21-316AUTOMATIC TRANSAXLEAnnulus Gear and- Transfer Drive Gear Set
SERVICE POINTS OF REASSEMBLY4. INSTALLATION OF BEARING
L:Using the special tool, install the bearing on the output
*h-
flange.MD998813
TFAO502
TFA0503
MD99881 2
MD998824
TFA03843. INSTALLATION OF TRANSFER DRIVE GEAR
Using the special tool, install the transfer drive gear in
proper direction. The direction can be identified by the
groove provided in one of the pinion side surfaces.
Caution
Replace the output flange and transfer drive gear as a
set.2. INSTALLATION OF BEARING
Using the special tool, install the bearing on the output
flange.@%1. SELECTION OF SNAP RING
Select a snap ring, which should be the thickest one that
can be installed in groove.
Standard value:
O-0.06 mm (O-.0024 in.)
170120

AUTOMATIC TRANSAXLEAnnulus Gear and- Transfer Drive Gear Set 44A33.W4A33>21-317
ANNULUS GEAR AND TRANSFER DRIVE GEAR SET
- DISASSEMBLY AND REASSEMBLY
Disassembly steps
l *1. Snap ring2.
Stopperplate
4eI)+ 3. Bearing
l W 4. Bearing
We+ 5. Transferdrive gear
6. Snar, rina
7.
Outbut frange
8. Annulus gear
NOTE(I) Reverse the disassembly procedures to reassemble.(2) +e : Refer to “Service Points of Disassembly”.(3) ++ : Refer to “Service Points of Reassembly”.
TFA0225
SERVICE POINTS OF DISASSEMBLY
3.14. REMOVAL OF BEARINGW5. TRANSFER DRIVE
GEAR(1) Using the special tool, remove the transfer drive gear
and bearings (2) as a set from the output flange.Caution
Install the special tool securely between the outputflange
and bearings.
) Using the special tool, remove the bearings on both
ends of the transfer drive gear.

21-318AUTOMATIC TRANSAXLE - EEtC EELCar set
TFA0226r
SERVICE POINTS OF REASSEMBLY
5. INSTALLATION OF TRANSFER DRIVE GEAW4.13. A,
BEARINGSL-1(1) Using the special tool, press-fit the bearings on both
ends of the transfer drive gear.
(2) Using the special tool, install the transfer drive gear on
the output flange.
1. SELECTION OF SNAP RING
Measure the snap ring groove, select and install a spacer sothe end play reaches the standard value.Standard value:
O-0.09 mm (O-.0035 in.)

AUTOMATIC TRANSAXLE - Differential
DIFFERENTIAL
- DISASSEMBLY AND REASSEMBLYNZlLNAF
1
k
130-140 Nm34-101 ft.lbs.
TWO263Disassembly stepsl 1. Bolt
2. Differential drive gear
4e e4 3. Ball bearing +e l a4. Taper roller bearing *ee+ 5. Lock pinl + 6. Pinion shaft
l + 7. Pinionl 8. Washer
e+ 9. Sidegearl + 10. SpacerIl. Differential case
$?everse the disassembly procedures to reassemble.(2) +e : Refer to “Service Points of Disassembly”.(3) l + : Refer to “Service Points of Reassembly”.
SERVICE POINTS OF DISASSEMBLY
3. REMOVAL OF BALL BEARINGUsing the special tool, remove the ball bearing.

21-320AUTOMATIC TRANSAXLE - Differential
TFA0231
Pinion, shaftPinion gear/
4. REMOVAL OF TAPER ROLLER BEARINGUsing the special tool, remove the taper roller bearing.
L+
5. REMOVAL OF LOCK PINUsing a pin punch, drive out the lock pin.
NOTESometimes the lock pin is removed with a light punch.
(F4A33)
SERVICE POINTS OF REASSEMBLY
10. INSTALLATION OFSPACER/S. SIDEGEAR/8.WASHERI7.
PINION/G. PINION SHAFT(1) First assemble the spacer on the rear of the side gear
&aand then assemble the gear in the differential case.
.--(2) Assemble the washer on the rear of the pinion, and
position in the designated place by rotating the two sidegears at the same time so they mesh.
(3) Insert the pinion shaft.
(4) Measure the backlash between the side gear and
pinion.Standard value:
0.025-0.150 mm (.OOl-.0059 in.)(5) If backlash is outside the standard value, select a
spacer, disassemble the gear again, reassemble and
adjust.
NOTELd
Adjust so backlash in both side gears is the same.

21-322AUTOMATIC TRANSAXLE - speedometer Gear AssemMylKickdown Servo
SPEEDOMETER GEAR ASSEMBLY
DISASSEMBLY AND REASSEMBLYNzlLaA6+.
201076
NOTE(1) Reverse the disassembly procedures to reassemble.(2) l : Refer to “Service Points of Reassembly”.(3) q : Non-reusable parts
Disassembly steps
1. O-ring
l + 2. Spring pin
H 3. Speedometer driven gear
4. Oil seal
5. Sleeve
SERVICE POINTS OF REASSEMBLY
3. INSTALLATION OF SPEEDOMETER DRIVEN GEARApply gear oil sparingly to the speedometer driven gear
shaft and insert the shaft.“c,
2. INSTALLATION OF SPRING PINL_,
Install the spring pin in such a way that its slit does not facethe gear shaft.
Slit201079
KICKDOWN SERVONZlLPAE
DISASSEMBLY AND REASSEMBLY
Disassembly steps
I. O-ring2. Kickdown servo
3. D-ring
4. Seal rina
65.
Locknuj6. Kickdown servo rod
7. Kickdown servo piston1750299
NOTE(1) Reverse the disassembly procedures to reassemble.
(2) m : Non-reusable parts

21-324AUTOMATIC TRANSAXLE - Valve Body
VALVE BODY
DISASSEMBLY AND REASSEMBLYViewed from A
NZlLOAK
-0 - -
8
TFA0523
Disassembly steps
1. Manual valve
l +2. Pressure control solenoid valvel +3. Damper clutch control solenoid v l +4. Shift control solenoid valve “A”
l +5. Shift control solenoid valve “B”6. Clamp
7. Valve stopper
8. N-D control sleeve
9. N-D control valve

l + 10. Lower valve body sub assembly11. Lower separating plate12.Nut13.Jet
l + 14. Relief spring
l + 15. Steel ballH 16. Oil filterW 17. Upper valve body sub assemblyWI
18. Steel ball
H 19. Teflon balll 420.N-Delate
NOTE(1) Reverse the disassembly procedures to reassemble.(2) l 4 : Refer to “Service Points of Reassembly”.
21. Block22. Upper separating plate
23. Intermediate plate

AUTOMATIC TRANSAXLE - Valve Bodv2646
38
I24
24. Fornt end cover
25. Pressure control spring
26. Pressure control valve
27. Torque converter control spring
28. Torque converter control valve
29. Adjusting screw
30. Regulator spring
31. Regulator valve32. Shift controlspring++ 33. Stopper plate
34. Shift control plug
35. Rear clutch exhaust valve A36. Rear clutch exhaust valve B37. Rear clutch exhaust springViewed from
B
.
I40
TFA0518
38.2-314-3shiftspring39.2-3/4-3shiftvalve40. Rear end cover41. Shift control plug Bl + 42. Stopper plate43. Shift control valve
44. l-2 shift spring
45.
l-2 shift valve
46. Upper valve body
NOTE(1) Reverse the disassembly procedures to reassemble.(2) I)4 : Refer to “Service Points of Reassembly”.
