2022 SUBARU BRZ Owners Manual

Reverse Automatic Braking (RAB) System (If Equipped)
283
Starting and Operating7
– CONTINUED –
NOTEIt may take time to display the wall and
sound warning beeps after the object
was recognized by the sonar audible
alarm.Guideline of detecting range
*: Range of detection may vary dependi
ng on the environmental condition.
Alert level
Range of detected
object
*
Distance
indicator Alarm pattern
Long proximity (object detected) 35 in (90 cm) or more Green No warning sound
Medium proximity alert (approaching
the object) 28 to 35 in (70 to 90 cm) Yellow Short beeps
Short proximity alert (approaching
closer to the object) 20 to 28 in (50 to 70 cm) Orange Rapid short beeps
Closest proximity alert (too close to
the object) 20 in (50 cm) or less Red Continuous beep
B5=B8.ERRN 23 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Reverse Automatic Braking (RAB) System (If Equipped)
284▼
Obstacle detected and alert levelLong proximity alert (object detected)
1) Green: 35 in (90 cm) or more
Medium proximity alert (approaching the
object)
1) Yellow: 28 to 35 in (70 to 90 cm)Short proximity alert (approaching the
object closer)
1) Orange: 20 to 28 in (50 to 70 cm)
Closest proximity alert (too close to the
object)
1) Red: 20 in (50 cm) or less
When an object is detected in the
reversing direction, the range of detected
object will be shown on the center infor-
mation display.
A warning alarm will sound and,
depending on the speed, either torque
control to generate engine braking or
automatic braking will be applied.■
Automatic Braking Operation
▼
Object close behind warningAutomatic braking warning
1) Warning messageIf the system determine the risk of collision
with the object. Short warning beeps or
continuous warning beeps will sound and
either strong automatic braking or torque
control will be applied to prevent collision.
1
702886
1
702887
1
702888
1
702889
1
702890
B5=B8.ERRN 24 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Reverse Automatic Braking (RAB) System (If Equipped)
285
Starting and Operating7
– CONTINUED –
At this time, a warning message is also
displayed on the combination meter
display (color TFT).Depress brake pedal warning
1) Warning messageMake sure to depress the brake pedal
once the vehicle has been stopped by
automatic braking. Until the brake pedal is
depressed, a message will be displayed
on the center information display and the
continuous beep will remain sounding.
At this time, a warning message is also
displayed on the combination meter
display (color TFT).
NOTEThe sonar audible alarm and auto-
matic braking are different in opera-
tion conditions. Therefore there are
cases in which only one of these func-
tions will activate.
▼
After the vehicle is stopped by the
systemAfter the brake pedal is depressed, the
RAB OFF indicator will illuminate and the
system will temporarily stop operating.
The RAB OFF indicator will turn off when
the select lever is shifted to a position
other than the “R” position.
The system will operate again the next
time the select lever is shifted to the “R”
position.
NOTE
The Reverse Automatic Braking
(RAB) system will be disabled in the
following situations. - When 3 seconds pass after the
vehicle is stopped
- When any door is opened
- When the RAB warning indicator
is illuminated
- When the RAB OFF indicator is
illuminated
 The Reverse Automatic Braking
(RAB) system may stop operating
temporarily in the following cases and
the RAB OFF indicator will illuminate. - Ice, snow or mud is adhered to
the sonar sensors or the rear
bumper near the sonar sensor
- Objects are too close to the rear
bumper when the select lever is set
to the “R” position
- The system detects sounds of a
similar frequency to the RAB sonar
1
702891
WARNING
Depress the brake pedal immedi-
ately after the system stops the
vehicle by automatic braking.
Depending on the conditions of the
road surface and tires, the vehicle
may not remain stopped, possibly
leading to an accident.
702810
B5=B8.ERRN 25 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Reverse Automatic Braking (RAB) System (If Equipped)
286
- When the TRAC mode and
Vehicle Stability Control (VSC)
mode are turned off
- When in TRACK mode and the
Pre-Collision Braking System has
been turned off
■
Canceling the Reverse Auto-
matic Braking (RAB) Sy stem
Operatio n
The Reverse Automatic Braking (RAB)
system can be temporarily canceled by
any of the following operation.
 While the vehicle is stopped by the
operation of automati c braking, the brake
pedal is depressed.
 While the vehicle is stopped by the
operation of automatic braking, the accel-
erator pedal is depressed.
 The accelerator pedal is depressed
continuously (In this case, limited acceler-
ation will be canceled and the vehicle will
continue reversing.)
 The select lever is shifted to a position
other than the “R” position.NOTEThe system will be canceled if the
object is no longer detected.
■
Reverse Automatic Braking
(RAB) System ON/OFF
Setting
While the select lever is shifted to the “R”
position, the below functions of the
Reverse Automatic Braking (RAB) system
can be set by operating the center infor-
mation display.1) ON setting key of automatic braking
2) OFF setting key of automatic braking
3) ON setting key of the sonar audible alarm
4) OFF setting key of the sonar audible alarmWhen the ON setting key is shown, the
corresponding setting is ON.
Touch and hold the ON setting key to turn
the setting OFF. When the OFF setting is shown, the corre-
sponding setting is OFF.
Touch and hold the OFF setting key to
turn the setting ON.
When the automatic braking are turned
OFF, the following indicator(s) will illumi-
nate.
The RAB OFF indicator will turn off when
the corresponding function is turned ON.
NOTEWhen the settings cannot be changed,
the ON/OFF setting key will be grayed
out.
Also, the following settings can be
changed by operating the center informa-
tion display.

Warning volume
 Sonar audible alarm
12
34
702892
702810
B5=B8.ERRN 26 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

Reverse Automatic Braking (RAB) System (If Equipped)
287
Starting and Operating7
Automatic Braking
For details, refer to "Car settings" P165.■
RAB Warning Indicator
If the Reverse Automatic Braking (RAB)
system malfunctions, the above indicator
illuminates on the combination meter.
Contact the nearest SUBARU dealer for
details.■
Handling of the Sonar
Sensors
The 4 sonar sensors are located in the
rear bumper. To ensure the proper opera-
tion of the Reverse Automatic Braking
(RAB) system, observe the following
precautions. 
Do not affix any stickers or other items
on the sonar sensor or the bumper
surface near the sonar sensors.
 Always keep the sonar sensor and the
rear bumper surface near the sonar
sensors clean.
 Do not modify rear bumper.
 Do not paint the bumper near the sonar
sensors.
 Do not apply high pressure water to the
sonar sensors with a high pressure car-
washing machine.
 Do not apply strong impacts to the rear
bumper near the sonar sensors. If a
sensor becomes misaligned, a system
malfunction may occur, including inability
to detect objects in the reversing direction.
If any strong impact is applied to the rear
bumper, contact a SUBARU dealer to
have the system inspected.
 Do not disassemble the sonar sensors.
NOTEIf the sonar sensors require repair or
replacement, or if the area of the rear
bumper near the sonar sensors
requires repair, paintwork or replace-
ment, contact your SUBARU dealer for
assistance.
702811
B5=B8.ERRN 2 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²
²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²²A4600BEscusenvhch07.fm 288 ページ ２０２１年７月５日　月曜日　午後５時５８分

Driving Tips8
Driving Tips
8-1. New Vehicle Break-In Driving – the First 1,000 miles (1,600 km) ......................................290
8-2. Fuel Economy Hints ................................... ........290
8-3. Engine Exhaust Gas (Carbon Monoxide) .........290
8-4. Catalytic Converter .............................................291
8-5. Periodic Inspections ...........................................292
8-6. Driving in Foreign Coun tries .............................292
8-7. Driving Tips .........................................................292
8-8. Winter Driving .....................................................293
Operation during Cold Weather ..................................293 Driving on Snowy and Icy Roads ............................... 295
Corrosion Protection ................................................... 296
Snow Tires.................................................................... 296
Tire Chains ................................................................... 297
Rocking the Vehicle..................................................... 297
8-9. Loading Your Vehicle .........................................297
Vehicle Capacity Weight ............................................. 298
GVWR and GAWR (Gross Vehicle Weight Rating
and Gross Axle Weight Rating) ................................ 299
8-10. Trailer Towing ...................................................299
B5=B8.ERRN 2 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分

New Vehicle Break-In Driving – the First 1,000 miles (1,600 km)
2908-1. New Vehicle Break-In
Driving – the First 1,000 miles(1,600 km)The performance and long life of your
vehicle are dependent on how you handle
and care for your vehicle while it is new.
Follow these instructions during the first
1,000 miles (1,600 km):
Do not race the engine. And do not
allow engine speed to exceed 4,000 rpm
except in an emergency.
 Do not drive at one constant engine or
vehicle speed for a long time, either fast or
slow.
 Avoid starting suddenly and rapid
acceleration, except in an emergency.
 Avoid hard braking, except in an emer-
gency.
The same break-in procedures should be
applied to a newly installed or overhauled
engine or when brake pads are replaced
with new ones.
8-2. Fuel Economy HintsThe following suggestions will help to
save your fuel.
 Select the proper gear position for the
speed and road conditions.
 Avoid sudden acceleration or decelera-
tion. Always accelerate gently until you
reach the desired speed. Then try to main-
tain that speed for as long as possible.
 Do not pump the accelerator and avoid
racing the engine.
 Avoid unnecessary engine idling.
 Keep the engine properly tuned.
 Keep the tires inflated to the correct
pressure shown on the tire inflation pres-
sure label, which is located on the driver’s
center pillar. Low pressure will increase
tire wear and fuel consumption.
 Use the air conditioner only when
necessary.
 Keep the front and rear wheels in
proper alignment.
 Avoid carrying unnecessary luggage or
cargo.
8-3. Engine Exhaust Gas(Carbon Monoxide)
WARNING
 Never inhale engine exhaust gas.
Engine exhaust gas contains
carbon monoxide, a colorless
and odorless gas which is
dangerous, or even lethal, if
inhaled.Always properly maintain the
engine exhaust system to prevent
engine exhaust gas from entering
the vehicle.Never run the engine in a closed
space, such as a garage, except
for the brief time needed to drive
the vehicle in or out of it. Avoid remaining in a parked
vehicle for a long time while the
engine is running. If that is
unavoidable, then use the ventila-
tion fan to force fresh air into the
vehicle.Always keep the front ventilator
inlet grille free from snow, leaves
or other obstructions to ensure
that the ventilation system
always works properly.
B5=B8.ERRN 20 ページ ２０２１年７月５日　月曜日　午後>1時>1>1分
