1996 FORD F150 light

190
*
[DR16370(B F )06/94]
4x4 system indicator lights
*
[DR16401(B F )06/94]
A 4x4 light and a LOW RANGE light are
located at the lower right of the instrument
cluster.
*
[DR16430(B F )06/94]
q
2H position Ð Neither the 4X4 or the LOW
RANGE lights are lit.
*
[DR16460(B F )06/94]
q
4H position Ð Only the 4x4 light is lit.
*
[DR16490(B F )06/94]
q
N position Ð Neither the 4x4 or LOW
RANGE lights are lit.
*
[DR16520(B F )06/94]
q
4L position Ð Both the 4x4 and the LOW
RANGE lights are lit.
*
[DR16550(B F )03/91]
Lever Operated System With Automatic
Locking Hubs
*
[DR16580(B F )06/94]
To shift from 2H to 4H:
*
[DR16610(B F )02/92]
Stop the vehicle and move the transfer case shift
lever straight back to the 4H position, the
automatic locking hubs will engage when the
vehicle is driven. When the automatic locking
hubs are engaged, shifts between 2H and 4H
may take place at any speed.
*
[DR16620(B F )02/92]
q
The automatic locking hubs may disengage in
2H if the vehicle's direction is momentarily
reversed, or the vehicle is allowed to roll
slightly in the opposite direction. If a
grinding noise occurs when shifting from 2H
to 4H while the vehicle is moving, one or
both of the automatic locking hubs have been
disengaged and the transfer case shift lever
should be switched back to the 2H position.
To shift back into 4H, stop the vehicle and
move the transfer case shift lever straight
back to the 4H position.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

192one continuous motion without pausing in the N
(neutral) position. Pausing in the neutral position
can result in gear clash and difficult shifting. If,
while shifting between 4H and 4L, the transfer
case gets stuck in the N (neutral) position or is
difficult to shift into either 4H or 4L, it may be
necessary to let the vehicle roll slightly and/or
turn off the engine (particularly on vehicles
equipped with automatic transmissions).
*
[DR16880(B F )03/91]
To shift into and out of N (neutral)
*
[DR16910( F )05/91]
To shift into N (neutral), stop the vehicle and
engage the parking brake. Place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. From
either the 4H or 4L position, push the transfer
case shift knob down (toward the ground) and
at the same time move the transfer case shift
lever to the N (neutral) position. The N (neutral)
position should only be used for vehicle towing
or transfer case mounted PTO use (transfer case
PTO opening available on F-350 only).
*
[DR16955(B F )12/91]
NOTE: Dash mounted four wheel drive
indicator lights are off when your
vehicle is in neutral.
*
[DR17001(B F )05/91]
To shift from N (Neutral) to either 4H or 4L,
stop the vehicle and engage the parking brake.
Place the automatic transmission into NEUTRAL
or depress the clutch on manual transmission
vehicles. Push the transfer case knob down
(toward the ground) and at the same time move
the transfer case shift lever to the desired
position. If it is difficult to shift into either 4H or
4L, it may be necessary to let the vehicle roll
slightly and/or turn off the engine (particularly
on vehicles equipped with automatic
transmissions).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

194
*
[DR17270(B F )06/94]
Operating in 2H with the hubs in the LOCK
position increases fuel consumption, noise,
vibration, and wear. For prolonged 2H operation
on dry pavement, set the manual locking hubs
to the FREE position.
*
[DR17301(B F )06/94]
To shift between 4H and 4L:
*
[DR17330(B F )05/91]
Stop the vehicle and place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. Push the
transfer case shift knob down (toward the
ground) and at the same time pull or push the
lever straight forward or rearward (depending
on the desired position 4H or 4L) in order to
shift the transfer case. This shift should be with
one continuous motion without pausing in the N
(neutral) position. Pausing in the neutral position
can result in gear clash and difficult shifting. If,
while shifting between 4H and 4L, the transfer
case gets stuck in the N (neutral) position or is
difficult to shift into either 4H or 4L, it may be
necessary to let the vehicle roll slightly and/or
turn off the engine (particularly on vehicles
equipped with automatic transmission).
*
[DR17390(B F )06/94]
To shift to N (neutral) from either 4H or 4L
*
[DR17420( F )05/91]
To shift into N (neutral), stop the vehicle and
engage the parking brake. Place the automatic
transmission into NEUTRAL or depress the
clutch on manual transmission vehicles. From
either the 4H or 4L position, push the transfer
case shift knob down (toward the ground) and
at the same time move the transfer case shift
lever to the N (neutral) position. The N (neutral)
position should only be used for vehicle towing
or transfer case mounted PTO use (transfer case
PTO opening available on F-350 only).
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

195
*
[DR17490(B F )12/91]
NOTE: Dash mounted four wheel drive
indicator lights are off when your
vehicle is in neutral.
*
[DR17540(B F )01/95]
To shift from N (Neutral) to either 4H or 4L,
stop the vehicle and engage the parking brake.
Place the automatic transmission into N
(Neutral) or depress the clutch on manual
transmission vehicles. Push the transfer case shift
lever to the desired position. If it is difficult to
shift into either 4H or 4L, it may be necessary to
let the vehicle roll slightly and/or turn off the
engine (particularly on vehicles equipped with
automatic transmissions).
*
[DR17570(B F )06/94]
4x4 SYSTEMS-TOUCH DRIVE
*
[DR17601(B F )06/94]
The Touch Drive 4x4 system functions in three
modes. In Two Wheel Drive mode, power is
delivered only to the rear axle at normal road
speed. The 4H position provides four-wheel
drive with power delivered to the front and rear
axles for increased traction. The 4L position
provides four-wheel drive with power delivered
to the front and rear axles when the above
average power is required at reduced speeds.
*
[DR17630(B F )06/94]
Four wheel drive operation (4x4 or 4x4 LOW
RANGE) on dry pavement is not recommended.
Operating the vehicle in four-wheel drive on dry
pavement will increase noise, vibration, tire
wear, decrease fuel economy, and make
four-wheel drive disengagement difficult for the
transfer case.
%*
[DR17660(B F )06/94]
Touch Drive system indicator lights
*
[DR17690(B F )03/91]
A 4x4 indicator light and a LOW RANGE
indicator light are located at the lower right of
the instrument cluster. In addition, two small
amber lights are located near the Touch Drive
system buttons. The amber light to the left of the
4x4 button will light up at the same time as the
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

1964x4 instrument panel light. The amber light to
the left of the LOW RANGE light will light up
at the same time as the instrument panel LOW
RANGE light.
*
[DR17750(B F )06/94]
q
Two Wheel Drive mode Ð Neither the 4x4
nor the LOW RANGE lights are lit.
*
[DR17780(B F )06/94]
q
4x4 mode Ð Only the 4x4 light is lit.
*
[DR17810(B F )06/94]
q
4x4 LOW RANGE mode Ð Both the 4x4 and
LOW RANGE lights are lit.
*
[DR17840(B F )06/94]
To shift from Two-Wheel Drive to 4x4:
*
[DR17871(B F )06/94]
To shift into 4x4, push the 4x4 button located on
the instrument panel. This shift can be done at a
stop or at speeds up to 55 miles per hour
(88 km/h). When the vehicle is driven, the
automatic locking hubs will engage. If the
vehicle is stopped while in 4x4 and the vehicle
direction is reversed from the previous direction,
the automatic locking hubs will momentarily
disengage and reengage. The automatic locking
hubs may click as they automatically engage in
the new direction.
*
[DR17900(B F )05/91]
one third page art:0020634-B
Touch drive electric shift switch
*
[DR17945(B F )06/92]
Ð At extremely low temperatures, it may be
necessary to slow down or even stop to shift
from two wheel drive to 4x4.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

198movement of front-wheel drive components
while operating in two-wheel drive.
*
[DR18230(B F )03/91]
To shift from 4x4 to 4x4 LOW RANGE:
*
[DR18290(B F )06/92]
Stop the vehicle and place the automatic
transmission in NEUTRAL or depress the clutch
on vehicles with a manual transmission. Push
the LOW RANGE button on the instrument
panel to shift the transfer case from 4x4 to 4x4
LOW RANGE. Both the 4x4 and LOW RANGE
lights are now lit.
*
[DR18300(B F )08/94]
NOTE: The vehicle must already be in 4x4
before pushing the Low Range Button.
*
[DR18320(B F )03/91]
To shift from 4x4 LOW RANGE to 4x4:
*
[DR18380(B F )06/94]
Stop the vehicle and place the automatic
transmission into NEUTRAL or depress the
clutch on vehicles with a manual transmission.
Push the LOW RANGE button on the instrument
panel to shift the transfer case from 4x4 LOW
RANGE to 4x4.
*
[DR19200(B F )01/89]
Driving Off Road with 4-Wheel
Drive
*
[DR19300(B F )11/89]
Most vehicles with four-wheel drive are
especially equipped for driving on sand, snow,
mud, or rough terrain and have operating
characteristics that are somewhat different from
conventional vehicles, both off and on the road.
The driving tips below will help you learn to
use four-wheel drive.
*
[DR19400(B F )10/94]
q
Do not use 4WD LOW on dry, hard-surfaced
roads.
*
[DR19600(B F )11/89]
q
Special maintenance procedures are necessary
after operating with drive components in
water.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

199
*
[DR19700(B F )08/94]
q
Manual locking hubs must be in LOCK
position before shifting into four-wheel drive.
*
[DR19800(B F )11/89]
When using four-wheel drive, maintain steering
wheel control at all times, especially in rough
terrain. Since sudden changes in terrain can
result in abrupt steering wheel motion, make
sure you grip the steering wheel rim from the
outside. Do not grip the spokes.
*
[DR19900(B F )05/90]
Drive cautiously to avoid vehicle damage from
concealed objects such as rocks and stumps.
Know the terrain or examine maps of the area in
question before driving. Map out your route
beforehand. To maintain steering and braking
control of your vehicle, you must have all four
tires on the ground, and they must be rolling,
not sliding or spinning.
*
[DR19925(B F )11/89]
Transmission upshift in 4x4 with transfer case in
4L may be quite firm due to large total gear
reduction. This condition is normal.
*
[DR20000(B F )11/89]
Sand
*
[DR20100(B F )11/89]
When driving over sand, try to keep all four
wheels of the vehicle on the most solid area of
the trail. Do not reduce the tire pressures but
shift to a lower gear and drive steadily through
the terrain. Apply accelerator slowly and avoid
spinning the wheels.
*
[DR20200(B F )11/89]
Mud and Water
*
[DR20300(B F )12/89]
When driving through water, determine the
depth; avoid water higher than the bottom of
the hubs (if possible) and proceed slowly. If the
ignition system gets wet, the vehicle may stall.
*
[DR20400(B F )11/89]
Once through water, always try the brakes. Wet
brakes do not stop the vehicle as effectively as
dry brakes. Drying can be improved by moving
your vehicle slowly, while applying light
pressure on the brake pedal.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996

202
*
[DR21900(BEF )10/94]
Rear Drum Brakes
*
[DR22000(BEF )03/95]
The rear drum brakes are self-adjusting.
Automatic adjustment occurs when the brakes
are applied while ªbacking up.º If normal
operation does not include much backing, adjust
the brakes when they seem ªlow,º using the
procedure underIf Brakes Do Not Grip Well or
Pedal is Lowin this chapter.
*
[DR22025( F )03/91]
Rear Disc Brakes (F-Super Duty and
F-Series Stripped Chassis Only)
*
[DR22050( EFM)04/95]
The rear disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of the caliper slide rails and
inspection for pad wear.
*
[DR22100( ALL)11/89]
Hydraulic Power Brakes
*
[DR22200(BEF )08/94]
The hydraulic brake system is made up of two
independent hydraulic circuits. One hydraulic
circuit supplies fluid to the front disc brakes and
the other hydraulic circuit supplies fluid to the
rear drum brakes. These two circuits are
supplied by a common hydraulic brake fluid
reservoir, with a fluid level sensor.
*
[DR22300( ALL)11/89]
The brake light in the instrument cluster will
light for low brake fluid in the common brake
fluid reservoir.
*
[DR22400( ALL)05/95]
RWARNING
An increase in pedal travel will result in
reduced braking capability. The brake
system should be checked immediately.
File:ltdrf.ex
Update:Thu May 9 15:17:55 1996
