Engine Coolant Drain and Flush
*
[SV20200( ALL)11/94]
Proper procedures for a complete coolant drain
and flush of the cooling system can be found in
theCar Service Manual. Following these
recommended procedures will ensure that the
specified coolant level and a 50/50 or
appropriate mixture of coolant and water is
maintained.
*
[SV20300( ALL)08/95]
Engine Coolant Refill Procedure
*
[SV20400( ALL)01/95]
When the entire cooling system is drained and
refilled, the following procedure should be used
to ensure a complete fill:
*
[SV20450( ALL)05/95]
NOTE: It is imperative the following
procedure be adhered to. Failure to do
so could result in damage to your
engine.
[SV20500(MBC )03/95]
3.8L engine only
[SV20601(MBC )03/94]
q
Open the vent plug.
[SV20700(MBC )03/93]
q
Remove coolant recovery reservoir cap.
[SV20801(MBC )03/93]
q
Remove radiator pressure cap.
[SV20900(MBC )05/94]
q
With the engine off and cool, add a 50/50
mixture of recommended cooling system fluid
and water to the radiator until full, then add
to the reservoir until the reservoir is at the
FULL-HOT level.
[SV21000(MBC )12/91]
q
Close the vent plug.
[SV21100(MBC )03/93]
q
Reinstall the coolant recovery reservoir cap
by installing the cap to the fully installed
position.
[SV21110(MBC )03/93]
q
Reinstall the pressure cap to the pressure
relief position by installing the cap to the
fully installed position, and then backing off
to the first stop.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

258 [SV21200(MBC )03/93]q
Start and idle engine until the radiator upper
hose is warm (this indicates the thermostat is
open and coolant is flowing through the
entire system).
[SV21300(MBC )03/93]
q
Immediately shut off engine. Cover cap
completely with a thick cloth and cautiously
remove radiator pressure cap and add a
50/50 mixture of recommended coolant and
water until system is full.
[SV21400(MBC )03/91]
q
Reinstall the radiator cap securely.
[SV21500(MBC )05/94]
q
Remove the cap from the engine coolant
recovery reservoir and add a 50/50 mixture
of recommended cooling system fluid and
water to the FULL-HOT mark on the engine
coolant recovery reservoir. Check that
reservoir hose is not kinked.
[SV21800(MBC )03/93]
q
Reinstall the reservoir cap.
*
[SV21900(MBC )05/95]
q
Check for leaks at the draincock, block plug
and vent plug.
*
[SV22000(MBC )03/95]
q
Recheck the engine coolant level, using the
recommended procedure, after one or two
occasions of vehicle use.
[SV22012(M )05/95]
4.6L (2V) engine only Ð GT models
*
[SV22014( ALL)03/95]
q
With the engine OFF and cool, remove the
pressure cap, located on the coolant reservoir.
Remove the heater hose and clamp, located
on the rear of the intake manifold.
*
[SV22021( ALL)03/95]
q
Add a 50/50 mixture of specified coolant and
water to the coolant reservoir. Refer toRefill
Capacitieslater in this chapter for the correct
amount. Add coolant to the reservoir until
the coolant continuously flows out of the tube
in the rear of engine. Reattach hose and
secure clamp.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

259 [SV22026( ALL)03/95]
q
Continue to fill the reservoir until the coolant
is at the FULL COLD level.
*
[SV22031( ALL)05/95]
q
Reinstall the pressure cap to the fully
installed position.
*
[SV22036( ALL)05/95]
q
Start and idle the engine until the radiator
upper hose is warm (this indicates the
thermostat is open and coolant is flowing
through the entire system).
*
[SV22041( ALL)03/95]
q
Immediately shut off the engine and let cool.
Cautiously remove the pressure relief cap and
add a 50/50 mixture of specified coolant and
water until the coolant is at the COLD FILL
level in the coolant reservoir.
*
[SV22046( ALL)03/95]
q
Reinstall the pressure cap securely.
*
[SV22050( ALL)03/95]
q
Check for leaks at the draincock.
*
[SV22055( ALL)03/95]
q
Recheck the engine coolant level, using the
recommended procedure, after one or two
occasions of vehicle use.
%
*
[SV22090( ALL)03/95]
Battery
*
[SV22100( ALL)02/95]
Your vehicle may have a Motorcraft
maintenance-free battery. When the original
equipment battery is replaced under warranty, it
may be replaced by a Motorcraft
Low-Maintenance Battery.
*
[SV22130( ALL)06/95]
The Low-Maintenance Battery has removable
vent caps for checking the electrolyte level and
for adding water, if necessary. The electrolyte
level should be checked at least every 24 months
or 24,000 miles (40,000 km) in temperatures up
to 90ÊF (32ÊC) andmore often in temperatures
above90ÊF (32ÊC).Keep the electrolyte level in
each cell up to the level indicator. Do not
overfill.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

260
*
[SV22145( ALL)02/95]
If the level gets low, you can add tap water to
the battery, provided the water isn't hard or
doesn't have a high mineral or alkali content.
However, if possible you should refill the battery
with distilled water. If the battery needs water
quite often, have the charging system checked
for a possible malfunction.
%*
[SV22160( ALL)03/95]
Help Us Protect Our Environment
*
[SV22175( ALL)04/95]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility for disposal.
*
[SV22190( ALL)03/95]
one inch art:0000983-A
Battery recycling symbol
% [SV22192(M )03/95]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery, install
a new battery, or experience a dead battery, you
must allow the computer to ªrelearnº its idle
conditions before your vehicle will idle at its
best. To let the engine do this, put the gearshift
in P (Park) (automatic transmission) or Neutral
(manual transmission), turn off all the
accessories, and start the vehicle. Let the engine
idle for at least one minute. (Engine must be
warm in order to ªlearn.º) Also, allow
approximately 10 miles (16 km) of stop and go
traffic for your vehicle's engine to completely
ªrelearnº its idle.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

261 [SV22198(M )09/95]
NOTE: If your vehicle is equipped with a 3.8L
engine you will need to perform
additional steps after the battery has
been disconnected, jump started or
replaced. SeeReadiness for
Inspection/Maintenance Testingin
Servicing Your Vehicle chapter.
%
*
[SV22200( ALL)03/95]
Windshield Washer Fluid and
Wipers
%*
[SV22250( ALL)03/95]
Washer Fluid
[SV22300( ALL)12/94]
Check the level of the windshield washer fluid
periodically, or when the optional lamp indicates
low fluid. The reservoir for washer fluid is
located on the driver's side of the engine
compartment. Visual inspection can determine if
the washer fluid is adequate. Do not operate the
washer when the reservoir is empty.
[SV22900(M )10/95]
half page art:0010374-D
The reservoir for the windshield washer fluid
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

262
*
[SV23400( ALL)05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
%*
[SV23500( ALL)01/95]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
%*
[SV23600( ALL)03/95]
Wiper Blades
*
[SV23700( ALL)03/95]
Check the windshield wiper blades at least twice
a year. Also check them whenever they seem
less effective than usual. Substances such as tree
sap and some hot wax treatments used by
commercial car washes reduce the effectiveness
of wiper blades.
*
[SV23800( ALL)09/95]
If the blades do not wipe properly, clean both
the windshield and the wiper blades. Use
undiluted windshield washer solution or a mild
detergent. Rinse thoroughly with clear water. Do
not use fuel, kerosene, paint thinner, or other
solvents to clean your wiper blades. These will
damage your blades.
*
[SV23900( ALL)03/95]
To make reaching the wiper blades easy, simply
turn the ignition to the ACC position and turn
your wipers on. Wait for them to reach a
vertical position and turn the ignition to the OFF
position. Do not move the wipers manually.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

270 %
*
[SV30550( ALL)02/95]
Checking the Automatic Transmission
Fluid
*
[SV30560( ALL)05/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (30 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (30 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
[SV30575( ALL)03/94]
With the vehicle on a level surface, start the
engine and, while fully applying the brake
pedal, move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage.Securely latch
the transmission shift selector in the P (Park)
position, fully set the parking brake and leave
the engine running.
[SV30625(MBC )03/93]
NOTE: Your vehicle should not be driven if
the fluid level is below the low cold
reading on the dipstick.
*
[SV30650( ALL)02/95]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
[SV30675(MBC )10/95]
When checking fluid at normal operating
temperature150ÊF-170ÊF (66ÊC-77ÊC), thefluid
level should be within the hot notched area on
the dipstick. When the vehicle has not been
driven, and the fluid is at room temperature
50ÊF-95ÊF (10ÊC-35ÊC), thefluid level should be
within the cold notched area.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

272
% [SV30875(M )12/94]
Manual Transmission Fluid
% [SV30925(M )03/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the fluid
level checked occasionally. If fluid is required,
seeLubricant Specificationsin the Index.
%
*
[SV30950(M )02/95]
The Clutch
[SV30975(M )12/94]
The clutch on your vehicle is operated by a
cable that adjusts itself with a little help from
you. Complete the following steps every
5,000-6,000 miles (10,000 km) to adjust the
clutch.
[SV31001(M )01/89]
1. Turn your engine off and put your gearshift
in First.
[SV31025(M )10/89]
2. Put your foot under the clutch pedal and
gently pull it up until the pedal stops.
[SV31050(M )01/89]
3. Then push the clutch down slowly. You will
hear a click if your clutch needed adjusting
and adjusted itself.
%
*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
[SV32300(M )03/95]
Check the brake fluid at each scheduled engine
oil change or at least once a year. You can do
this by looking at the fluid level in the plastic
reservoir on the master cylinder. Also, see label
on reservoir cap. (To locate the master cylinder,
seeThe Engine Typesin the Index.) The fluid
level should be between the MIN and MAX
marks.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
