1996 FORD MUSTANG transmission fluid

269
*
[SV29200( ALL)01/95]
q
Put the chains on tightly with the ends held
down securely. Verify that no chain touches
any wiring, brake lines, or fuel lines. Follow
the chain manufacturer's instructions.
*
[SV29300( ALL)01/95]
q
Drive slowly. If you can hear the chains rub
or bang against your vehicle, stop the vehicle
and tighten the chains. If you continue to
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[SV29400( ALL)10/94]
q
Avoid fully loading your vehicle if possible.
*
[SV29500( ALL)05/94]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%*
[SV29600( ALL)04/95]
Cleaning the Wheels
*
[SV29700( ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[SV29800( ALL)09/95]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
%
*
[SV30450( ALL)01/95]
Automatic Transmission Fluid
*
[SV30475( ALL)01/95]
Under normal circumstances, you do not need to
check the fluid level of the transmission, since
your vehicle does not use up transmission fluid.
Refer to theMaintenance Schedule and Record
booklet for replacement intervals. However, if
the transmission is not working properly Ð for
instance, the transmission may slip or shift
slowly, or you may notice some sign of fluid
leakage Ð the fluid level should be checked.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

270 %
*
[SV30550( ALL)02/95]
Checking the Automatic Transmission
Fluid
*
[SV30560( ALL)05/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (30 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (30 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
[SV30575( ALL)03/94]
With the vehicle on a level surface, start the
engine and, while fully applying the brake
pedal, move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage.Securely latch
the transmission shift selector in the P (Park)
position, fully set the parking brake and leave
the engine running.
[SV30625(MBC )03/93]
NOTE: Your vehicle should not be driven if
the fluid level is below the low cold
reading on the dipstick.
*
[SV30650( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
[SV30675(MBC )10/95]
When checking fluid at normal operating
temperature150ÊF-170ÊF (66ÊC-77ÊC), thefluid
level should be within the hot notched area on
the dipstick. When the vehicle has not been
driven, and the fluid is at room temperature
50ÊF-95ÊF (10ÊC-35ÊC), thefluid level should be
within the cold notched area.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

271
*
[SV30715( ALL)01/95]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off for about 30 minutes to
allow the fluid to cool before checking.
%*
[SV30725( ALL)08/95]
Adding Automatic Transmission Fluid
[SV30750( ALL)03/94]
Before adding any fluid, be sure that the correct
type will be used. Use only MERCONHfluid.
*
[SV30775( ALL)03/95]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level to the correct
area on the dipstick. DO NOT OVERFILL. If the
level is above the top hole on the dipstick,
excess fluid should be removed by a qualified
technician.
%*
[SV30801( ALL)09/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
[SV30825(MBC )03/93]
one third page art:0011152-A
Detail of the automatic transmission dipstick
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

272
% [SV30875(M )12/94]
Manual Transmission Fluid
% [SV30925(M )03/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the fluid
level checked occasionally. If fluid is required,
seeLubricant Specificationsin the Index.
%
*
[SV30950(M )02/95]
The Clutch
[SV30975(M )12/94]
The clutch on your vehicle is operated by a
cable that adjusts itself with a little help from
you. Complete the following steps every
5,000-6,000 miles (10,000 km) to adjust the
clutch.
[SV31001(M )01/89]
1. Turn your engine off and put your gearshift
in First.
[SV31025(M )10/89]
2. Put your foot under the clutch pedal and
gently pull it up until the pedal stops.
[SV31050(M )01/89]
3. Then push the clutch down slowly. You will
hear a click if your clutch needed adjusting
and adjusted itself.
%
*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
[SV32300(M )03/95]
Check the brake fluid at each scheduled engine
oil change or at least once a year. You can do
this by looking at the fluid level in the plastic
reservoir on the master cylinder. Also, see label
on reservoir cap. (To locate the master cylinder,
seeThe Engine Typesin the Index.) The fluid
level should be between the MIN and MAX
marks.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

318 Index
Anti-theft lug nuts and key........ 212
Anti-theft system
arming the system.......... 105
description.............. 104
disarming an untriggered system.... 106
disarming a triggered system...... 107
triggering............104, 107
warning light.............. 72
Appeals (see Dispute settlement board) . . 218
Assistance (see Customer assistance).... 215
Audio system (see Electronic
sound system)............ 141
Autolamp system (see Headlamps)..... 84
Automatic transmission
driving an automatic overdrive . . . 177, 180
fluid, adding............. 271
fluid, checking............ 270
fluid, refill capacities......... 298
fluid, specification........... 300
Axle
lubricant specifications......... 300
refill capacities............ 298
traction lok.............. 185
B
Backing up.............179, 183
Basic vehicle warranty........... 4
Battery
acid, treating emergencies.....199, 260
battery saver............. 112
charging system warning light...... 68
disconnecting...........204, 260
how to service............ 259
jumping a disabled battery....... 199
maintenance-free........... 259
proper disposal, recycling....... 260
replacement, specifications....... 299
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

322 Index
Controls
instrument panel............ 79
mirrors................ 125
steering column............. 91
Convertible
cleaning............... 138
installation of the boot......... 134
lowering the convertible top...... 132
raising the convertible top....... 137
Coolant (see Engine coolant)
checking and adding......... 252
drain and flush............ 257
preparing for storage......... 303
proper solution............ 255
refill capacities............ 298
specifications............. 300
temperature gauge........... 73
warnings............... 252
Cooling fan............... 236
Crankcase emission filter......... 299
Cruise control (see Speed control)...... 97
Customer Assistance Center, Ford (U.S.) . . 217
Customer Assistance Centre,
Ford of Canada..........217, 223
D
Dashboard (see Instrument panel)...... 79
Daytime running light system....... 84
Defects, reporting............ 222
Defrost
rear window.............. 83
windshield............... 82
Dipstick
automatic transmission fluid....269, 271
engine oil.............. 249
power steering fluid.......... 274
Disabled vehicle (see Towing)...... 213
Dispute Settlement Board........ 218
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

330 Index
Lights, warning and indicator (continued)
safety belt............... 66
service engine soon........... 70
theft system.............. 72
turn signal indicator......... 72,91
Load limits
GAWR................ 192
GVWR................ 192
trailer towing............. 194
Lubricant specifications......... 300
Luggage compartment.......... 131
Lug nuts
anti-theft............... 212
standard............... 209
tightening sequence.......... 211
M
Maintenance schedule and record
(see separate Maintenance
Schedule and Record booklet)...... 3
Maintenance (see Servicing)....... 235
Manual transmission
backing up (reverse).......... 183
clutch..............182, 272
driving................ 182
fluid, checking and adding....... 272
fluid capacities............ 298
lubricant specifications......... 300
shifting gears............. 183
shift speeds.............. 184
Map pockets.............. 131
Master cylinder, brakes......... 272
Methanol in fuel............. 244
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

336 Index
Tires (continued)
snow tires and chains......... 268
spare tire............... 206
storing your vehicle.......... 303
tire grades............265±266
treadwear............265, 267
wear bands.............. 265
Towing a trailer (see Trailer towing) . . . 194
Towing your vehicle
using wheel dollies.......... 213
with a tow truck........... 213
Traction-lok rear axle.......... 185
Trailer towing
calculating maximum
trailer weight..........194±195
safety chains............. 196
tips................. 197
trailer brakes............. 196
trailer lamps............. 197
Transmission
automatic operation.......... 177
fluid, checking and adding (automatic) . 270
fluid, checking and adding (manual) . . 272
fluid, refill capacities......... 298
lubricant specifications......... 300
manual operation........... 182
Transmission control switch....... 180
Transmitter (see Remote entry)...... 110
Trip odometer............... 75
Trunk
remote release lever.......... 132
using the keys to open........ 131
using the remote entry system
to open.............. 110
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996
