1991 HONDA CIVIC Owners Manual

The COMPACT spare tire has a
much shorter tread fife than regu-
lar tires. Replace the tire as soon
as tread wear indicators appear
as solid bands across the tread. Replace with a tire of exactly the
same size and construction. TREAD
WEARINDICATOR INDICATOR
LOCATIONMARK
The COMPACT spare tire and wheel set was designed espe- cially for your car; do not use it on any other vehicle; do not in-stall any other tire on this wheel which is not identical to the
original in size and construction, and do not use the COMPACT
spare tire on any other wheel.
Because the COMPACT spare is smaller in size and higher in air
pressure than a regular tire, it will ride more harshly with less
ground clearance and may have less traction on some road
surfaces. Drive cautiously.ProCarManuals.comMain Menu s t

Changing a Flat Tire
Do not attempt to change a tire unless the car is on firm, level
ground and well out of the flow of traffic.
Park the car on a firm, level surface, apply the parking brake, turn
on the hazard warning switch and put the transmission in gear (Park

for automatic).

1. Remove the jack, lug wrench/jack handle and jack handle extension (in the tool bag) from the location shown.

NOTE:

To remove the jack, release its tension against the mount by turning

the screw counterclockwise.

JACK TOOL BAG
Follow tire changing preparations and procedures carefully to reduce the possibility of injury. The jack is designed for changing
tires only. STAND CLEAR, DO NOT get under the car and DO NOT run the engine when the car is supported only by the jack.
5. Place the jack under the jack point nearest the wheel you are removing; align the jack head so the car frame will fit in the recess
as you raise the jack.

Hatchback

SPARE TIRE COVER
Sedan

TOOL BAG SPARE TIRE COVER
JACK
COMPACT SPARE COMPACT SPARE
2. Remove the spare tire.
3. Place blocks in front and back of the wheel diagonally opposite the tire you are changing.
4. Use the lug wrench/jack handle to loosen the wheel lug nuts counterclockwise one-half turn.ProCarManuals.comMain Menu s t

To reduce the possibility of injury, be sure to use the jack provided
with the car and the correct jacking points; never use any otherpart of the car for jack support.
6. Set the jack handle extension in the connector on the end of the jack and install the lug wrench/jack handle. Turn the lug wrench/
jack handle clockwise until the tire is slightly off the ground.
JACK HANDLE EXTENSION
LUG WRENCH/JACK HANDLE
7. Remove the center cap by turning
the lock to 90°.
(Center cap: EX Sedan)
8. Remove the lug nuts, wheel cover and wheel.
(Wheel cover: Si/DX Hatchback
and LX/EX Sedan)
(cont'd)

VALVE

LUG NUTS
WHEEL COVERProCarManuals.comMain Menu s t

Changing a Flat Tire (cont'd)
9. Everytime you install the wheel on the brake hub, use a rag to
wipe any dirt off the mounting surface of the hub and the wheel.
This will assure a tight, even contact between the wheel and hub.
10. Install the spare, and lug nuts hand tight.
TIGHTENING TORQUE
110 N.m(11 kg-m,80 Ib-ft)

11. Lower the car, remove the jack, then tighten the lug nuts securely in an "X" pattern as shown.
12. Tighten the lug nuts to the recommended torque is:
110 N.m (11 kg-m,80 Ib-ft)

If a torque wrench was not used, ask an authorized Honda
dealer to verify the torque as soon as possible.
ProCarManuals.comMain Menu s t

13. Repair or replace the damaged tire as soon as you can, reinstall
it in its original position, then put the spare back in the car.

CAUTION:

Always stow the jack, tools and tire securely to prevent them
from becoming dangerous projectiles in an accident.
14. Secure the tire and the spacer as shown in the illustration.
COMPACT SPARE DAMAGED TIRE

SPACERProCarManuals.comMain Menu s t

Jump Starting

To start a car with a dead battery, use another battery of the samevoltage, and the proper jumper cables.
Procedures other than those below could cause injury or
damage from battery acid spray, explosion or charging system

overload.

Never connect the jumper cable directly to the negative post of
the "dead" battery.
Never allow the two cars to touch each other. Never allow the jumper cable clamps to touch each other.
Never lean over the battery when making connections.
Never attempt to jump start a vehicle with a frozen battery. The
battery could rupture and explode. If you suspect a frozenbattery, remove the vent caps and check the fluid. If there
seems to be no fluid, or if you see ice, do not attempt a jump
start until the fluid thaws.

CAUTION:

If jumper cables are connected backwards, the car's main fuse
may blow.
1.Turn off all lights, heater and other electrical loads, set parking brake, and shift the transmission to Neutral or Park.
2. Use one cable to connect the positive terminal of the booster
battery to the positive terminal of the "dead" battery.

3. Use the other cable to connect
the negative terminal of the

booster battery to the engine at
the ground cable as shown.
4. To remove the cables, reverse the above procedures exactly.
DO NOT push or tow a car to start
it. The forward surge when the en- gine starts could cause a collision.
Also, under some conditions, the catalytic converter could be dam- aged. A car equipped with an auto-matic transmission cannot be
started by pushing or towing.
DEAD

BATTERY
Negative to the
engine at the

ground cable, not

to the battery

Do not attach

cable here
Positive to

positive
BOOSTER

BATTERYProCarManuals.comMain Menu s t

If towing is necessary, contact a professional towing service. Your
authorized Honda dealer can assist you with detailed towing

instructions.

Never use tow chains or rope to tow a car; your ability to safely
control the car may be adversely affected.
We recommend the following: Flat Bed Equipment —Entire car is winched on a flat bed vehicle.
This is the best way of transporting your Honda.
Wheel Lift Type—Tow with the front wheels off the ground.

If the car can only be towed with the front wheels on the ground:

make sure the transmission is full of fluid (see pages 78 — 79) and
tow with the transmission in neutral (N) and the ignition key in the 1
position.

CAUTION:

To avoid serious damage on automatic transmission cars, first
start the engine and shift to D4, then to N and shut the engine off. If the engine does not run or the transmission cannot be shifted
while the engine is running, the car must be transported on flat
bed equipment.
Check local regulations for towing.

CAUTION:
Do not exceed 35 mph (55 km/h) or tow for distances of more
than 50 miles (80 km).
If a sling type tow is used, the tow truck driver should position
wood spacer blocks between your car's frame and the chains
and lift straps to avoid damaging the bumper and the body. Do not use the bumpers to lift the car or to support the car's
weight while towing. TowingProCarManuals.comMain Menu s t

If Your Car Gets Stuck
If your car gets stuck in sand, mud, or snow, call a professional
towing service for assistance in getting your car out.
CAUTION: Do not rev up the engine and allow the wheels to spin freely at
high speed. Severe transmission damage may result if the wheels are allowed to spin for more than a few seconds.DO NOT try to free a car with automatic transmission from
snow, etc. by rocking the car alternately between forward and
reverse gears. Severe transmission damage may result from
shifting into gear with the wheels moving.ProCarManuals.comMain Menu s t
