1996 FORD F150 light

113
*
[FV16300(BEF )02/95]
Locking the doors with the remote entry
system
[FV16500(B F )04/95]
To lock all the doors, press the LOCK button.
*
[FV16600(B F )03/93]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. The door will lock again,
the horn will beep, and the external lamps will
flash.
%*
[FV16800(BEF )02/95]
Remote entry personal alarm
*
[FV16900(BEF )04/95]
If you wish to activate the remote entry system
personal alarm, press the PANIC button. This
will honk the horn and flash the lights for
approximately 2 minutes 45 seconds. You can
turn it OFF by pressing the PANIC button again
from the same transmitter or by turning the
ignition to the ON or ACCESSORY position.
*
[FV17000(BEF )02/95]
When you use the remote entry UNLOCK or
PANIC buttons, the illuminated entry system
turns on the vehicle's interior lights for 25
seconds. You can turn these lights off with the
remote entry LOCK button or by turning the
ignition to the ON or ACCESSORY position.
*
[FV17100(BEF )04/94]
quarter page art:0060566-B
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

115
*
[FV18001(BEF )02/95]
quarter page art:0020790-A
Replacing the batteries
%*
[FV18101(BEF )02/95]
Replacing lost transmitters
*
[FV18200(BEF )02/95]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
*
[FV18301(BEF )02/95]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
*
[FV18601(BEF )04/95]
Illuminated Entry System (If equipped)
[FV18701(BEF )04/95]
This system will provide illumination of the
vehicle's interior courtesy lamps when either
outside front door handle is pulled or when the
Remote Entry System is used to unlock the door
or sound the Personal Alarm. The system will
automatically turn off after approximately 25
seconds or when the ignition is turned to the
START or ACCESSORY position.
*
[FV18801(BEF )04/94]
NOTE: The inside lights will not turn off if
you have turned them on with the
dimmer knob or if any door is open.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

116
*
[FV18900(B F )04/94]
Battery Saver (with Remote Entry Ð
If equipped)
*
[FV19000(B F )03/95]
When the ignition is turned off, the vehicle will
turn off battery voltage to all of these lights after
40 minutes: glove box, engine compartment,
overhead console, mirror, courtesy and
interior (including cargo) lamps.
*
[FV19102(B F )03/95]
This will prevent draining of the battery if these
lights have been left on inadvertently or if a
door is not completely closed. Battery voltage to
these lamps will be restored when the remote
entry transmitter is used, any door is opened, or
the ignition key is turned on again.
*
[FV19250(BEF )02/95]
Windows
*
[FV19300(BEF )03/95]
Operating the Windows Manually
*
[FV21100( F )02/91]
Cab rear sliding window (If equipped)
*
[FV21300( F )06/94]
To open the sliding cab window, release the
latch by pulling the left portion of the snap lock
away from the window, then move the window
to the desired position. To close, slide the
windows to the center and snap the latch closed.
*
[FV21400( F )06/92]
quarter page art:0020208-A
Sliding cab window
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

131 %
*
[FV50700(B F )01/95]
Automatic Dimming Inside Rearview
Mirror (If equipped)
*
[FV50850(B F )03/93]
half page art:0021008-A
Automatic dimming inside rearview mirror
*
[FV50900(B F )03/93]
This mirror is equipped with an electrochromic
glare control feature that automatically darkens
the mirror, reducing glare from the headlamps
of vehicles behind you. A forward facing light
sensor measures the ambient light just as your
eyes do. When the rear facing light sensor in the
glass senses glare, such as from following
headlights, it energizes a chemical layer in the
glass causing it to darken and absorb light. As
the glare subsides, the mirror glass returns to its
normal clear state.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

132
*
[FV51050(B F )03/94]
To turn the mirror on, push the On/Off switch,
located on the bottom of the mirror, to latch it
in the ON position. The button will be latched in
the up position and at night a low intensity
green light will be visible from the button when
the mirror is turned on. To turn the mirror off,
push the On/Off switch again and the button
will unlatch shutting off the light and the mirror
will be off.
*
[FV51100(B F )03/93]
DemonstrationÐ The mirror's operation may
be demonstrated by simulating glare as follows:
*
[FV51200(B F )03/94]
1. Cover the forward facing sensor, located on
the right side of the mirror back, with a
dark (preferably black) cloth. Hold the dark
cloth over the sensor until you notice the
mirror glass start to darken to the non-glare
state. If the surrounding lighting conditions
are too dark it may be necessary to shine
additional lighting, such as from a flashlight,
on the rearward sensor located on the glass
face.
*
[FV51400(B F )03/93]
2. Remove the cloth (and shut off the flashlight
if applicable) and the glass will return to the
clear reflective stage.
*
[FV51500(B F )01/95]
One important safety feature is that the mirror
automatically returns to the normal position
whenever the vehicle is placed in R (Reverse)
(when the mirror is in the ON position). This
feature ensures a bright clear view in the mirror
when backing up.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

133
*
[FV52400( EF )05/93]
Illuminated Vanity Mirror (If equipped)
*
[FV52500( EF )05/93]
Your vehicle may feature illuminated vanity
mirrors on the sun visors. You can turn on the
lighted mirror by lifting the mirror door cover.
*
[FV52600( EF )05/93]
quarter page art:0020251-A
Visor vanity mirror
*
[FV52700( F )05/93]
Visors that are equipped with the lighted vanity
mirror also have an auxiliary visor. The auxiliary
visor slides right and left to cover the
windshield when the primary visor is pivoted to
the door window.
*
[FV52800( F )05/93]
one third page art:0020665-A
Auxiliary sun visor
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

138
*
[FV69900(BEF )03/95]
Power Point Electrical Outlet
*
[FV70000(B F )05/94]
The power point outlet is located on the
instrument panel to the right of the shift lever.
This outlet should be used in place of the
cigarette lighter for optional electrical accessories.
*
[FV70200(BEF )06/92]
NOTE: Do not use the cigarette lighter in
place of the power point.
*
[FV70300(B F )06/92]
quarter page art:0020929-A
Power point electrical outlet
*
[FV70500(B F )07/92]
To access the outlet, lift up the hinged cover.
File:ltfvf.ex
Update:Thu May 9 15:20:08 1996

150
*
[AS07400(BEF )04/95]
How to eject the disc
*
[AS07500(BEF )04/95]
Push the ªEJECTº button to stop play, eject the
disc and resume radio operation of your audio
system.
*
[AS07600(BEF )04/95]
NOTE: You can eject the disc while the radio
power and/or ignition is on or off.
%*
[AS08100(BEF )04/95]
How To Take Care of and Clean Your CD
Player and Discs
*
[AS08200(BEF )04/95]
To ensure the continued performance of your
Ford Compact Disc Player, carefully read the
following precautions:
*
[AS08300(BEF )04/95]
q
Always handle the disc by its edge. Never
touch the playing surface.
*
[AS08400(BEF )04/95]
q
Before playing, inspect the disc for any
contamination. If needed, clean the disc with
an approved disc cleaner, such as the
DiscwasherHCompact Disc Cleaner or the
Allsop 3HCompact Disc Cleaner, by wiping
from the center out to the edges.Do not use
a circular motion to clean.
*
[AS08500(BEF )04/95]
q
Do not clean discs with solvents such as
benzine, thinner, commercially available
cleaners or antistatic spray intended for
analog records.
*
[AS08600(BEF )04/95]
q
Do not expose the disc to direct sunlight or
heat sources such as defroster and floor
heating ducts. Do not leave any discs in a
parked car in direct sunlight where there may
be a considerable rise in temperature or
damage may result.
*
[AS08700(BEF )04/95]
q
After playing, store the disc in its case.
*
[AS08800(BEF )04/95]
q
If a disc has already been inserted, do not try
to insert another disc. Doing so may damage
the disc player.
