2022 TOYOTA PRIUS Owners Manual

PRIUS_OM_OM47F01U_(U)
1052. Instrument cluster
2
Instrument cluster
■When disconnecting and reconnecting 12-volt battery terminals
The settings of the clock will be reset.
■ Calendar settings
●Until the calendar settings are set, the check screen is displa yed every time
the power switch is turned to ON mode.
● After the calendar information is set, it can be changed in the “Meter Cus-
tomize” settings. ( P. 153)
■ When the menu screen on the navi gation system is operated (vehicles
with 11.6-inch display)
■ Liquid crystal display
Small spots or light spots may appear on the display. This phen omenon is
characteristic of liquid crystal displays, and there is no prob lem continuing to
use the display.
■ Pop-up display
Some functions, such as the driving mode select switch and air conditioning
system, are operation-linked and display pop-up screens on the multi-infor-
mation display. If the pop-up screens of these functions are not desired, they
can be turned off in the “Meter Customize” settings. ( P. 153)
If calendar recording is interrupted due to
replacement of the 12-volt battery or 12-
volt battery discharge, etc., when the
power switch is turned to ON mode after
maintenance, the calendar settings check
screen is automatically displayed on the
multi-information display.
●
If date information is not set, the fuel
consumption record cannot be stored
correctly. When the calendar settings
check screen is displayed, make sure to
always set the settings. ( P. 151)
A pop-up display of the menu screen icon
is displayed on the multi-information dis-
play.
*
*
: The pop-up display on the navigation
system can be turned off in the “Meter
Customize” settings. ( P. 153)

106
PRIUS_OM_OM47F01U_(U)
2. Instrument cluster
WARNING
■To prevent an accident
■ Caution for use while driving
For safety, avoid operating the meter control switch while driv ing as much
as possible, and do not look continuously at the multi-informat ion display
while driving. Stop the vehicle and operate the meter control switch. Failure
to do so may cause a steering wheel operation error, resulting in an unex-
pected accident.
NOTICE
■ The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
Do not place anything or attach a sticker
in front of the instrument cluster. The item
may obscure or obstruct the display, or
could reflect off the display, possibly
causing an accident.

107
PRIUS_OM_OM47F01U_(U)
2. Instrument cluster
2
Instrument cluster
Warning lights and indicators
The warning lights and indicators inform the driver of the status
of the vehicle’s various systems.
For the purpose of explanation, t he following illustration dis-
plays all indicators and wa rning lights illuminated.

108
PRIUS_OM_OM47F01U_(U)
2. Instrument cluster
Warning lights inform the driver of malfunctions in any of the vehicle’s
systems.
Warning lights
Warning lightsPages
*1Brake system warning light (U.S.A.) P. 588
*1Brake system warning light (Canada)
(Red)P. 588
*1Brake system warning light
(Yellow)P. 588
*1Charging system warning light
P. 588
*1Low engine oil pressure warning lightP. 588
*1Malfunction indicator lamp (U.S.A.) P. 588
*1Malfunction indicator lamp (Canada)P. 588
*1SRS warning light P. 589
*1ABS warning light (U.S.A.) P. 589
*1ABS warning light (Canada)P. 589
*1Electric power steering system warning light
(Red/yellow)P. 589
*1,2PCS warning light (if equipped)
P. 589
LTA indicator (Orange) (if equipped)P. 589
*1Slip indicator light P. 590

PRIUS_OM_OM47F01U_(U)
1092. Instrument cluster
2
Instrument cluster
*1: These lights turn on when the power switch is turned to ON mode to indi-
cate that a system check is being performed. They will turn off after the
hybrid system is on, or after a few seconds. There may be a malfunction in
a system if a light does not come on, or turn off. Have the veh icle
inspected by your Toyota dealer.
*2: The light flashes or illuminates to indicate a malfunction.
*3: The light flashes to indicate a malfunction.
*1High coolant temperature warning light P. 590
*1, 3PKSB OFF indicator (if equipped)P. 590
Open door warning light P. 590
Low fuel level warning lightP. 590
Driver’s and front passenger’s seat belt
reminder light P. 591
Rear passengers’ seat belt reminder light
(U.S.A.)P. 591
Rear passengers’ seat belt reminder light
(Canada)P. 591
*1Master warning light
P. 591
*1Tire pressure warning lightP. 591
Warning lightsPages

110
PRIUS_OM_OM47F01U_(U)
2. Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
IndicatorsPages
Turn signal indicator P. 255
Headlight indicator (U.S.A.) P. 257
Tail light indicator (Canada) P. 259
Parking brake indicator (U.S.A.) P. 256
Parking brake indicator (Canada)P. 256
Headlight high beam indicator P. 259
Fog light indicator (if equipped) P. 267
Security indicator P. 96
“READY” indicatorP. 239
Shift position indicatorsP. 249
*1, 2Slip indicator light P. 416
*1, 3VSC OFF indicatorP. 417
Cruise control indicatorP. 332,
337

PRIUS_OM_OM47F01U_(U)
1112. Instrument cluster
2
Instrument cluster
Dynamic radar cruise control indicator (if
equipped)P. 321
Cruise control “SET” indicatorP. 321,
337
AFS OFF indicator (if equipped) P. 259,
591
*1, 3PCS warning light (if equipped) P. 295
*4LTA indicator (if equipped) P. 311
Steering control indicator (if equipped)P. 311
Automatic High Beam indicator (if equipped) P. 262
Heated steering wheel indicator (if equipped) P. 451
“BSM” indicator (if equipped)P. 344
Intuitive parking assist indicator (if equipped) P. 358
*1, 3PKSB OFF indicator (if equipped)P. 372
*1S-APGS indicator (if equipped) P. 385
*1“AIR BAG ON/OFF” indicator (U.S.A.) P. 49
*1“AIR BAG ON/OFF” indicator (Canada)P. 49
IndicatorsPages

112
PRIUS_OM_OM47F01U_(U)
2. Instrument cluster
*1: These lights turn on when the power switch is turned to ON mode to indi-
cate that a system check is being performed. They will turn off after the
hybrid system is on, or after a few seconds. There may be a malfunction in
a system if a light does not come on, or turn off. Have the veh icle
inspected by your Toyota dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light comes on when the system is turned off.
*4: Depending on the operating condition, the color and illuminati ng/flashing
state of the light change.
