1991 LEXUS SC400 ECO mode

CIRCUIT DESCRIPTION (Cont'd)
DIAGNOSIS TROUBLE CODE DETECTION DRIVING PATTERN
Purpose of the driving pattern.
(a) To simulate diag. trouble code detecting condition after diag. trouble co\
de is recorded.
(b) To check that the malfunction is corrected when the repair is completed co\
nfirming that diag. trouble codeis no longer detected.
Malfunction: Open in EGR gas temp. sensor circuit
Disconnect the EFI fuse (15 A) for 10 sec. or more, with IG switch OFF\
.
Initiate test mode (Connect terminal TE2 and E1 of check connector or TDCL with\
IG
switch OFF).
Start the engine and warm up.
After the engine is warmed up, let it idle for 3 min.
With the A/C ON and transmission in 5th gear (ECT in 3rd speed) drive at 5\
5 ~ 60 mph
(88 ~ 96 km/h) for 4 min or less.
HINT: If a malfunction exists, the ºCHECKº engine warning light will l\
ight up during step .
NOTICE: If the conditions in this test are not strictly followed, detection of \
the malfunction will not be possible.
±
ENGINE TROUBLESHOOTING Circuit InspectionTR±105
WhereEverybodyKnowsYourName

CIRCUIT DESCRIPTION (Cont'd)
DIAGNOSIS CODE DETECTION DRIVING PATTERN
Purpose of the driving pattern.
(a) To simulate diag. code detecting condition after diag. code is recorded.
(b) To check that the malfunction is corrected when the repair is completed c\
onfirming that diag. code is nolonger detected.

Initiate test mode (See page TR±12).
Start engine and warm up.
After engine is warmed up, let it idle for 3 min.
With the A/C ON and transmission in D range (O/D OFF), drive at 40±\
70 mph for 4 min.
HINT: If a malfunction exists, the ºCHECKº engine warning light will light up at 1±4 min. of driving at 40±70 mph (64±112 km/h).
NOTICE: If the conditions in this test are not strictly followed, detection of the\
malfunction will not be possible.
Malfunction: Open in EGR gas temp. sensor circuit
±
ENGINE TROUBLESHOOTING Circuit InspectionTR±109
WhereEverybodyKnowsYourName

Neutral Start Switch Circuit
CIRCUIT DESCRIPTION
The neutral start switch goes on when the shift lever is in the N or P shif\
t position. When it goes on the terminal
NSW of the ECU is grounded to body ground via the starter relay and theft deterrent ECU\
, thus the terminal
NSW voltage becomes 0V. When the shift lever is in the D, 2, L or R position, the neutral start\
switch goes off,
so the voltage of ECU terminal NSW becomes battery voltage, the voltage of the ECU internal power source.
If the shift lever is moved from the N range to the D range, this signal\
is used for air±fuel ratio correction and
for idle speed control (estimated control), etc.
When the neutral start switch is off, code º51º is output in the test mode diagnosis. (This is not a\
bnormal.)
DIAGNOSTIC CHARTDIAGNOSTIC CHART
HINT: This diagnosis chart is based on premise that the engine is cranked norm\
ally. If the engine is notcranked, proceed to the matrix chart of problem symptoms on page TR±35.
Check output condition of diag. code 51.
Proceed to next circuit inspection shown
on matrix chart (See page TR±35).
Check for open in harness and connector
between neutral start switch and ECU.
Repair or replace harness or connector.
Check and replace ECU.
Check and replace ECU.
Replace neutral start switch.Check neutral start switch (See page
AT±100 ).
TR±122
±
ENGINE TROUBLESHOOTING Circuit Inspection
WhereEverybodyKnowsYourName

AIR CONDITIONING EVAPORATOR ODOR ± AC001±97 September 12, 1997
General1. Preparation of freshener solution:
Procedure (a) Invert freshener container and shake vigorously for 30 seconds.
(b) Mix 3.4 fl. oz. of freshener (1 container) with 30 fl. oz. to make 1 q\
t. of solution.
2. Drying the evaporator: Dry the evaporator for 10 minutes with the following settings:
A/C: Off
. . . . . . . . . . .
Air Outlet: Foot
. . . . . .
Mode: Recirc.
. . . . . . . . . .
Blower: High
. . . . . . . .
Te m p : Max Warm
. . . . . . . . . .
3. Evaporator Treatment Preparation: (a) Ensure availability of 30±45 psi compressed air to be used with spray\
gun for application of freshener.
(b) Place a tray under the evaporator housing drain hose to collect used cle\
aning solution.
(c) Place shop cloth under the evaporator housing in the vehicle to prevent \
cleaning solution from dripping onto the floor mat.
4. Vehicle Preparation: See specific model section.
5. Evaporator treatment: (a) Set HVAC mode as follows: A/C: Off
. . . . . . . . . . .
Air Outlet: Face
. . . . . .
Mode: Fresh
. . . . . . . . . .
Blower: High
. . . . . . . .
Te m p : Max Warm
. . . . . . . . . .
Windows: Open
. . . . . .
(b) Insert spray nozzle into the filter inlet and spray the entire quantity (1 qt.) of
freshener solution into the evaporator
while moving the nozzle around to
cover the complete evaporator surface.
(c) Turn the blower OFF.
6. Reinstallation of Parts.
7. Completion of Treatment. (a) Dry the evaporator for 30 minutes with the following settings:
A/C: Off
. . . . . . . . . . .
Air Outlet: Foot
. . . . . .
Mode: Recirc.
. . . . . . . . . .
Blower: High
. . . . . . . .
Te m p : Max Warm
. . . . . . . . . .
Windows: Closed
. . . . . .
(b) If the vehicle still has alcohol smell, open windows for ventilation. Do not turn on
the AC switch until the evaporator is
completely dry as this can reduce the
effectiveness of the solution.
Page 2 of 11
CAUTION
Do not get into the vehicle during
this drying operation.
WhereEverybodyKnowsYourName

DATE:NOVEMBER 29, 1996
TitleALTERNATE REFRIGERANTS AND A/C RETROFITPage 1 of 2
Effective January 1, 1996, the E.P.A. has officially banned the manufacture of Refrigerant 12 (Freon).
As a result, surplus supplies of R±12 will begin to dwindle over the ne\
xt several years until, eventually,
R±12 will no longer be available.
This uncertainty about the availability of R±12 has caused significant concerns for Lexus dealers when
servicing HVAC systems not using R±134a refrigerant. Similarly, the reduced availability of R±12 has
prompted demands for R±134a retrofit kits and/or alternate refrigerants. Thi\
s TSB will clarify Lexus's
current recommendations for servicing and retrofitting HVAC systems on Lexus vehicles using R±12
refrigerant.
ALTERNATE REFRIGERANTS:
Previously, the E.P.A. has endorsed other alternative refrigerants. These endorsements, combin\
ed with
the uncertain future availability of R±12, have lead to a limited accept\
ance of using alternative refrigerants
when servicing or retrofitting R±12 HVAC systems. Use of these refrigerants can lead to several service
related problems, including:
Poor system performance and leak detection capabilities.
Contamination of R±12 and R±134a during refrigerant recovery and r\
ecycling.
Recently the E.P.A. released a statement clarifying that approval of alternative refrige\
rants relates only
to the toxicology, flammability, ozone depletion and global warming characteristics. The approval does
not imply acceptability of alternative refrigerants use with respect to serviceability or performance.
TOYOTA MOTOR SALES, U.S.A. ENDORSES THE USE OF R±134a AS THE ONLY ACCEPTABLE ALTERNATIVE REFRIGERANT FOR VEHICLES USING R±12.
R±12 AVAILABILITY:
It is estimated that existing R±12 supplies will meet market demand i\
n 1996. Beyond that, Lexus will
supply R±12 to it's dealers from a strategic reserve. These strategic reserves are alloca\
ted specifically
for distribution to Lexus dealers for repair of their customers' R±12 H\
VAC systems. TMS projects these
reserves may meet dealer demand through early 1998. After that, we believe R±12 will no longer be re\
adi-
ly available and dealers will begin to retrofit customer vehicles with R\
±134a.
REF: HEATING & AIR CONDITIONING
NO:AC007±96
MODEL:ALL MODELS
WhereEverybodyKnowsYourName

ALTERNATE REFRIGERANTS AND A/C RETROFITPage 2 of 2
RETROFIT ISSUES:
Lexus has completed development of retrofit parts for all later model Le\
xus vehicles using R±12 refrigerant.
These parts will be produced in harmony with market demand, based on R±12 \
availability.
The parts necessary for a typical retrofit will generally include:Receiver Dryer
O±Rings
Fittings
Labels
Oil
A TSIB outlining retrofit procedures will be released when the retrofit \
kits become available.
For additional information, contact the Environmental Assistance Network\
Hotline at 1±800±542±3914.
WhereEverybodyKnowsYourName

ALTERNATIVE REFRIGERANTSPage 1 of 1
Beginning with the Montreal Protocol signed in April 1988, auto manufacturers wor\
ld±wide
committed to phase±out the use of ozone damaging Refrigerant R±12,\
also known as Freon.
All automobile manufacturers are re±designing new production vehicles\
to use non-ozone depleting
R±134a which is the only
universally approved replacement refrigerant for R±12.
All 1994 and newer Lexus use R±134a.
Several independent companies have begun marketing alternative refrigerants whi\
ch they claim can
replace R±12 when servicing vehicles in the dealership. These R±12 repla\
cements commonly
referred to as blends or hydrocarbon based refrigerants, have the potent\
ial to cause damage to
Lexus AC systems and in some cases can cause personal injury to the serv\
ice technician or the
end±user. Lexus strongly discourages the use of these refrigerants in Lexus vehicl\
es.
Furthermore, dealer technicians should be cautious of vehicles that may be labeled o\
r otherwise
identified to contain such refrigerants. Servicing these vehicles can contaminate your AC
refrigerant recovery equipment causing refrigerant stored in the recovery machine to be rendered
unusable. Also, if the contaminated refrigerant equipment is then used on subseq\
uent repairs, the
dealer may unknowingly contaminate other owner's vehicles.
For all Lexus models and years that are designed to operate on R±12, \
continue to service with
R±12 as long as it is available which is expected to be two or more years. When research is
complete and R±12 becomes difficult to acquire, Lexus will provide parts and procedures to properly
retrofit an R±12 vehicle to non±ozone depleting R±134a.
HEATING & AIR
CONDITIONING
AC94±001
MARCH 25, 1994
ALL MODELS
WhereEverybodyKnowsYourName

DATE:NOVEMBER 29, 1996
TitleALTERNATE REFRIGERANTS AND A/C RETROFITPage 1 of 2
Effective January 1, 1996, the E.P.A. has officially banned the manufacture of Refrigerant 12 (Freon).
As a result, surplus supplies of R±12 will begin to dwindle over the ne\
xt several years until, eventually,
R±12 will no longer be available.
This uncertainty about the availability of R±12 has caused significant concerns for Lexus dealers when
servicing HVAC systems not using R±134a refrigerant. Similarly, the reduced availability of R±12 has
prompted demands for R±134a retrofit kits and/or alternate refrigerants. Thi\
s TSB will clarify Lexus's
current recommendations for servicing and retrofitting HVAC systems on Lexus vehicles using R±12
refrigerant.
ALTERNATE REFRIGERANTS:
Previously, the E.P.A. has endorsed other alternative refrigerants. These endorsements, combin\
ed with
the uncertain future availability of R±12, have lead to a limited accept\
ance of using alternative refrigerants
when servicing or retrofitting R±12 HVAC systems. Use of these refrigerants can lead to several service
related problems, including:
Poor system performance and leak detection capabilities.
Contamination of R±12 and R±134a during refrigerant recovery and r\
ecycling.
Recently the E.P.A. released a statement clarifying that approval of alternative refrige\
rants relates only
to the toxicology, flammability, ozone depletion and global warming characteristics. The approval does
not imply acceptability of alternative refrigerants use with respect to serviceability or performance.
TOYOTA MOTOR SALES, U.S.A. ENDORSES THE USE OF R±134a AS THE ONLY ACCEPTABLE ALTERNATIVE REFRIGERANT FOR VEHICLES USING R±12.
R±12 AVAILABILITY:
It is estimated that existing R±12 supplies will meet market demand i\
n 1996. Beyond that, Lexus will
supply R±12 to it's dealers from a strategic reserve. These strategic reserves are alloca\
ted specifically
for distribution to Lexus dealers for repair of their customers' R±12 H\
VAC systems. TMS projects these
reserves may meet dealer demand through early 1998. After that, we believe R±12 will no longer be re\
adi-
ly available and dealers will begin to retrofit customer vehicles with R\
±134a.
REF: HEATING & AIR CONDITIONING
NO:AC007±96
MODEL:ALL MODELS
