Fan speed and thumbwheel
*
[IP18401( GV)02/95]
Your EATC automatically adjusts the fan speed
to the existing conditions. You must push
AUTOMATIC for automatic fan speed operation.
To control the fan speed yourself, use the
thumbwheel which will cancel the automatic fan
speed control. The thumbwheel is located at the
extreme right side of the EATC control panel. It
is a vertical control marked with a fan symbol.
Rotate up for HI and down for LO speeds.
[IP18501( GV)03/95]
one third page art:0011304-B*
[IP18601( GV)03/95]
When you move the thumbwheel, the fan speed
will go to manual control. The display window
will show the
Hsymbol in the lower right
corner along with the selected temperature and
operating function.
[IP18701( GV)05/95]
quarter page art:0011305-CFile:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

97
*
[IP18801( GV)02/95]
You can override the fan speed at any time. If
you use the thumbwheel to override the fan
speed, the EATC will continue to control the
temperature but you control the fan speed. To
return to auto fan control, press the
AUTOMATIC button. If you are operating in
one of the override functions (FLOOR, MAX
A/C, etc.), automatic fan control will continue
unless you rotate the fan thumbwheel. To return
to automatic fan control, press the AUTOMATIC
button. The EATC will return to Automatic
operation. If you want to return to any override
function, press the button for that function. The
fan speed will continue to be automatically
controlled.
*
[IP18901( GV)01/95]
Manual override buttons
*
[IP19001( GV)02/95]
Your EATC has six buttons which allow you to
make special selections. The buttons are located
along the bottom edge of the EATC control and
allow you to determine where the air will be
discharged. Pressing any override button
changes the air discharge location only. It does
not affect the ability of the system to control
temperature or the fan speed. Return to fully
Automatic operation by pushing the
AUTOMATIC button.
*
[IP19101( GV)01/95]
MAX A/C button
[IP19201( GV)05/94]
The MAX A/C feature allows for faster cooling
because air is drawn from inside the car. Using
inside air causes the fan to sound louder which
is normal for this selection. The Display window
will indicate MAX A/C under the selected
temperature. The airflow will be from the
instrument panel registers.
File:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

98
*
[IP19301( GV)01/95]
NORM A/C button
*
[IP19400( GV)01/95]
When you push this button, you select air
conditioning using outside air. The Display
window will indicate A/C under the selected
temperature. The cooled air will flow from the
instrument panel registers. The fan speed will
continue on automatic.
%*
[IP19500( GV)01/95]
VENT button
[IP19600( GV)03/95]
Push this button to select outside air through the
instrument panel registers. The display window
will show the set temperature and VENT to the
lower right of the temperature. Your EATC will
heat the air if the temperature you have selected
is warmer than the outside air coming into the
vehicle. However, the air will NOT be cooled
regardless of the temperature setting. Airflow
will be from the instrument panel registers.
*
[IP19700( GV)02/95]
FLOOR button
*
[IP19800( GV)05/95]
Airflow will be to the floor when the FLOOR
button is pressed. The display window will
show the set temperature and FLR to the left of
the temperature. The air cannot be cooled in the
FLOOR position, only heated. Fan speed will be
automatic unless manually controlled. If you
override the fan speed and wish to return to
automatic fan control, push AUTOMATIC. Then,
again select FLOOR for airflow to the floor.
%*
[IP19900( GV)02/95]
FLR & DEF button
[IP20000( GV)03/95]
Push this button to get air to the floor and
windshield defrosters at the same time. The
display will show the set temperature, FLR and
the Defrost symbolVto indicate FLR-DEF has
been selected. If the outside temperature is about
50ÊF (10ÊC) andabove, the air will be
dehumidified to remove moisture. This will help
to prevent fogging in humid weather.
File:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

99
*
[IP20100( GV)02/95]
DEFVbutton
[IP20200( GV)03/95]
Press the DEFVbutton to obtain maximum
airflow to the windshield. Adjust the
temperature setting as required for defrosting.
The Display window will show the temperature
setting with the defrost symbolVto the left of
the temperature. When the outside temperature
is about50ÊF (10ÊC) andabove, the air will be
dehumidified to remove moisture. This will help
prevent fogging in humid weather.
*
[IP20300( GV)04/95]
OUTSIDE TEMP button
*
[IP20400( GV)01/95]
By pressing this button the temperature of the
air outside of the vehicle will show in the
display. The outside temperature will continue to
be displayed until the OUTSIDE TEMP button is
pressed again to cancel. If the selected
temperature setting is changed while the outside
temperature is displayed, the new selected
temperature will be displayed for 4 seconds after
it is changed. Then, the outside temperature will
return to the window. If a manual override is
pressed or the thumbwheel is rotated while the
outside temperature is displayed, the window
will show the change for 4 seconds. Then, the
outside temperature will return along with the
changed override selection.
[IP20500( GV)05/95]
quarter page art:0011306-CFile:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

100
*
[IP20600( GV)02/95]
If the EATC is turned OFF while the outside
temperature is displayed, the temperature will
continue to be displayed. Press the OUTSIDE
TEMP button to clear the display window. When
the ignition key is turned OFF the display will
be blank (dark).
*
[IP20700( GV)01/95]
NOTE: The outside temperature reading is
most accurate when the vehicle is
moving. Higher readings may be
obtained when the vehicle is not
moving. The readings that you get may
not agree with temperatures given on
the radio due to differences in vehicle
and station locations.
*
[IP20800( GV)04/95]
Operating tips
*
[IP20900( GV)04/95]
The following tips will help you to get the most
satisfaction from your Electronic Automatic
Temperature Control system.
*
[IP21000( GV)02/95]
q
In humid weather, select DEFVbefore
starting your engine. This will help to
prevent windshield fogging. After a few
minutes of operation, switch to AUTOMATIC
or an override selection of your choice.
*
[IP21100( GV)04/95]
q
To prevent humidity buildup inside your
vehicle, always drive with the EATC System
turned on.
*
[IP21200( GV)03/95]
q
Do not put objects under the front seats that
interfere with the flow of air to the back seat
area.
*
[IP21300( GV)04/95]
q
Remove any snow, ice, or leaves from the air
intake area of your EATC System which
could block the air intake. The intake area is
located at the bottom of the windshield,
under the hood at the passenger side rear
corner.
File:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

101
*
[IP21400( GV)04/95]
Service
*
[IP21500( GV)04/95]
If your EATC is not operating as described here,
take it to your dealer to have it checked. System
diagnostics are built in which will allow your
dealer to readily identify problems that might
occur.
% [IP31800( GV)12/91]Rear Window Defroster
*
[IP32000( ALL)12/91]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window.
[IP32800( GV)03/94]
The button for the rear window defroster is
located on the left hand (driver's) side of the
instrument panel.
[IP32900( GV)05/94]
one third page art:0010191-F
The button that controls the rear window defroster
[IP33000( ALL)12/94]
Clear away any snow that is on the rear
window before using the defroster. With the
engine running, push the defrost button.
[IP33100( ALL)12/94]
After approximately 10 minutes, the defroster
will turn off. If the window is still not clear,
turn the defroster on again.
[IP33200( ALL)12/94]
The defroster will turn off when the ignition key
is turned to the OFF position.
File:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

102
*
[IP33300( ALL)02/95]
The heating elements are bonded to the inside of
the rear window. Do not use sharp objects to
scrape the inside of the rear window or use
abrasive cleaners to clean it. Doing so could
damage the heating elements.
%
*
[IP34200( ALL)01/95]
The Interior and Exterior Lights
%*
[IP34310( ALL)01/95]
Daytime Running Light System
*
[IP34312( ALL)03/95]
(Canadian vehicles only)
*
[IP34320( ALL)03/95]
The Daytime Running Light (DRL) system turns
the high beam headlamps on, with a reduced
light output, when:
*
[IP34325( ALL)03/95]
q
The headlamp system is in the OFF position,
and
*
[IP34330( ALL)03/95]
q
The vehicle is running, and
*
[IP34340( ALL)01/95]
q
The vehicle has a fully released parking
brake.
*
[IP34360( BCGV)01/95]
NOTE: If you have a vehicle with an
automatic lighting system, the DRL
system is active until the automatic
system turns on the headlamps.
*
[IP34363( ALL)10/94]
NOTE: The high beam indicator will not turn
on in the flash-to-pass mode during
nighttime driving.
*
[IP34365( ALL)01/95]
NOTE: You may notice that the lights flicker
when the vehicle is turned on or off.
This is a normal condition.
*
[IP34367( ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system
will not illuminate the tail lamps and
parking lamps. Turn on your headlamps
at dusk. Failure to do so may result in a
collision.
File:rcipv.ex
Update:Wed Jan 31 10:22:47 1996

103 %
*
[IP34370( ALL)01/95]
Turning On the Exterior Lights
*
[IP34550( BCGV)05/95]
To turn on the headlamps, parking lamps, side
markers, and tail lamps, use the rotary knob that
is to the left of the steering wheel.
[IP35100( GV)05/95]
one third page art:0010197-H
The knob that controls the headlamps and parking lamps
[IP35200( ALL)12/91]
When you turn on the headlamps, the parking
lamps, tail lamps, and side markers
automatically turn on. But you can turn on the
parking lamps, tail lamps, and side markers
without turning on the headlamps.
*
[IP36100( ALL)01/95]
For more information about how the high beams
work, refer to theSteering Column Controls
chapter.
[IP36130( BCGV)05/95]
Chime for headlamps on
*
[IP36160( BCGV)05/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
%*
[IP36200( ALL)05/95]
Cleaning the Exterior Lamps
*
[IP36300( ALL)05/95]
Do not use dry paper towel, chemical solvents
or abrasive cleaners to clean the lamps, as these
may cause scratches or crack the lamps.
