1996 FORD MUSTANG mirror controls

127 % [FV22700(M )06/93]
Adjusting the Side View Mirrors
[FV24200(M C )06/93]
The switch for controlling the dual electric
remote control mirrors is located on the driver's
door.
%*
[FV24400( ALL)01/95]
Do not clean the housing or glass of any mirror
with harsh abrasives, fuel or other
petroleum-based cleaning products.
[FV24520(M )03/95]
half page art:0010272-C
The mirror controls on the driver's door
*
[FV24700( ALL)04/95]
To adjust the side mirrors:
*
[FV24800( ALL)01/95]
1. Find the control switch in the driver's door
panel.
*
[FV24900( ALL)06/94]
2. Select the right or left mirror by moving the
selector switch to R or L.
[FV25000( ALL)06/93]
3. Move the knob in the direction of the arrows
for the direction you want to move the
mirror.
*
[FV25100( ALL)06/94]
4. Return the selector switch to the middle
position to keep the mirror in place.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

322 Index
Controls
instrument panel............ 79
mirrors................ 125
steering column............. 91
Convertible
cleaning............... 138
installation of the boot......... 134
lowering the convertible top...... 132
raising the convertible top....... 137
Coolant (see Engine coolant)
checking and adding......... 252
drain and flush............ 257
preparing for storage......... 303
proper solution............ 255
refill capacities............ 298
specifications............. 300
temperature gauge........... 73
warnings............... 252
Cooling fan............... 236
Crankcase emission filter......... 299
Cruise control (see Speed control)...... 97
Customer Assistance Center, Ford (U.S.) . . 217
Customer Assistance Centre,
Ford of Canada..........217, 223
D
Dashboard (see Instrument panel)...... 79
Daytime running light system....... 84
Defects, reporting............ 222
Defrost
rear window.............. 83
windshield............... 82
Dipstick
automatic transmission fluid....269, 271
engine oil.............. 249
power steering fluid.......... 274
Disabled vehicle (see Towing)...... 213
Dispute Settlement Board........ 218
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996
