BRAKES - Wheel Speed Sensor 5-83
Front
Rear

14AO04814R0146
0R
Qfs0
0 (-Jor
L/
14AOO47
NOTEThe pole piece can become magnetized because of the
magnet built into the speed sensor, with the result that
metallic foreign material easily adheres to it. Moreover, the
pole piece may not be able to function to correctly sense
the wheel rotation speed if it is damaged.
(2) Measure the resistance between the speed sensor termi-
nals.Standard value:
0.8-1.2 kQIf. the internal resistance of the speed sensor is not within
the standard value, replace it with a new speed sensor.
(3) Check the speed sensor cable for breakage, damage or
disconnection; replace with a new one if a problem is
found.
NOTE
When checking for cable damage, remove the cable clamppart from the body and then bend and pull the cable near
the clamp to check whether or not temporary disconnec-
tion occurs.
TOOTHED ROTOR CHECKCheck whether rotor teeth are broken or deformed, and, if so,
replace the rotor.
SERVICE POINTS OF INSTALLATION
11. INSTALLATION OF REAR SPEED SENSOR BRACKET
Assemble the speed sensor and the speed sensor bracket.
NOTEThe shape is different for the left and right speed sensor
brackets. Each bracket has an identification symbol, so be
sure to note these symbols and install correctly.
R: Indicates that the bracket is for the right wheel.
L: Indicates that the bracket is for the left wheel.

5-84BRAKES - Wheel Speed Sensor Left side view
Right side
14AOO4:Left side view
Left side
14A004.fCrossmember
10. INSTALLATION OF REAR SPEED SENSOR (1) Teimn;rarily install the speed sensor to the rear axle
Caution
Be careful when handling the pole piece at the tip of
the speed sensor and the toothed edge of the rotor
so as not to damage them by striking against metal
objects.(2) Note the following points when connecting the speed
sensor cable, and secure the cable by the clip.
@I Secure the clip so that the white-painted part
(shaded in the illustration) of the speed sensor cableis not twisted.
@ Be sure that there is space (where shown in the
illustration) so that the trailing arm and speed
sensor cable do not contact, and then secure by the
clip.
Caution
Because there is the possibility of damage to the
cable during driving if the speed sensor cable and
the trailing arm come into contact, or if the speed
sensor cable is twisted, care must be taken regard-
ing this point.(3) Insert a feeler gauge into the space between the speed
sensor’s pole piece and the rotor’s toothed surface, andthen tighten the speed sensors at the position where
the clearance is the standard value.
Standard value:
0.3-0.9 mm (.012-.035 in.)
NOTECheck to be sure that there is no contact of the speed
sensor’s pole piece and the rotor’s toothed surface
when the rear hub assembly is slowly rotated one time.
If there is contact, it is probable that the rotor or the rearhub is installed incorrectly, recheck installation.
10. INSTALLATION OF REAR SPEED SENSOR Install the rear speed sensors as shown in the illustration.
Cross-section A-AParking cable
Rear
spe/edsensor12A0075
Cross-section B-B
Cross-section C-CRear speed
sensor
VA007412AOO7612AOO77

BRAKES - Wheel Speed Sensor 545
14LOl89
Cross-section A-ACross-section B-B
12R015i
5. INSTALLATION OF FRONT SPEED SENSOR BRACKET
Assemble the speed sensor and the speed sensor bracket.
NOTE(1) The shape is different for the left and right speed
sensor brackets. Each bracket has an identification
symbol, so be sure to note these symbols
ahd. install
correctly.
FR: Indicates that the bracket is for the front speed
sensor.R: Indicates that the bracket is for the right wheel.
L: Indicates that the bracket is for the left wheel.
(2) Check to be sure, when installing the speed sensor to
the bracket, that the letters “FR” are visible.
4. INSTALLATION OF FRONT SPEED SENSOR(1) Temporarily install the speed sensor to the knuckle.Caution
Be careful when handling the pole piece at the tip of
the speed sensor and the toothed edge of the rotor
so as not to damage them by striking against other
parts.(2) Note the following points when connecting the speed
sensor cable, and secure the cable by the clip.
@ Secure the cable by the clip so that the white-
painted parts of the blackened parts (in the illustra-
tion) of the speed sensor cable are within the rangeof the angles indicated by cross-section A-A and
cross-section B-B in the illustration.
@ Check to be sure that the white-painted part
(shaded in the illustration) of the speed sensor cableis not twisted.Caution
Because there is the possibility of damage to the
cable during driving if the speed sensor cable is
twisted, care must be taken regarding thispoint.
(3) Insert a feeler gauge into the space between the speed
sensor’s pole piece and the rotor’s toothed surface, and
then tighten the speed sensor at the position where theclearance is the standard value all around.Standard value:
0.3-0.9 mm (.012-.035 in.)
NOTE
If the clearance between the speed sensor’s pole pieceand the rotor’s toothed surface is not within the
standard value range, it is probable that the rotor is
incorrectly installed, recheck installation.

BRAKES - G-sensor
G-SENSOR N&OVA8
REMOVAL AND INSTALLATION
14AO595
NOTEReverse the removal procedures to reinstall.
G-sensor removal steps
1. Wiring harness connector
2. G-sensor3. G-sensor bracket
14AO194
14A0195
INSPECTION
(1)Place the sensor on a level surface, then check that there isconductance between the terminals.
(2) Slowly inclining the G-sensor in the direction of forward
vehicle travel, check that there is no conductance above a
sensor angle of 30 degrees.

BRAKES - G-sensor /Electronic Control Unit 5-87
I
14AO198(3) Slowly inclining the G-sensor in the direction of reverse
vehicle travel, check that there is no conductance above a
sensor angle of 30 degrees.
ELECTRONIC CONTROL UNIT ABS>NOSOZAEREMOVAL AND INSTALLATION
Pre-removal Operation
@Removal of the Quarter Trim (R.H.)(Refer to GROUP 23-Trim.)IPost-installation Operation
4*Installation of the
Quarter TrimI1 (RIt?.) (Refer to GROUP 23-Trim.)1
14AO584
Removal steps
4*1. Electronic control unit connection
l +2. Electronic control unit3. Bracket
NOTE(I) Reverse the removal procedures to reinstall.(2) 4e : Refer to “Service Points of Removal”.(3) l + : Refer to “Service Points of Installation”.
SERVICE POINTS OF REMOVAL
1. DISCONNECTION OF ELECTRONIC CONTROL UNIT
Unlock the connector and take the connector out.
