1996 FORD MUSTANG engine

239
%*
[SV04600( ALL)04/95]
Engine Compartment
*
[SV04700(MBC )09/93]
Your vehicle has one of these types of engines:
[SV04900(MBC )06/95]
q
a 3.8 liter SFI engine
[SV05075(MBC )03/95]
q
a 4.6 liter SFI engine
*
[SV05300(MBC )11/94]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

240 [SV05400(M )10/95]
full page art:0010325-DA 3.8 Liter SFI engine
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

241 [SV05500(M )05/95]
full page art:0011343-A
A 4.6 Liter (2V) engine Ð GT models
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

242 %
*
[SV05850( ALL)04/95]
Cleaning the Engine
*
[SV06000( ALL)04/95]
A clean engine is more efficient because a
buildup of grease and dirt acts as an insulator,
keeping the engine warmer than usual.
*
[SV06020( ALL)07/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV06040( ALL)08/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV06060( ALL)07/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV06080( ALL)04/95]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100( ALL)03/95]
Filling the Fuel Tank
*
[SV06240(MBC )05/95]
The fuel door is outside the car on the passenger
side near the back. To fill the fuel tank:
*
[SV06550( ALL)05/95]
1. After opening the fuel filler door, remove
the cap carefully and slowly by turning it
counterclockwise 1/2 to 3/4 turn.
*
[SV06650( ALL)05/95]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound while disengaging
the fuel cap, wait until it stops before
completely removing the cap. Otherwise,
fuel may spray out and injure you or
others.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

244 %
*
[SV08750( ALL)08/95]
Octane recommendations
*
[SV08800( ALL)05/95]
Your engine is designed to use fuel with an
octane rating of 87. In most cases it is not
necessary to use a fuel with an octane rating
higher than 87. At service stations, the octane
rating is displayed in a label on the pumps.
[SV08900( ALL)05/95]
one inch art:0060001-C*
[SV09100( ALL)08/95]
Using a fuel with a lower octane rating can
cause persistent and heavy knocking, which can
damage the engine.
*
[SV09200( ALL)05/95]
Do not be concerned if your vehicle sometimes
knocks lightly when you drive up a hill or when
you accelerate. However, see your dealer or a
qualified service technician if persistent heavy
knocking occurs because this can damage the
engine.
*
[SV09350( ALL)05/95]
If your vehicle has problems with starting, rough
idle or hesitation problems when the engine is
cold, it may be caused by fuel with low
volatility. Try a different brand of fuel. If the
condition persists, see your dealer or a qualified
service technician.
%*
[SV09800( ALL)04/95]
Gasolines for clean air
*
[SV09900( ALL)06/95]
Fuels in certain areas of the country are required
to contain oxygenates to improve air quality.
Common oxygenates are ethanol or grain alcohol
(blended at no more than 10%), methanol or
wood alcohol (blended at no more than 5% with
cosolvents and additives), and MTBE or methyl
tertiary butyl ether (blended at no more than
15%).
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

246
*
[SV10227( ALL)08/95]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[SV10230( ALL)08/95]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[SV11300( ALL)05/95]
Running Out of Fuel
*
[SV11350( ALL)09/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[SV11500( ALL)07/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
[SV11600( ALL)05/95]Calculating Fuel Economy
*
[SV11700( ALL)05/95]
Fuel economy is an estimate of the efficiency of
your vehicle, and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[SV11750( ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
*
[SV11800( ALL)05/95]
To calculate fuel economy:
*
[SV11900( ALL)05/95]
1. Fill the fuel tank completely and record the
initial odometer reading.
*
[SV12000( ALL)05/95]
2. Every time you buy fuel, record the
amount (in gallons or liters) purchased.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

247
*
[SV12100( ALL)05/95]
3. After at least 3-5 tankfuls, fill the fuel tank
and record the final odometer reading.
*
[SV12200( ALL)10/95]
4. Use these equations to calculate your fuel
economy:
*
[SV12250( ALL)10/95]
q
English: MPG = (total miles driven)V
(gallons used)
*
[SV12275( ALL)10/95]
q
Metric: L/100k = (liters used)V
(100 kilometers)
*
[SV12300( ALL)05/95]
Comparisons With EPA Estimates
*
[SV12400( ALL)05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
*
[SV12650( ALL)05/95]
The following decrease fuel economy:
*
[SV12700( ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12800( ALL)05/95]
q
Rapid acceleration and excessive speed
*
[SV12850( ALL)05/95]
q
Driving with your foot on the brake
*
[SV12900( ALL)05/95]
q
Sudden stops
*
[SV12950( ALL)05/95]
q
Extended engine idling
*
[SV13000( ALL)05/95]
q
Using speed control in hilly terrain
*
[SV13100( ALL)05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13200( ALL)05/95]
q
Underinflated tires
*
[SV13300( ALL)05/95]
q
Heavy loads
*
[SV13400( ALL)05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

248
*
[SV13510( ALL)02/95]
Self-Service Pointers
*
[SV13520( ALL)01/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[SV13530( ALL)01/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[SV13540( ALL)01/95]
q
Check the engine oil at every refueling stop
*
[SV13550( ALL)01/95]
q
Clean the windshield, outside mirrors and
headlights
*
[SV13560( ALL)01/95]
q
Check windshield washer fluid
*
[SV13570( ALL)02/95]
q
Check tires for excessive wear or worn edges
*
[SV13580( ALL)01/95]
q
Check the tire pressure at least monthly
%
*
[SV13600( ALL)02/95]
Engine Oil Recommendations
*
[SV13610( ALL)09/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13650( ALL)03/95]
one third page art:0060021-E
The API Certification Mark
