
In order to keep your cassette tape player
performing the way it was meant to, read and
follow these simple precautions:
*
[AS27750(MBC )08/95]
q
Using a Ford Cassette Cleaning Cartridge to
clean the tape player head after 10-12 hours
of play will help maintain the best playback
sound and proper tape operation.
*
[AS27800(MBC )08/95]
q
Only cassettes that are 90 minutes long or
less should be used. Tapes longer than 90
minutes are thinner and subject to breakage
or may jam the tape player mechanism.
*
[AS27900(MBC )08/95]
q
Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions, allow them to reach a moderate
temperature before playing.
*
[AS28001(MBC )08/95]
q
If a tape is loose inside the cassette, tighten it
before playing by putting your finger or a
pencil into one of the holes and turning the
hub until the tape is tight.
*
[AS28101(MBC )08/95]
q
Loose labels on cassette tapes can become
lodged in the mechanism. Remove any loose
label material before inserting a cassette.
*
[AS28200(MBC )08/95]
q
Do not leave a tape in the cassette tape
player when not in use. High heat in the
vehicle can cause the cassette to warp.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

148 % [AS28600(M )05/94]
full page art:0060665-AFord Mini Disc Player
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

149
[AS28650(M )03/95]
Ford Mini Disc Player
[AS28700(M )05/94]
The Ford Mini Disc Player operates when the
Audio System is on and a disc is inserted(label
side up). (Be sure to read and follow all of the
care and cleaning instructions underHow To
Take Care of Your Mini Disc Player and Discsin
this section.)
[AS28800(M )05/94]
The digital display on your Mini Disc player
shows the track (selection) number and the disc
title.
[AS28900(M )05/94]
Once a disc is inserted, operation of the Mini
Disc player will override that of the cassette
player or radio.
[AS29000(M )05/94]
Using the Controls on Your New Mini
Disc Player
[AS29100(M )09/95]
NOTE: The volume, bass, treble, balance and
fader controls on the radio are also
used with the Mini Disc player. Refer
toUsing the Controls on Your New
Radioin this section for operating
instructions on these controls.
*
[AS29200(M )10/95]
How to insert a disc and begin play
[AS29300(M )05/94]
Insert one disc,label side upinto the disc
opening. Arrow on top of disc must point
inward. When inserted, the disc automatically
loads into the unit and play starts at the
beginning of the first track (selection).
*
[AS29400(M )10/95]
When the disc reaches the end, the disc player
automatically returns to the beginning of the
disc and resumes playing.
*
[AS29500(M )09/95]
NOTE: Once a disc is inserted, the disc
opening is secured to prevent the
accidental insertion of a second disc.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

150 [AS29600(M )09/95]NOTE: The Mini Disc player has heat
protection circuitry to protect the laser
diode. If the temperature of the player
reaches167ÊF (75ÊC), theheat detection
circuit will shut off the player and
ªHOTº will appear in the display.
When the temperature is within normal
operating range, the ªHOTº indication
will turn off and the Mini Disc player
will again be operational.
[AS29700(M )09/95]
NOTE: If the ignition key is turned OFF
during play and then is set to the ON
or ACCESSORY position, the Mini
Disc player will resume playing in the
mode it was in when ignition was
turned off.
[AS29800(M )05/94]
How to fast forward or rewind your Mini
Disc player
[AS29900(M )03/95]
To quickly search for a particular point in a
selection, press the right (
e) side of the
ªREV/FFº button (to fast forward) or the left
(
f) side (to rewind). While either side of the
button is pressed, the disc goes forward or
backward at two different speeds depending on
how long the button is held down. (Pressing the
button for more than approximately 5 seconds
will speed up the process.) Release the button at
the desired point (found by watching the
elapsed playing time in the display or by
listening to the sound during fast forward or
rewind).
[AS30000(M )03/95]
When you have reached the end of the disc by
keeping the fast forward (
e) side of the
button pressed, the display will show the end
time of the last track and the sound will be
muted. When the fast forward (
e) side of the
button is released, the player resumes play at
the beginning of the first track.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

151 [AS30200(M )05/94]
Using the ªSCROLLº feature
[AS30300(M )05/94]
The scroll feature allows the display to scroll
through titles that are larger than 12 characters.
[AS30400(M )05/94]
Press the ªSCROLLº button to activate the scroll
feature.
[AS30420(M )05/94]
Using the ªAMSº feature
[AS30440(M )03/95]
Pressing the right (
e) side of the ªAMSº
button advances the disc forward one track at a
time.
[AS30445(M )03/95]
Pressing the left (
f) side of the ªAMSº button
brings the disc back to the beginning of the
current track. Pressing and holding the left
(
f) or right (
e) side of the ªAMSº button
will scroll backward or forward respectively
through the tracks.
[AS30460(M )05/94]
Using the display feature
[AS30480(M )07/94]
Three different displays can be shown. Pressing
the ªDISPLAYº button will toggle between track
# and disc title, song title, and track # and
elapsed time.
[AS30482(M )07/94]
When a disc is ejected and another inserted, the
display will show the same selected display as
the disc that was ejected.
*
[AS30500(M )10/95]
How to eject the disc
[AS30600(M )05/94]
Push the ªEJECTº button in the upper left
corner of your Mini Disc player to stop play,
eject the disc and resume radio or tape operation
of your audio system.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

152 % [AS30700(M )11/94]How To Take Care of and Clean Your
Mini Disc Player and Discs
[AS30800(M )05/94]
To ensure the continued performance, of your
Ford Mini Disc Player carefully read the
following precautions.
*
[AS30900(M )08/95]
q
Always handle the disc by its edge. Never
touch the playing surface.
*
[AS31100(M )08/95]
q
Do not clean discs with solvents such as
benzine, thinner, commercially available
cleaners or antistatic spray intended for
analog records.
*
[AS31200(M )08/95]
q
Do not expose the disc to direct sunlight or
heat sources such as defroster and floor
heating ducts. Do not leave any discs in a
parked car in direct sunlight where there may
be a considerable rise in temperature or
damage may result.
*
[AS31300(M )08/95]
q
After playing, store the disc in its case.
*
[AS31400(M )08/95]
q
If a disc has already been inserted, do not try
to insert another disc. Doing so may damage
the disc player.
*
[AS31500(M )08/95]
q
Do not insert anything other than a disc into
the disc player.
*
[AS31600(M )08/95]
CAUTION:The use of optical instruments with
this product will increase eye hazard as the laser
beam used in this compact disc player is
harmful to the eyes. Do not attempt to
disassemble the case. Refer servicing to qualified
personnel only.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

153 [AS31700(M )07/94]
Common Operating Conditions of Your
Mini Disc Player
*
[AS31800(M )08/95]
The following information is designed to help
you recognize typical situations that could be
mistakenly interpreted as mechanical
malfunctions of the disc player.
*
[AS31900(M )08/95]
q
A disc is already loaded.
*
[AS32000(M )08/95]
q
The disc is inserted with the label surface
downward.
*
[AS32100(M )08/95]
q
The disc is dusty or defective.
*
[AS32200(M )05/95]
q
The player's internal temperature is above
167ÊF (75ÊC).Allow the player to cool off
before operating.
[AS32300(M )05/94]
q
Different manufacturers of compact discs may
produce discs with different dimensions or
tolerances, some of which may not be within
industry standards or in accordance with the
Mini Disc format. Because of this, a new disc
that is free of dust and scratches could be
defective and may not play on your Ford
Mini Disc Player.
*
[AS32400(M )09/95]
If play does not begin after the CD button is
pushed:
*
[AS32500(M )08/95]
q
The radio is not on.
*
[AS32600(M )08/95]
q
The unit is in the stop mode.
*
[AS32700(M )08/95]
q
Moisture may have condensed on the lenses
within the unit. If this occurs, remove the
disc and wait approximately an hour until the
moisture evaporates.
*
[AS32800(M )08/95]
If the sound skips:
*
[AS32900(M )08/95]
q
Badly scratched discs or extremely rough
roads will cause the sound to skip. Skipping
will not damage the disc player or scratch the
discs.
