1996 FORD MUSTANG CD player

154 % [AS38050(M )02/95]
full page art:0060593-BFord Compact Disc Player
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

155
*
[AS38075(M )05/95]
Ford Compact Disc Player
*
[AS38100(M )03/95]
The Ford Compact Disc Player operates when
the Audio System is on and a disc is inserted
(label side up). Handle the disc by its edge
only. (Be sure to read and follow all of the care
and cleaning instructions underHow To Take
Care of and Clean Your CD Player and Discsin this
section.)
*
[AS38200(M )06/95]
The digital display on your CD player shows the
track (selection) number and the elapsed time.
Indicators for play
a, stop
X, compression on
(ªCOMPº) and shuffle on (ªSHUFº) are also in
the display. (These features are described later.)
[AS38210(M )06/95]
Once a disc is inserted, operation of the CD
player will override that of the cassette player or
radio.
%*
[AS38250(M )10/95]
Using the Controls on Your New Compact
Disc Player
[AS38270(M )09/95]
NOTE: The volume, bass, treble, balance and
fader controls on the radio are also
used with the CD player. Refer to
Using the Controls on Your New Radio
in this section for operating
instructions on these controls.
*
[AS38300(M )10/95]
How to insert a disc and begin play
[AS38310(M )03/95]
Insert one disc,label side upinto the disc
opening. When inserted, the disc automatically
loads into the unit and play starts at the
beginning of the first track (selection). The play
indicator (
a) lights up and the number ª1º
(track) and ª0:00º (elapsed time) are shown in
the digital display.
*
[AS38320(M )10/95]
When the disc reaches the end, the disc player
automatically returns to the beginning of the
disc and resumes playing.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

156
*
[AS38330(M )10/95]
NOTE: Once a disc is inserted, the disc
opening is secured to prevent the
accidental insertion of a second disc.
[AS38340(M )03/95]
NOTE: The CD player has heat protection
circuitry to protect the laser diode. If
the temperature of the player reaches
167ÊF (75ÊC), theheat detection circuit
will shut off the player and ªHOTº
will appear in the display. When the
temperature is within normal operating
range, the ªHOTº indication will turn
off and the CD player will again be
operational.
*
[AS38400(M )10/95]
How to stop and restart the CD player
[AS38450(M )03/95]
When a disc is loaded, the unit automatically
enters the play mode and the play indicator (
a)
illuminates. To stop temporarily, press the
ªPLAY/STOPº button. The stop indicator (
X)in
the display illuminates and operation returns to
the radio or tape mode. To resume CD play,
press this button once again or press any other
function button (except ªEJECTº or
ªCOMPRESSº buttons).
*
[AS38475(M )10/95]
NOTE: If the ignition key is turned OFF
during play and then is set to the ON
or ACCESSORY position, the CD
player will resume playing in the mode
it was in when ignition was turned off.
*
[AS38500(M )03/95]
How to locate a selection on your CD
player using Automatic Music Search (AMS)
*
[AS38510(M )06/95]
An ªAMSº (Automatic Music Search) control on
your CD player allows you to quickly find a
particular selection on the disc. Press the left
fside of the ªAMSº control to locate a
previous selection or the right
eside of the
ªAMSº control to locate a later selection.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

157
*
[AS38550(M )10/95]
How to fast forward or reverse your CD
player
[AS38560(M )06/95]
To quickly search for a particular point in a
selection, press the right (
e) side of the
ªREV/FFº button (to fast forward) or the left
(
f) side (to rewind). While either side of the
button is pressed, the disc goes forward or
backward at two different speeds depending on
how long the button is held down. (Pressing the
button for more than a couple seconds will
speed up the process.) Release the button at the
desired point (found by watching the elapsed
playing time in the display or by listening to the
sound during fast forward or rewind).
*
[AS38580(M )06/95]
When you have reached the end of the disc by
keeping the fast forward
eside of the button
pressed, the display will show the end time of
the last track and the sound will be muted.
When the fast forward
eside of the button is
released, the player resumes play at the
beginning of the first track.
*
[AS38600(M )06/95]
A ª1º and ª0:00º will appear in the display
when the beginning of the disc is reached by
pressing the rewind
fside of the button.
*
[AS38620(M )10/95]
Using the ªSCANº function
*
[AS38630(M )03/95]
Press the ªSCANº button to enter the scan
mode. The CD player will begin scanning the
disc, stopping on each listenable track for
approximately eight seconds. This continues until
you press the ªSCANº button a second time or
eject the disc. While in the scan mode, the
display flashes ªSCAN.º
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

158
*
[AS39050(M )07/94]
Special Features of Your CD Player
*
[AS39100(M )10/95]
q
Compression
*
[AS39110(M )10/95]
The compression feature will bring soft and
loud passages closer together for a more
consistent listening level.
*
[AS39120(M )03/95]
To turn the compression on, press the
ªCOMPRESSº button. When on, the
compression indicator (ªCOMPº) will appear
in the display. Press the button again to turn
off.
*
[AS39150(M )03/95]
q
Shuffle
*
[AS39160(M )03/95]
The shuffle feature on your CD player allows
you to listen to your disc selections in a
different order. When this feature is
activated, your CD player will randomly
select and play tracks on the disc.
*
[AS39170(M )03/95]
Press the ªSHUFFLEº button to turn on,
press it again to turn off. When on, the
shuffle indicator (ªSHUFº) will appear in the
display. When the player is between
selections, the display will show a moving
dash (ªsº) around the perimeter of the
display.
*
[AS39200(M )03/95]
q
Shuffle and Scan
*
[AS39210(M )03/95]
Both the shuffle and scan features can be
activated simultaneously. In this mode, the
player will randomly pick a selection and
play the first eight seconds. This process is
continued until either the ªSCANº button or
ªSHUFFLEº button is pressed a second time.
*
[AS39250(M )10/95]
q
Automatic Disc Storage
[AS39260(M )03/95]
If the disc is ejected from the CD player but
is not removed from the disc opening within
approximately 15 seconds, the player will
automatically reload the disc for storage.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

159
*
[AS39300(M )10/95]
How to eject the disc
*
[AS39310(M )06/95]
Push the ªEJECTº button in the upper left
corner of your CD player to stop play, eject the
disc and resume radio or tape operation of your
audio system.
%*
[AS41201(M )08/95]
How To Take Care of and Clean Your CD
Player and Discs
*
[AS41301(M )08/95]
To ensure the continued performance of your
Ford Compact Disc Player, carefully read the
following precautions:
*
[AS41401(M )08/95]
q
Always handle the disc by its edge. Never
touch the playing surface.
*
[AS41501(M )08/95]
q
Before playing, inspect the disc for any
contamination. If needed, clean the disc with
an approved disc cleaner, such as the
DiscwasherHCompact Disc Cleaner or the
Allsop 3HCompact Disc Cleaner, by wiping
from the center out to the edges.Do not use
a circular motion to clean.
*
[AS41601(M )08/95]
q
Do not clean discs with solvents such as
benzine, thinner, commercially available
cleaners or antistatic spray intended for
analog records.
*
[AS41701(M )08/95]
q
Do not expose the disc to direct sunlight or
heat sources such as defroster and floor
heating ducts. Do not leave any discs in a
parked car in direct sunlight where there may
be a considerable rise in temperature or
damage may result.
*
[AS41801(M )08/95]
q
After playing, store the disc in its case.
*
[AS41901(M )08/95]
q
If a disc has already been inserted, do not try
to insert another disc. Doing so may damage
the disc player.
*
[AS42001(M )08/95]
q
Do not insert anything other than a disc into
the disc player.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

160
*
[AS42101(M )08/95]
CAUTION:The use of optical instruments with
this product will increase eye hazard as the laser
beam used in this compact disc player is
harmful to the eyes. Do not attempt to
disassemble the case. Refer servicing to qualified
personnel only.
*
[AS42201(M )08/95]
Common Operating Conditions of Your
CD Player
*
[AS42301(M )08/95]
The following information is designed to help
you recognize typical situations that could be
mistakenly interpreted as mechanical
malfunctions of the disc player.
*
[AS42401(M )08/95]
q
A disc is already loaded.
*
[AS42501(M )08/95]
q
The disc is inserted with the label surface
downward.
*
[AS42601(M )08/95]
q
The disc is dusty or defective.
*
[AS42701(M )05/95]
q
The player's internal temperature is above
167ÊF (75ÊC).Allow the player to cool off
before operating.
*
[AS42801(M )08/95]
q
Different manufacturers of compact discs may
produce discs with different dimensions or
tolerances, some of which may not be within
industry standards or in accordance with the
CD format. Because of this, a new disc that is
free of dust and scratches could be defective
and may not play on your Ford Compact
Disc Player.
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996

161
*
[AS42901(M )09/95]
If play does not begin after the CD button is
pushed:
*
[AS43001(M )08/95]
q
The radio is not on.
*
[AS43101(M )08/95]
q
The unit is in the stop mode.
*
[AS43201(M )08/95]
q
Moisture may have condensed on the lenses
within the unit. If this occurs, remove the
disc and wait approximately an hour until the
moisture evaporates.
*
[AS43301(M )08/95]
If the sound skips:
*
[AS43401(M )08/95]
q
Badly scratched discs or extremely rough
roads will cause the sound to skip. Skipping
will not damage the disc player or scratch the
discs.
