2023 HYUNDAI I20 Stop and go

2-8
Vehicle information
INTERIOR OVERVIEW
The actual shape may differ from the illustration.OBC3010003R
1. Door handle ...................................................................................................................................5-15
2. Outside rearview mirror folding button .....................................................................................5-26
3. Outside rearview mirror control switch .....................................................................................5-25
4. Power window switches.............................................................................................................. 5-27
5. Power window lock button .........................................................................................................5-30
6. Bonnet release lever .................................................................................................................... 5-36
7. Headlight leveling device switch ................................................................................................ 5-47
8. Heated steering wheel switch .................................................................................................... 5-22
9. Idle Stop and Go on/off switch ................................................................................................. 6-46
10. Electronic Stability Control (ESC) switch .................................................................................6-39
11. Tire pressure monitoring system (TPMS) switch ....................................................................... 8-11
12. Fuse box ......................................................................................................................................9-42
13. Steering wheel ............................................................................................................................ 5-20
14. Seats ..............................................................................................................................................3-4
15. Instrument panel illumination control switch ............................................................................4-4

2-9
02
1. Door handle ...................................................................................................................................5-15
2. Outside rearview mirror control switch .....................................................................................5-25
3. Outside rearview mirror folding button .....................................................................................5-26
4. Power window switches.............................................................................................................. 5-27
5. Power window lock button .........................................................................................................5-30
6. Bonnet release lever .................................................................................................................... 5-36
7. Headlight leveling device switch ................................................................................................ 5-47
8. Heated steering wheel switch .................................................................................................... 5-22
9. Idle Stop and Go on/off switch ................................................................................................. 6-46
10. Electronic Stability Control(ESC) switch ..................................................................................6-39
11. Tire pressure monitoring system(TPMS) switch ........................................................................ 8-11
12. Fuse box ......................................................................................................................................9-42
13. Steering wheel ............................................................................................................................ 5-20
14. Seats ..............................................................................................................................................3-4
15. Instrument panel illumination control switch ............................................................................4-4
The actual shape may differ from the illustration.
OBC3TN011003R
„1OLQH

3-2
Safety system
IMPORTANT SAFETY PRECAUTIONS
You will find many safety precautions
and recommendations throughout this
section, and throughout this manual.
The safety precautions in this section are
among the most important.
Always wear your seat belt
A seat belt is your best protection in all
types of accidents. Air bags are designed
to supplement seat belts, not replace
them. So even though your vehicle is
equipped with air bags, ALWAYS make
sure you and your passengers wear your
seat belts, and wear them properly.
Restrain all children
All children under age 13 should ride
in your vehicle properly restrained in a
rear seat, not the front seat. Infants and
small children should be restrained in
an appropriate Child Restraint Systems.
Larger children should use a booster
seat with the lap/shoulder belt until they
can use the seat belt properly without a
booster seat.
Air bag hazards
Whilst air bags can save lives, they can
also cause serious or fatal injuries to
occupants who sit too close to them, or
who are not properly restrained. Infants,
young children, and short adults are at
the greatest risk of being injured by an
inflating air bag. Follow all instructions
and warnings in this manual.
Driver distraction
Driver distraction presents a serious and
potentially deadly danger, especially for
inexperienced drivers. Safety should be
the first concern when behind the wheel
and drivers need to be aware of the wide
array of potential distractions, such as
drowsiness, reaching for objects, eating,
personal grooming, other passengers,
and using mobile phones.
Drivers can become distracted when
they take their eyes and attention off
the road or their hands off the wheel to
focus on activities other than driving. To
reduce your risk of distraction and an
accident:

[ALWAYS set up your mobile devices
(i.e., MP3 players, phones, navigation
units, etc.) when your vehicle is parked
or safely stopped.

[ONLY use your mobile device when
allowed by laws and conditions permit
safe use.
NEVER text or email whilst driving.
Most countries have laws prohibiting
drivers from texting. Some countries
and cities also prohibit drivers from
using handheld phones.

[NEVER let the use of a mobile device
distract you from driving. You have a
responsibility to your passengers and
others on the road to always drive
safely, with your hands on the wheel
as well as your eyes and attention on
the road.

3-5
03
Safety precautions
Adjusting the seats so that you are
sitting in a safe, comfortable position
plays an important role for the safety
of the driver and passengers, along
with seat belts and air bags when in an
accident.
WARNING
Do not use a cushion that reduces
friction between the seat and the
passenger. The passenger’s hips may
slide under the lap portion of the seat
belt during an accident or a sudden
stop. Serious or fatal internal injuries
could result because the seat belt
cannot operate properly.
Air bags
You can take steps to reduce the risk
of being injured by an inflating air bag.
Sitting too close to an air bag greatly
increases the risk of injury in the event
the air bag inflates. Move your seat as
far back as possible from front air bags,
whilst still maintaining control of the
vehicle.
WARNING
To reduce the risk of serious injury or
death from an inflating air bag, take the
following precautions:

[Adjust the driver’s seat as far to the
rear as possible whilst maintaining
the ability to maintain full control of
the vehicle.

[Adjust the front passenger seat as far
to the rear as possible.

[Hold the steering wheel by the rim
with hands at the 9 o’clock and 3
o’clock positions to minimise the risk
of injuries to your hands and arms.

[NEVER place anything or anyone
between the air bag.

[Do not allow the front passenger to
place feet or legs on the dashboard
to minimise the risk of leg injuries.

3-8
Safety system
Seatback angle
OBC3030003R
To recline the seatback:
1. Lean forward slightly and lift up the
seatback lever.
2. Carefully lean back on the seat and
adjust the seatback to the position you
desire.
3. Release the lever and make sure the
seatback is locked in place. (The lever
MUST return to its original position for
the seatback to lock.)Reclining seatback
Sitting in a reclined position when the
vehicle is in motion can be dangerous.
Even when buckled up, the protections
of your restraint system (seat belts
and/or air bags) is greatly reduced by
reclining your seatback.
WARNING
NEVER ride with a reclined seatback
when the vehicle is moving.
Riding with a reclined seatback
increases your chance of serious or
fatal injuries in the event of a collision
or sudden stop.
Drivers and passengers should ALWAYS
sit well back in their seats, properly
belted, and with the seatbacks upright.
Seat belts must be snug against your
hips and chest to work properly. When
the seatback is reclined, the shoulder
belt cannot do its job because it will not
be snug against your chest. Instead, it
will be in front of you.
During an accident, you could be twined
around the seat belt, causing neck or
other injuries.
The more the seatback is reclined,
the greater chance the passenger’s
hips will slide under the lap belt or the
passenger’s neck will strike the shoulder
belt.

3-10
Safety system
Rear seats (if equipped)
The rear seatbacks can be folded to
facilitate carrying long items or to
increase the luggage capacity of the
vehicle.
WARNING

[Never allow passengers to sit on top
of the folded down seatback whilst
the vehicle is moving. This is not a
proper seating position and no seat
belts are available for use. This could
result in serious injury or death in
case of an accident or sudden stop.

[Objects carried on the folded down
seatback should not extend higher
than the top of the front seatbacks.
This could allow cargo to slide
forward and cause injury or damage
during sudden stops.
1. Set the front seatback to the upright
position and if necessary, slide the
front seat forward.
2. Lower the rear head restraints to the
lowest position (if equipped with
adjustable head restraints).
OAI3039010
3. Insert the rear lap/shoulder belt plate
into the holder on the side trim. It will
prevent the lap/shoulder belt from
interfering with the seatback when
folding.
OAC3039006TU
OAC3039007TU
4. Pull up the seatback lever and fold
the seatback toward the front of the
vehicle.
To use the rear seat, lift and push up the
seatback backward. Push the seatback
firmly until it clicks into place. Make sure
the seatback is locked in place.
When returning the rear seatbacks to
the upright position, remember to return
the rear shoulder belts to their proper
position.

3-11
03
WARNING
When you return the rear seatback to
its upright position after being folded
down:
Be careful not to damage the seat belt
webbing or buckle. Do not allow the
seat belt webbing or buckle to get
caught or pinched in the rear seat.
Ensure that the seatback is completely
locked into its upright position by
pushing on the top of the seatback.
Otherwise, in an accident or sudden
stop, the seat could fold down and
allow cargo to enter the passenger
compartment, which could result in
serious injury or death.
NOTICE

[When returning the rear seatbacks
to the upright position, remember to
return the rear shoulder belts to their
proper position.

[Routing the seat belt webbing
through the rear seat belt guides will
help keep the seat belts from being
trapped behind or under the seats.
WARNING
Cargo
Cargo should always be secured to
prevent it from being thrown about the
vehicle in a collision and causing injury
to the vehicle occupants. Do not place
objects in the rear seats, since they
cannot be properly secured and may hit
the front seat occupants in a collision.
WARNING
Cargo loading
Make sure the engine is off, the
Automatic transmission/Dual clutch
transmission is in N (Neutral) or the
Manual transmission is in R (Reverse)
or the 1st gear, and the parking brake is
securely applied whenever loading or
unloading cargo. Failure to take these
steps may allow the vehicle to move if
the shift lever is inadvertently moved to
another position.

3-19
03
SEAT BELTS
This section describes how to use the
seat belts properly. It also describes
some of the things not to do when using
seat belts.
Seat belt safety precautions
Always fasten your seat belt and make
sure all passengers have fastened their
seat belts before starting any trip.
Air bags (if equipped) are designed
to supplement the seat belt as an
additional safety device, but they are
not a substitute. Most countries require
all occupants of a vehicle to wear seat
belts.
WARNING
Seat belts must be used by ALL
passengers whenever the vehicle is
moving. Take the following precautions
when adjusting and wearing seat belts:

[ALWAYS properly restrain children
under age 13 in the rear seats.

[NEVER allow children to ride in the
front passenger seat. If a child age 13
or older must be seated in the front
seat, move the seat as far back as
possible and properly restrain them
in the seat.

[NEVER allow an infant or child to be
carried on an occupant’s lap.

[NEVER ride with the seatback
reclined when the vehicle is moving.

[Do not allow children to share a seat
or seat belt.

[Do not wear the shoulder belt under
your arm or behind your back.

[Never wear a seat belt over fragile
objects. If there is a sudden stop or
impact, the seat belt can damage it.

[Do not use the seat belt if it is
twisted. A twisted seat belt will not
protect you properly in an accident.

[Do not use a seat belt if the webbing
or hardware is damaged.
[Do not latch the seat belt into the
buckles of other seats.

[NEVER unfasten the seat belt
whilst driving. This may cause loss
of vehicle control resulting in an
accident.

[Make sure there is nothing in the
buckle interfering with the seat belt
latch mechanism. This may prevent
the seat belt from fastening securely.

[No modifications or additions
should be made by the user which
will either prevent the seat belt
adjusting devices from operating to
remove slack, or prevent the seat
belt assembly from being adjusted to
remove slack. WARNING
Damaged seat belts and seat belt
assemblies will not operate properly.
Always replace:

[Frayed, contaminated, or damaged
webbing.

[Damaged hardware.

[The entire seat belt assembly after it
has been worn in an accident, even
if damage to webbing or assembly is
not apparent.
