1995 HONDA ODYSSEY Owners Manual

Ashtrays, Interior Lights

Use the ashtray only for cigarettes,

cigars and other smoking materials. To

prevent a possible fire and damage to
your car, don't put paper or other
things that can burn in the ashtray.
Ceiling Lights
Your Honda has two ceiling lights. Each ceiling light has a three-
position switch. In the OFF position,
the lights do not come on. In the center position they come on when
you open any door. In the ON position, they stay on continuously. Spotlights
On some models
Turn on the spotlight by pushing the button next to each light. Push the
button again to turn it off.
Instruments and Controls
DOOR ACTIVATED

NOTICEProCarManuals.comMain Menu Table of Contents s t

Interior Lights

Tailgate Light
The tailgate light has a two position switch. In the OFF (down) position,
the light does not come on. In the ON (up) position, the light comes on
when you open the tailgate. Courtesy Lights
Each door has a courtesy light. This
light comes on when you open the
door.

Your car also has a courtesy light in the ignition switch. This light comeson when you open the driver's door.
It remains on for several seconds
after the door is closed.
Instruments and ControlsProCarManuals.comMain Menu Table of Contents s t

Comfort and Convenience Features

The heating and air conditioning
system in your car provides a com-
fortable driving environment in all

weather conditions.

The audio sound system is very
versatile. To get the most from this system, take the time to learn what
the controls do.

Some models have an anti-theft
audio system that requires a code

number to enable it. Heating and Cooling........................ 76

What Each Control Does............ 78
How to Use the System............... 79

Controlling Air Flow
Direction............................... 79
Ventilation................................ 79
To Cool with A/C.................... 80
To Heat..................................... 80
To Heat and Dehumidify with Air Conditioning.......... 81
To Defog and Defrost............. 82
To Turn Everything Off ............. 82
Rear A/C Unit.............................. 83
Audio System (US EX and

Canadian EX).......................... 84

AM/FM/Cassette Stereo Audio System...................................... 84
Operating the Radio.................... 85
Finding the Radio Station........... 85
Presetting..................................... 86
Adjusting the Sound.................... 87
Radio Frequencies....................... 88Operating the Cassette Player... 89
Cassette Search Functions......... 90
Caring for Cassettes.................... 91 Audio System (US EX).................... 92
AM/FM/Cassette Stereo Audio
System....................................... 92

Operating the Radio.................... 93
Finding the Radio Station........... 93
Presetting..................................... 94

Adjusting the Sound.................... 96 Radio Frequencies....................... 97Operating the Cassette Player... 98
Cassette Search Functions......... 99
Caring for Cassettes.................. 100
Operating the CD Player.......... 101
CD Error Indications................. 104
Caring for the Cassette Player..... 105
Theft Protection............................. 106
Comfort and Convenience FeaturesProCarManuals.comMain Menu s t

Heating and Cooling

This system has full heating, venti- lation, and air conditioning capabi-
lities. You can adjust the system
controls to mix these in various
combinations. The air flows into the
interior at three possible levels,
which you can select. CENTER VENT
SIDE VENT
The direction of air flow from the vents in the center and each side ofthe dashboard is adjustable. Move
the tab in the center of each vent up-and-down and side-to-side.
The side vents can be opened and closed with the dials next to them. The heating and cooling system
draws air through the exterior vents
at the bottom of the windshield.
Keep these vents clear of leaves and
other debris.

Comfort and Convenience FeaturesProCarManuals.comMain Menu Table of Contents s t

Heating and Cooling

Comfort and Convenience FeaturesProCarManuals.comMain Menu Table of Contents s t

Heating and Cooling

What Each Control Does Fan Control LeverSliding this lever to the right
increases the fan speed, which
increases air flow.
Temperature Control Lever Sliding this lever to the right
increases the temperature of air
flowing from the system.
Mode Buttons
These buttons control the direction of air flow. The indicator light shows
which button is controlling air flow.
Air Conditioning (A/C) Switch
This switch turns the air condi- tioning ON and OFF. The indicator
in the switch lights when the A/C is
ON.
TEMPERATURE CONTROL LEVER
Fresh Air and Recirculation Buttons
These two buttons control the source of air going into the system. In Fresh Air mode air
comes from outside the car. In
Recirculation mode the
interior air recycles through the

system.
FAN CONTROL

LEVER

AIR CONDITIONING

SWITCH

Comfort and Convenience Features FRESH AIR
BUTTON
RECIRCULATION AIR BUTTON
MODE BUTTONSProCarManuals.comMain Menu Table of Contents s t

Heating and Cooling

How to Use the System
This section covers the best way to use the system for ventilation,cooling, dehumidifying, defrosting
and heating. In most cases, the mode
and air source selections are only
recommendations. You may prefer different settings. Use mode to heat or cool the
interior more quickly, or to keep out
smoke and dust. Leaving the system
in the recirculation mode with the
A/C off can cause the windows to fog up. Switch to
mode as

soon as the interior reaches a
comfortable temperature or the
outside smoky, dusty condition

clears.
The engine must be running for the
heater and air conditioning to pro-
vide hot and cold air. The heater uses engine coolant to warm the air.If the engine is cold, it will be several
minutes before you feel warm air
circulating.
The air conditioning system does not depend on engine temperature. It
can produce cold air almost immedi-

ately.

Controlling Air Flow Direction
Air flows into the interior at three
levels: Toward the floor

through the dash vents and
toward the windshield and side
windows You select the air
flow level or combination of levels
with the five mode buttons.
Ventilation

Your car has a flow-through venti- lation system. Air enters the car
through vents in front of the wind-shield. It circulates through the
interior then exits through the rear side panels. This system provides
fresh air even when the car is standing still. To bring in outside air, press the button. Set the fan
at a comfortable speed.
CONTINUED

Comfort and Convenience FeaturesProCarManuals.comMain Menu Table of Contents s t

Heating and Cooling

To Cool with A/C

To operate the air conditioning system, press the air conditioning
switch. Set the fan to the desired
speed. You can also use the mode button to direct air out
of the dash and heater vents.
To cool the interior down rapidly after the car has been sitting in the

sun:

1. Start the engine. 2. Turn on the A/C by pressing the
switch.

3. Set the fan to maximum speed.
4. Open the windows partially. Select
and
When the interior reaches a com-
fortable temperature, close the

windows and set the system for

cooling as described above.
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page 40) when using the A/C in heavy
traffic or driving up long hills. If it
moves near the red zone, turn off the
air conditioning until the gauge reads normally.
To Heat

To warm the interior:
1. Start the engine. 2. Select and
3. Switch the fan to the desired
speed.

4. Adjust the warmth of the air with the temperature control lever.
Comfort and Convenience Features MODE BUTTONS
AIR CONDITIONING SWITCH
FAN CONTROL LEVER
TEMPERATURE CONTROL LEVERProCarManuals.comMain Menu Table of Contents s t
