1994 PONTIAC FIREBIRD Owners Manual

Service Station Information
Engine
(3.4L I
Engine Hood
Release
See Page 188 ---G A-
Windshield Washer
Fluid Reservoir
Oil Dipstick and
Fill Cap.
J32 (Code S) Engine)
See Page 192
Oil Dipstick and
Fill Cap
(5.7L LT1 (Code P) Engine)
See Page 192
Cold Tire Pressure
See Tire-Loading Information label on the
inside
of the rear edge of the driver’s door.
See Page 213
Fuel
Capacity 15.5 U.S. Gal. (58.7 L).
Use unleaded gas only, 87 octane or
higher for
the 3.4L L32 (Code S) engine,
91 octane or higher for the 5.7L LT1
(Code
P) engine. See Page 185
See Page 205
Battery
The Delco Freedom@ battery needs
no water.
See Page 208
Cooling system Reservoir
Check coolant at the coolant recovery tank
by using the dipstick. Add coolant at the
coolant recovery tank. The fluid should be
at or a little above the “FULL HOT’’ mark
on the dipstick when the engine is warm.
If the.engine is cool, the level should be at
“FULL COLD’’ on the dipstick.
See Page 202
Spare Tire Pressure
Compact Spare: 60 psi (420 kPa).
See Page 180
