2022 TOYOTA PRIUS Owners Manual

6097-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
7
When trouble arises
2WD models
Location of the emergency tire puncture repair kit and tools
Jack handle
Jack
(Use of the jack: P. 6 1 3 )
Wheel nut wrench Emergency tire puncture
repair kit
Towing eyelet1
2
3
4
5

6107-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
AWD models
To w i n g e y e l e t
Jack handle
Wheel nut wrenchEmergency tire puncture
repair kit
Jack
(Use of the jack: 
P. 613)1
2
3
4
5

6117-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
7
When trouble arises
Emergency tire puncture repair kit components
Hose
Air release cap
StickerPower plug
Air pressure gauge
Compressor switch1
2
3
4
5
6

6127-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
Pull up the handle to open the
deck board.
Secure the deck board using
the grocery bag hooks.
( P. 463)
Take out the emergency t ire puncture repair kit.
2WD models: If the luggage cover (if equipped) is stowed, turn over the
tonneau cover to take out the emergency tire puncture repair ki t.
Taking out the emergency tire puncture repair kit
1
2
3
2WD modelsAWD models

6137-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
7
When trouble arises
■Taking out the jack
Unhook the tightening strap and take out the jack.
■Storing the jack
Place the jack in the same direction as the mark next to the storage
space.
2WD models AWD models
2WD modelsAWD models
WARNING
■After using the tools and jack
Before driving, make sure all the tools and jack are securely i n place in
their storage location to reduce the possibility of personal in jury during a
collision or sudden braking.

6147-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
Take out the repair kit from the plastic bag.
Remove the valve cap from the
valve of the punctured tire.
Extend the hose. Remove the
air release cap from the hose.
Attach the sticker enclosed with
the bottle on the specified loca-
tions. (See step .)
You will use the air release cap
again. Therefore keep it in a safe
place.
Connect the hose to the valve.
Screw the end of the hose clock-
wise as far as possible.
Emergency repair method
1
2
3
10
4

6157-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
7
When trouble arises
Make sure that the compressor
switch is off.
Lift the rubber stopper on the
compressor.
Remove the power plug from
the compressor.5
6
7

6167-2. Steps to take in an emergency
PRIUS_OM_OM47F01U_(U)
Connect the power plug to the
power outlet socket. (P. 468)
Connect the bottle to the com-
pressor.
As shown in the illustration, insert
the bottle securely into the com-
pressor until the upper side of the
mark on the bottle is aligned with
the upper end of the notch.
Attach the sticker provided with
the tire puncture repair kit to a
position easily seen from the
driver’s seat.
8
9
10
