Clear snow from underneath and
around your vehicle, particularly the
tail pipe, before starting the engine:
Running the engine when a vehicle is
stopped in deep snow is dangerous.
The exhaust pipe could be blocked by
the snow, allowing exhaust gas to
enter the cabin. Because exhaust gas
contains poisonous carbon monoxide,
it could cause loss of consciousness or
even death to occupants in the cabin.
Driving
Refueling
5-110
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Target object is thin such as wire,
rope, or poles.
Target object absorbs waves easily
such as cotton or snow.
Target object has an angular shape.Target object is tall and wide at the
upper part.
Target object height is low.There are multiple target objects.Target objects are too close to the
sensors.
Ice, snow, or mud is adhering to
the sensor area.
Heavy rainfall or pressurized water
is applied to the sensor area.
The sensor areas are frozen.You cover the sensor with your
hand.
The area around the sensor has
received a strong impact.
The vehicle is excessively tilted.Under extremely hot or cold
weather.
Approached by an object that
generates ultrasonic waves, such as
the horn of another vehicle, the
engine noise of a motorcycle, the
air brake noise of a large vehicle,
or the sensor of another vehicle.
A commercially-available fender
pole or an antenna for a radio
transmitter is installed to the
vehicle.
The vehicle is moving towards a tall
or square curbstone, or a steep
grade.
The vehicle is moving towards an
uneven wall or stairs.
The vehicle is driven in a place with
low ceilings.
The vehicle is driven on bumpy
roads, inclines, gravel roads, dense
grass, or grating.
The ultrasonic sensor does not detect
target objects directly beneath the
bumper. Even if target objects which
are located at a position lower than
an ultrasonic sensor have been
detected, the ultrasonic sensor may
suddenly stop detecting as the
vehicle approaches the target object.
Front ultrasonic sensors
The following systems utilize front
ultrasonic sensors.
Pa r k i n g S e n s o r
Rear ultrasonic sensors
The following systems utilize rear
ultrasonic sensors.
Smart Brake Support (SBS) reverse
drive detection
Pa r k i n g S e n s o r
Driving
Ultrasonic Sensors
5-136
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Driving condition Instrument cluster display Active driving display indication
During travel at constant
speed
During travel under head-
way control
1. Set speed
2. Vehicle ahead indication
NOTE
While in EV mode, acceleration may be restricted and the vehicle may not be able
to be driven at the set speed.
Refer to Mazda intelligent Drive Select (Mi-Drive) on page 5-95.
If there is a structure on the road or an obstruction at a low height off the ground
in front of the vehicle, the system may recognize it as a vehicle ahead.
Acceleration and deceleration by accelerator pedal operation takes priority while
traveling at a constant speed or in headway control. When the accelerator pedal is
released, the vehicle returns to driving at a constant speed or headway control at
the set speed.
If a vehicle ahead is traveling at an extremely low speed, the system may not
detect it correctly.
While driving using the MRCC, intended engine braking is not applied even if the
selector lever is operated.
The brake lights turn on while the brakes are operating by the MRCC control.The MRCC is also turned off automatically when the vehicle power is switched
OFF.
Driving
Mazda Radar Cruise Control (MRCC)
5-168
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Driving condition Instrument cluster display Active driving display indication
During travel at constant
speed
During travel under head-
way control
1. Set speed
2. Vehicle ahead indication
NOTE
While in EV mode, acceleration may be restricted and the vehicle may not be able
to be driven at the set speed.
Refer to Mazda intelligent Drive Select (Mi-Drive) on page 5-95.
If there is a structure on the road or an obstruction at a low height off the ground
in front of the vehicle, the system may recognize it as a vehicle ahead.
Acceleration and deceleration by accelerator pedal operation takes priority while
traveling at a constant speed or in headway control. When the accelerator pedal is
released, the vehicle returns to driving at a constant speed or headway control at
the set speed.
The Forward Sensing Camera (FSC) may not be able to detect target objects
correctly, and the CTS may not operate normally.
Refer to Forward Sensing Camera (FSC) on page 5-127.
If a vehicle ahead is traveling at an extremely low speed, the system may not
detect it correctly.
While driving using the CTS, intended engine braking is not applied even if the
selector lever is operated.
The brake lights turn on while the brakes are operating by the CTS control.
Driving
Cruising & Tra ffi c Support (CTS)
5-178
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

While the cruise control is operating,
the driver is notified of the operation
condition by the screen display.
Instrument cluster
1. Set speed

Active driving display
1. Set speed
NOTE
The cruise control does not operate
when the Hill Descent Control is
operating.
While in EV mode, acceleration may
be restricted and the vehicle may not
be able to be driven at the set speed.
Refer to Mazda intelligent Drive
Select (Mi-Drive) on page 5-95.
The accelerator pedal operation
takes priority during constant speed
driving. When you release your foot
from the accelerator pedal, the
vehicle returns to constant speed
driving at the set speed.
(Vehicles with Mazda Radar Cruise
Control with Stop & Go function
(MRCC with Stop & Go function))
If the distance between vehicles
control is disabled using the Mazda
Connect, the system switches to the
cruise control. At this time, the
MRCC switch functions as the cruise
control switch.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
If the vehicle power is switched OFF
while the distance between vehicles
control is disabled, the distance
between vehicles control is enabled
automatically the next time the
vehicle power is switched ON.
The system may not be able to
maintain the set speed depending
on the road conditions such as steep
up or down slopes.
When the vehicle speed is less than
20 km/h (12 mph), the cruise
control is canceled. If you want to
use the cruise control again, reset the
cruise control.
The brake lights turn on while the
brakes are operating by the cruise
control.
The cruise control cannot be
canceled while driving in manual
shift mode (selector lever shifted
from the D to M position).
Therefore, engine braking does not
work even if you shift down to a
lower gear. If deceleration is
required, lower the set vehicle speed
or depress the brake pedal.
Changing the set vehicle speed
Changing the set vehicle speed using
the RES switch
Press the RES switch up (SET+) or
down (SET-) to the desired speed.
Press and release immediately: 1
km/h (1 mph)
Press and hold: 10 km/h (5 mph)
Driving
Cruise Control
5-227
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Winter Driving
Carry emergency gear, including tire
chains, window scraper, flares, a small
shovel, jumper cables, and a small bag
of sand or salt.
Ask an Authorized Mazda Dealer to
check the following:
Have the proper ratio of antifreeze in
the radiator.
Refer to Inspecting the Coolant on
page 9-14.
Inspect the battery and its cables.
Cold reduces battery capacity.
Use an engine oil appropriate for the
lowest ambient temperatures that
the vehicle will be driven in (page
9-18).
Inspect the ignition system for
damage and loose connections.
Use washer fluid made with
antifreeze―but do not use engine
coolant antifreeze for washer fluid
(page 9-17).
When driving on ice or in water, snow,
mud, sand, or similar hazards:
Be cautious and allow extra distance
for braking.
Avoid sudden braking and sudden
maneuvering.
Do not pump the brakes. Continue
to press down on the brake pedal.
Refer to Antilock Brake System (ABS)
on page 5-84.
If you get stuck, select a lower gear
and accelerate slowly. Do not spin
the rear wheels.
For more traction in starting on
slippery surfaces such as ice or
packed snow, use sand, rock salt,
chains, carpeting, or other nonslip
material under the rear wheels.
NOTE
Remove snow before driving. Snow
left on the windshield is dangerous
as it could obstruct vision.
Do not apply excessive force to a
window scraper when removing ice
or frozen snow on the mirror glass
and windshield.
Never use warm or hot water for
removing snow or ice from windows
and mirrors as it could result in the
glass cracking.
Drive slowly. Braking performance
can be adversely affected if snow or
ice adheres to the brake
components. If this situation occurs,
drive the vehicle slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the
brake performance returns to
normal.
Driving
Winter Driving
5-240
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

The display indicates whether
recirculate mode (
) or fresh air
mode (
) is selected.
WARNING
Do not recirculate the air in the cabin
during cold or rainy weather.
Recirculating the air in the cabin during
cold and rainy weather is dangerous as
it will cause the windows to fog up.
Your vision will be hampered, which
could lead to a serious accident.
Recirculate mode (
)
Outside air is shut off. Air within the
vehicle is recirculated. Use this
position when going through tunnels,
driving in congested traffic (high engine
exhaust areas) or when quick cooling is
desired.
Fresh air mode (
)
Outside air is allowed to enter the
cabin.
Use this mode for ventilation or
windshield defrosting.
NOTE
The recirculated air position is the
default position whenever the
ignition is switched ON, the climate
control system is on, and the outside
temperature exceeds about 73 °F
(23 ℃).
To exit the default recirculated air
position, press the air intake selector
switch to select the outside air
position.
When the air intake selector switch is
set to the outside air position and
the outside temperature exceeds
about 73 °F (23 ℃), the climate
control system may automatically
select the recirculated air position to
improve the efficiency of the climate
control system.
Mode selector switch
The desired airflow mode can be
selected.
The mode changes each time the
switch is pressed. The selected mode is
indicated on the display.
NOTE
To set the air vent to press the
windshield defroster switch.
Fan control switch
How to increase the airflow amount
Equipment to Make Cabin More Comfortable
Fully Automatic Climate Control (Front)
6-10
CX-90_8KG7-EA-22L_Edition1_new
2022-11-17 16:05:04

All of our premium programming, including Howard Stern, every NFL, MLB®, and
NBA game, NHL® games, every NASCAR® race, 24/7 talk channels dedicated to
the biggest leagues, and much more.
All SiriusXM services require a subscription, sold separately or as a package by
SiriusXM Radio Inc. (or, in Canada, SiriusXM Canada Inc.), after any trial
subscription which may be included with your vehicle purchase or lease. To
subscribe after your trial subscrip tion, call 1-877-447-0011 (U.S.A.) or
1-877-438-9677 (Canada).
CAUTION
It is prohibited to copy, decompile, disassemble, reverse engineer, hack,
manipulate, or otherwise make available any technology or software incorporated in
receivers compatible with the SiriusXM satellite radio service or that support the
SiriusXM website, the online service or any of its content. Furthermore, the AMBE
®
voice compression software included in this product is protected by intellectual
property rights including patent rights, co pyrights, and trade secrets of Digital Voice
Systems, Inc. The SiriusXM Service may include traffic, weather and other content
and emergency alert information and data. Such information and data is not for
“safety for life”, but is merely supplemental and advisory in nature and, therefore,
cannot be relied upon as safety critical. Neither SiriusXM nor Mazda is responsible
for any errors in accuracies in the SiriusXM data services or its use in applications.
The SiriusXM content is subject to change without notice.
NOTE
SiriusXM Satellite Radio Service is available in the 48 contiguous United States and
the District of Columbia. The service is not available in Alaska, Hawaii or Puerto
Rico.
HD Radio™
*
What is HD Radio™ Technology and how does it work?
HD Radio™ Technology is the digital evolution of analog AM/FM radio.
Your radio product has a special receiver which allows it to receive digital broadcasts
(where available) in addition to the analog broadcasts it already receives.
Digital broadcasts have better sound quality than analog broadcasts as digital
broadcasts provide free, crystal clear audio.
For more information, and a guide to available radio stations and programming,
please visit www.hdradio.com.
Benefits of HD Radio™ Technology
(Information)
The song title, artist name, album name will appear on the screen when available by
the radio station.
Other Equipment
Mazda Connect
7-22*Some models.
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
