1995 HONDA ODYSSEY Owners Manual

Seats

Adjust the seat-back before you start driving. The seat-backs should be in
an upright position for you and your
passengers to get the most protec-
tion from the seat belts.
To change the seat-back angle of the front seats, or the second-row seatsin the six passenger model, pull up
on the lever on the outside of the
seat bottom. To adjust the seat-back
angle of the second seat in the seven- passenger model, pull up on the lever
on the side of the seat-back.
Move the seat-back to the desired
position and release the lever. Let
the seat-back latch in the new
position.
Driver's Seat Power Height
Adjustment

U.S. EX model only

The height of your driver's seat is power adjustable. Pull up the switch
to raise the seat. Push it down to
lower the seat.

Instruments and Controls

Reclining the seat-back can
decrease the protection you get
from your seat belt in a crash.
You can slide under the seat belt and be seriously injured.
Adjust the seat-back to an upright position and sit well
back in the seat.ProCarManuals.comMain Menu Table of Contents s t

Seats

Head Restraints
The head restraints are designed to help reduce the risk of neck injuries.
Your Honda has adjustable head restraints in all the outside seating
positions. Adjust the head restraintso the top is even with the tops of
your ears. The head restraints adjust for height.
You need both hands to adjust the
restraint. Do not attempt to adjust it
while driving. To raise it, pull upward.
To lower the restraint, press the release button and push the restraintdown.
To remove a head restraint for cleaning or repair, pull it up as far as
it will go. Press the release button
and pull the restraint out of the seat-
back. Third Seat Access

Six-passenger model

To get into or out of the third row seat, walk between the second row

seats.

Instruments and Controls
KNOB

Driving your vehicle without
head restraints can lead to a
serious injury to you and your passengers in a crash.
Make sure the head restraints
are in place and adjusted properly before driving.ProCarManuals.comMain Menu Table of Contents s t

Seats

Seven-passenger model

LOCK RELEASE LEVER

Pull the seat-back angle adjustment
lever on the second row seat to tilt
the seat-back forward. Pull the lock
release lever and pivot the seat up out of the way. Move the second seat back into
place by pivoting the seat down. Make sure it locks to the floor. Pull
the seat-back angle adjustment lever
forward and push the seat-back to
the desired position, then release the
lever. Make sure the seat is securely
locked in place. Removing the Second Seats in the
Six-Passenger Model
Both seats can be removed to give
more cargo capacity.
To remove a seat, unlock the seat from the floor by pulling both lockrelease levers up at the same timeand pulling up on the rear of the seat.

CONTINUED

Instruments and Controls
LOCK RELEASE LEVERProCarManuals.comMain Menu Table of Contents s t

Seats

Unhook the front of the seat from
the floor by pulling it back slightly,
then pivoting it upward.
Always remove an unlocked seat from the vehicle before driving. Aseat that is not locked in place could
fly around and cause injury in a sudden stop or crash.
To reinstall a seat, hook the front of

the seat to the floor, then push the

back into the locks. Make sure both
the front and the back of the seat aresecurely fastened down before

driving. Folding the Second Seats in the
Seven-Passenger Model
The left and right halves of the second seat can be folded up
separately to create more cargo

space.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Seats

SEAT-BACK ANGLE

ADJUSTMENT LEVER
RIVET

LOCK RELEASE LEVER

Pull the seat-back angle adjustment
lever and tilt the seat-back forward.
Then pull the lock release lever and pivot the seat forward. Pull out the fastening strap. Hook
the ring on the fastening strap to the
rivet on the side of the seat-back. Make sure the seat is secure.
Reverse this procedure to return the seat to the upright position. Make
sure you store the fastening strap
properly, and that the seat is locked securely before driving. Reclining the Second Seat

Seven-passenger model only

You can recline the seat-backs on the second seat so they are level with
the seat cushion of the third seat, making a large, cushioned area. Todo this:
1. Remove the head restraints. Store them in the pocket in the left side
panel behind the third seat.

Instruments and Controls CONTINUED

FASTENING STRAPProCarManuals.comMain Menu Table of Contents s t

Seats

ANGLE ADJUSTMENT LEVER
SLIDE LEVER
2. Lift the lever and slide the seat forward as far as it will go. Pull theseat-back angle adjustment lever
and pivot the seat-back backward.
Release the lever when the seat-
back is even with the cushion on
the third seat.
Reverse this procedure to return the second seat to the upright position.
Make sure you install the head
restraints before driving (see page 58). Folding the Third Seat in All
Models
To create more cargo space, you can fold the third seat into the floor
recess.

To fold the third seat:
1. Remove the head restraints. Store them in the pocket in the left side

panel.
KNOB

2. Unlock the seat-back by turning
the knob. Push the seat-back

forward.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Seats

KNOB
3. Turn the knob on the back of the seat cushion while you pull the
entire seat towards you. Pivot the seat into the floor recess. To return the seat to the upright
position:
1. Pull the seat out of the recess by pulling on the handle. Pivot theseat forward all the way. KNOB
2. Turn the knob on the seat-back and pull the seat-back upright.
Make sure the seat is securely
locked in place.
3. Reinstall the head restraints.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Power Windows

Your car's windows are electrically- powered. Turn the ignition switch toON (II) to raise or lower any window.
Each door has a switch that controls
its window. To open the window,
push the switch down and hold it.
Release the switch when you want
the window to stop. Close the
window by pulling back on the switch and holding it.
DRIVER'S WINDOW
SWITCH
MAIN

SWITCH

The driver's armrest has a master power window control panel. To open any of the passengers' windows,
push down on the appropriate switch and hold it down until the window
reaches the desired position. To
close the window, pull back on the
window switch. Release the switch
when the window gets to the position
you want.
The master control panel also con-
tains these extra features:
AUTO — To open the driver's window fully, push the window switch firmly down and release it.
The window automatically goes all the way down. To stop the window
from going all the way down, pull back on the window switch briefly.
To open the driver's window only partially, push the window switchdown lightly and hold it. The window
will stop as soon as you release the
switch.

The AUTO function only works to lower the driver's window. To raise
the window, you must pull back on
the window switch and hold it untilthe window reaches the desired

position.

Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t
