1996 FORD F150 light

161
*
[AS27600(BEF )02/95]
Tips on Caring for the Cassette Player and
Tapes
*
[AS27700(BEF )02/95]
In order to keep your cassette tape player
performing the way it was meant to, read and
follow these simple precautions:
*
[AS27750(BEF )02/95]
q
Using a Ford Cassette Cleaning Cartridge to
clean the tape player head after 10-12 hours
of play will help maintain the best playback
sound and proper tape operation.
*
[AS27800(BEF )02/95]
q
Only cassettes that are 90 minutes long or
less should be used. Tapes longer than 90
minutes are thinner and subject to breakage
or may jam the tape player mechanism.
*
[AS27900(BEF )02/95]
q
Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions, allow them to reach a moderate
temperature before playing.
*
[AS28001(BEF )02/95]
q
If a tape is loose inside the cassette, tighten it
before playing by putting your finger or a
pencil into one of the holes and turning the
hub until the tape is tight.
*
[AS28101(BEF )02/95]
q
Loose labels on cassette tapes can become
lodged in the mechanism. Remove any loose
label material before inserting a cassette.
*
[AS28200(BEF )03/95]
q
Do not leave a tape in the cassette tape
player when not in use. High heat in the
vehicle can cause the cassette to warp.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

166
*
[AS35900(BEF )01/95]
If there is a building or large structure between
the antenna and station, some of the signal
ªbendsº around the building, but certain spots
receive almost no signal. Moving out of the
ªshadowº of the structure will allow the station
to return to normal.
*
[AS36000(BEF )01/95]
When the radio waves are reflected off objects or
structures, the reflected signal cancels the normal
signal, causing the antenna to pick up noise and
distortion. Cancellation effects are most
prominent in metropolitan areas, but also can
become quite severe in hilly terrain and
depressed roadways.
*
[AS36100(BEF )01/95]
To minimize these conditions, a stereo/mono
blend circuit has been incorporated into this
system. This feature automatically switches a
weak stereo signal to a clearer monaural signal,
which improves the quality of reception.
*
[AS36200(BEF )01/95]
Several sources of static are normal conditions
on AM frequencies. These can be caused by
power lines, electric fences, traffic lights and
thunderstorms.
*
[AS36300(BEF )01/95]
Another reception phenomenon isStrong Signal
Capture and Overload. This can occur when
listening to a weak station and when passing
another broadcast tower. The close station may
capture the more distant station, although the
displayed frequency does not change. While
passing the tower, the station may switch back
and forth a few times before returning to the
original station.
*
[AS36400(BEF )01/95]
When several broadcast towers are present
(common in metropolitan areas) several stations
may overload the receiver, resulting in
considerable station changing, mixing and
distortion.
File:ltasf.ex
Update:Thu May 9 15:15:21 1996

174Speed, Vehicle Speed and Transmission
Temperature are used by the PCM to shift the
transmission into a higher or lower gear when
required for the best performance and fuel
economy. For example, you may notice that the
transmission will upshift to a higher gear more
quickly when the vehicle is first driven and has
not reached normal operating temperature.
*
[DR08730( ALL)07/94]
The PCM also controls the transmission's Torque
Converter Clutch to further raise vehicle
performance and fuel economy. The Torque
Converter Clutch will engage when the
transmission operating temperature and other
conditions determined by the PCM have been
met. Engagement of the clutch may be noted as
a decrease in engine speed after an upshift has
completed or when the driver has depressed the
throttle while driving at a steady road speed.
[DR08740( ALL)04/95]
To help in troubleshooting, the PCM continually
performs self-tests on the electronic control
system and if any faults are detected, will store
them in memory. The Transmission Control
Indicator Light (TCIL), which is located on the
gearshift lever, may flash steadily if a
malfunction has been detected. If the TCIL is
flashing, contact your Ford dealer as soon as
possible. If this condition persists, damage to the
transmission could occur.
[DR08745( ALL)04/95]
NOTE: The word ªOFFº located on the end of
the gearshift lever is the transmission
control indicator light (TCIL).
*
[DR08750( ALL)01/95]
Putting Your Vehicle in Gear
*
[DR08800( ALL)03/94]
Your vehicle's gearshift is on the steering
column. The Transmission Control Switch and
indicator light are located on the end of the
gearshift lever. You can put the gearshift in any
of the several positions.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

175
*
[DR08915(BEF )06/94]
one third page art:0021081-A
The positions of the column-mounted gearshift
*
[DR08925( ALL)05/95]
quarter page art:0020771-C
Transmission Control Switch and indicator light (located
on the gearshift lever)
*
[DR09000( ALL)01/93]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
*
[DR09100( ALL)01/95]
Once you place the gearshift securely into
position, gradually release the brake pedal and
use the accelerator as necessary.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

177 %
*
[DR09400( ALL)01/95]
Driving
%*
[DR09500( ALL)04/95]
When to usej(Overdrive)
*
[DR09600( ALL)04/95]
This is the normal driving position. As the
vehicle picks up speed, automatic upshifts to
second, third and fourth gears will occur when
jOverdrive is chosen on the selector and the
transmission control switch has not been
pressed. The transmission will shift into the
correct gear when the right speed is achieved,
for the accelerator pedal position you have
chosen.
*
[DR09700( ALL)03/94]
When to use Drive
*
[DR09800( ALL)05/95]
You will note that there isn't a drive position on
your gearshift indicator. However, you will find
a Transmission Control Switch and an indicator
light labeled ªOverdriveº located on the end of
the gearshift lever. Press this switch and the
word ªOFFº will illuminate on the shift lever
knob. With the word ªOFFº illuminated, the
transmission will operate in gears one through
three. Operating in the Overdrive ªOFFº mode
gives more engine braking than Overdrive and
is useful for descending hills or when towing.
[DR09850( ALL)04/95]
quarter page art:0020771-C
Transmission Control Switch and indicator light (located
on the gearshift lever)
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

178
*
[DR09900( ALL)05/95]
To return the transmission to the normalj
Overdrive operation, press the transmission
control switch again. The Transmission Control
Indicator Light will not be illuminated when
Overdrive operation resumes. This switch may
be used to select O/D ON or O/D OFF any
time the vehicle is being driven.
*
[DR09950( ALL)05/94]
When starting your vehicle, the overdrive system
will automatically be in the normal overdrive
mode.
*
[DR10000( ALL)03/94]
If the Transmission Control Indicator Light is
flashing on and off steadily, a transmission
system malfunction was detected. The
transmission will operate in a failure
management mode and may have harsh
engagements, firm shift feel, or abnormal shift
schedule. If this condition persists, damage to
the transmission could occur. Contact your
dealer as soon as possible.
*
[DR10100( ALL)01/95]
When to use 2 (Second)
*
[DR10200( ALL)01/95]
Use 2 (Second) to start-up on slippery roads or
to provide additional engine braking on
downgrades. This position provides 2 (Second)
gear operation only.
*
[DR10300( ALL)01/95]
When to use 1 (Low)
*
[DR10400( ALL)04/95]
Use 1 (Low) to provide maximum engine
braking on steep downgrades. Upshifts from 1
(Low) can be made by manually shifting to 2
(Second) orj(Overdrive). Selection of 1 (Low)
gear provides only low gear operation from
start-up. Selection of 1 (Low) while at higher
speeds provides a shift to second gear, and a
shift to first gear will occur after the vehicle
decelerates to the proper speed.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

187
*
[DR16101(B F )03/95]
Four-Wheel Drive (4WD)
System (If equipped)
*
[DR16130(B F )08/94]
When you select the 4WD mode, your light
truck uses all four wheels to power itself. This
increases traction, enabling you to drive your
4x4 over terrain and road conditions two-wheel
drive vehicles cannot.
*
[DR16160(B F )10/94]
Power is supplied to all four wheels through a
transfer case that allows you to select four-wheel
drive when necessary. Methods for engaging and
disengaging 4WD and low range will depend on
which system your vehicle has.
*
[DR16190(B F )01/95]
4x4 Systems Ð Lever Operated
*
[DR16220(B F )06/94]
The lever operated transfer case can be placed
into four positions. The 2H position is the
two-wheel drive position in which power is
delivered only to the rear axle. The 4H position
provides four-wheel drive with power delivered
to the front and rear axles for increased traction.
The 4L position provides four-wheel drive with
power delivered to the front and rear axles
when the above average power is required at
reduced speeds. In the N (neutral) position, there
is no power delivered to either axle.
[DR16225(B F )05/95]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

189
*
[DR16310(B F )01/95]
Four-wheel drive operation (4H or 4L) on dry
pavement is not recommended. Operating the
vehicle in four-wheel drive on dry pavement
will increase tire wear, decrease fuel economy,
and make four-wheel drive disengagement
difficult for the transfer case.
*
[DR16340( F )06/93]
NOTE: All transfer cases on F-350 4x4 trucks
are equipped with an opening for a
power take-off (PTO). If this opening
is used for a transfer case mounted
PTO, additional transfer case lubricant
is required. Refer to the Refill
Capacities section for lubricant fill
requirements. Vehicles equipped with
an E4OD automatic transmission and a
7.3L diesel engine will require exhaust
modification for PTO clearance. For
vehicles equipped with an E4OD
automatic transmission: If a transfer
case mounted PTO is operated with the
transfer case shift lever in neutral, a
Vehicle Speed Sensor Self-test error
may be set in the Powertrain Control
Module (PCM) causing the
transmission to function abnormally,
and the Transmission Control Indicator
Light (TCIL) may flash on and off
repeatedly. Normal transmission
function should return when the
transfer case has been engaged and the
vehicle is driven. If the TCIL continues
to flash or the transmission continues
to operate abnormally contact your
Ford dealer as soon as possible.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
