1991 MITSUBISHI ECLIPSE service

21-338AUTOMATIC TRANSAXLE- Transfer Case Adapter Sub Assembly 4W4A33>
TRANSFER CASE ADAPTER SUB ASSEMBLY N21VlAADISASSEMBLY
AND REASSEMBLY
Disassembly steps
4**+1.Locknut
4*2. Driven bevel gear
I)4 3. Taper roller bearing
*4 ;. ;z;;r
6:Outer race
7.Outer race
8. Transfer case adapter
4e W 9. Taper roller bearing
NOTE(I) Reverse the disassembly procedures to reassemble.(2) 4e : Refer to ::Service Points of Disassembly:‘.[j &@ j Refer to Service Points of Reassembly
Non-reusable parts
140-150 Nm102-115 ft.lbs.
TEA0 604
SERVICE POINTS OF DISASSEMBLY
1. REMOVAL OF LOCK NUT
(1) Unstake the lock nut.
I IMB991013
TFAO289(2) Remove the driven bevel gear’s lock nut by using the
special tool.

AUTOMATIC TRANSAXLE - Transfer Case Adapter Sub Assembly 21-339
TFAO290
MD99881 2
MD99881 3
M D998825
I
MD99881 4
2. REMOVAL OF DRIVEN BEVEL GEAR ASSEMBLY
Using a press, remove the driven bevel gear assembly.
9. REMOVAL OF TAPER ROLLER BEARINGUsing the special tool, remove the taper roller bearing.
SERVICE POINTS OF REASSEMBLY
9. INSTALLATION OF TAPER ROLLER BEARINGUsing the collar, install the taper roller bearing.
4. SPACER SELECTION(1) First install the spacers used up to this time, and then
assemble the transfer case adapter sub-assembly.
(2) Using the special tool, measure the rotating drive
torque of the driven bevel gear and select spacer(s) so itreaches within the standard value.Standard
value: 1.0-l .7 Nm (0.72-I .23 ft.lbs.)

AUTOMATIC TRANSAXLE- Transfer Case Sub Assembly 21-341
TRANSFER CASE SUB ASSEMBLY
- DISASSEMBLY AND REASSEMBLY
NZlVJAA
Ii35-42
irn26-30 ftlbs.
Disassembly steps
1.Transfer cover
2.O-ring
r)+3.Spacer4.Outer race
5. Drive bevel gear shaft
6.Outer race
**7.Spacer
I)+ 8. Oil seal9.Transfer case
10. Drive bevel gear
~~ e+ 11. Taper roller bearing~~ e+ 12. Taper roller bearing
TFA0603
NOTE(1) Reverse the disassembly procedures to reassemble.(2) +e : Refer to “Service Points of Disassembly”.(3) ~~ : Refer to “Service Points of Reassembly”.(4) m : Non-reusable parts

21-342AUTOMATIC TRANSAXLE -Transfer Case Sub Assembly
MD99891 2\
MD998827.
MD998812
MD998818
TFA0302
SERVICE POINTS OF DISASSEMBLY11./12. REMOVAL
OF TAPER ROLLER BEARINGSriUsing the special tool, remove the taper roller bearing.
-I
SERVICE POINTS OF REASSEMBLY
12./l 1. INSTALLATION OF TAPER ROLLER BEARINGSUsing the special tool, install the taper roller bearing.
r,
8. INSTALLATION OF OIL SEALUsing the special tool, install the oil seal.

22-l-.
WHEELS
AND TIRES
CONTENTSNZZAA-
SERVICE ADJUSTMENT PROCEDURES.......4TROUBLESHOOTING......................................3
Tire
InflationPressureCheck......................4Bald Spots
TireWearCheck..........................................4Cracked Treads
Wheel
RunoutCheck...................................4Feathered Edge
SPECIFICATIONSRapid Wear at Center.............................................2
General
Specifications..................................2Rapid Wear at Shoulders
ServiceSpecificationsScalloped Wear...................................2Wear on One Side
7TorqueSpecifications...................................2
WHEEL AND TIRE..........................................5

5 22-2WHEELS AND TIRES - Specifications
SPECIFICATIONS
GENERAL SPECIFICATIONSN22CA- @NVehicles with
~eDhL”~~HWCthEngineVehicles withVehicles withItems1.8L Engine2.0L DOHC Engine 2.0L DOHC Engine-FWD-AWD
Wheel
Tire sizePI 85/70R14P205155Rl6 89HP205/55R16 89VP205/55R 16 89VP205155R16 89V205/55R 16 88V205/55R16 88V
205/55R16 88V
Wheel typeSteel typeSteel/Aluminium type Aluminium typeAluminium type
Wheel size14 x 5’/2JJ16 x 6JJ16 x 6JJ16 x 6JJAmount of wheel offset
mm (in.) 46 (1.8)
46 (1.8)46 (1.8)46 (1.8)
Tire inflation pressure
kPa (psi)
Front200 (29)
200 (29)200 (29)220 (32)
Rear180 (26)180 (26)180 (26)200 (29)
Spare wheel
Tire size
T125/70D15T125/70D15T125/90D16
T125/80D16*
Wheel size
4T x 154T x 154T x 16
4T x 16”Amount of wheel offset
mm (in.) 46 (1.8)
46 (1.8)46 (1.8)
Tire inflation pressure
kPa (psi) 420 (60)420 (60)420 (60)
NOTE*:
SERVICE SPECIFICATIONS
I 1terns
LimitWheel
runout
Radialmm (in.)
Lateralmm (in.)
Tread depth of tiremm (in.)
Specifications2.0
(.08)2.0
i.08)1.6 l.06)
TORQUE SPECIFICATIONSNz2cG-
ItemsNm
Hub nuts120-140ftlbs.87-101

22-4WHEELS AND TIRES - Service Adjustment Procedures
Wear indicator
53r510
/ Lateral 11Y602
SERVICE ADJUSTMENT PROCEDURES
TIRE INFLATION PRESSURE CHECKN2ZFOACCheck the inflation pressure of the tires. If it is not within the
standard value, make the necessary adjustment.
TIRE WEAR CHECKN2zFsABMeasure the tread depth of tires.Limit:
1.6 mm (.06 in,)If the remaining tread depth is less than the limit, replace the
tire.
NOTEWhen the tread depth of tires is reduced to 1.6 mm
(.06 in.) or
less, wear indicators will appear.
WHEEL RUNOUT CHECKNZ2FCA5Jack up the vehicle so that the wheels are clear of the floor.
While slowly turning the wheel, measure wheel
runout with a
dial indicator.Limit:
Radial2.0 mm (.08 in.)
Lateral2.0 mm (.08 in.)If wheel
runout exceeds the limit, replace the wheel.

WHEELS AND TIRES - Wheel and Tire22-5
WHEEL AND TIRE
- REMOVAL AND INSTALLATIONSteel typeAluminium type
120-140 Nm87-101 ft.lbs.
1 lA0267
Removal steps
1. Wheel cover 2. Center cover
I)+ 3. Hub nuts4. Center cap
5. Spring
6. Ornament
7. Balance weight
8. Tire
9. WheelNUGA-
120-140 Nm87-101 ftlbs.liA0334
o-140 Nm87-101 ft.lbs.
/llA0336
7
NOTE(1) Reverse the removal procedures to reinstall.(2) l 4 : Refer to “Service Points of Installation”
llAO2661 lAO265
SERVICE POINT OF INSTALLATIONNUGDABa
2. INSTALLATION OF HUB NUTS
On the high speed tire (205/55R16 88V) vehicle, the left andright tires are respectively specified. Attach the tires as
follows :Observe the wheel in the
P direction as illustrated, and the
direction characters will be found.
Attach the
(a Cl ROTATION LEFT SIDE) tire on the left
wheel, and the (ROTATION RIGHT SIDE
DD) tire on the
right wheel.
