2020 VOLKSWAGEN T-ROC Owners Manual

observe the following steps in order to reduce the risk of serious injuries:
as soon as possible and when safe to do so. Park the vehicle at a safe distance
from moving traffic in order to carry out the wheel change.
work during the wheel change.

board or similar support for the vehicle jack.
urself when you feel confident with carrying out the procedure. If not,
seek expert assistance.

ver
to the position P or select a gear on a manual gearbox in order to reduce the risk of unintended
vehicle movement.
immediately after changing a wheel.
n the case of vehicles with a Tyre Pressure Loss Indicator, the system must be re-synchronised
immediately after a wheel changeTyre Pressure Loss Indicator
Preparations for changing a wheel
First read and observe the introductoryinformation and safety warnings
Checklist
The following actions must always be carried out in the given order in preparation for changing the
wheel

If your vehicle has a flat tyre, park the vehicle on a firm and level surface at a safe distance from
moving traffic.

Switch on the electronic parking brake Parking and manoeuvring.

DSG

Manual gearbox: select a gear.

Ask all vehicle occupants to leave the vehicle and stand at a safe distance away from moving traffic.

Switch on the hazard warning lights and set up the warning triangle In an emergency. Observe any
legal requirements.

Chock the wheel diagonally opposite the wheel being worked on with a stone, collapsible chocks or
another suitable object.

When towing a trailer: unhitch the trailer from the vehicle and park it properly .

Remove any items of luggage from the luggage compartment.

Remove the spare wheel or temporary spare wheel and the vehicle toolkit from the luggage
compartment.

Remove the hubcaps Hubcaps.

WARNING
Ignoring any of the items on this important safety checklist can lead to accidents and severe injuries.

Wheel bolts

Fig. 203 Changing a wheel: loosening the wheel bolts.

Fig. 204
First read and observe the introductoryinformation and safety warnings
Use a suitable box spanner to loosen the wheel bolts.
Slacken the wheel bolts only by approximately one turn before raising the vehicle with the vehicle
jack.
If a wheel bolt is very tight, you may be able to loosen it by pushing down the end of the spanner
carefully with your foot. Hold on to the car for support and take care not to slip.
Loosening the wheel bolts
it will go Fig. 203
-clockwise
Loosening the anti-theft wheel bolt
-theft wheel bolt out of the vehicle toolkit.
anti-theft wheel bolt as far as it will go.

-clockwise
Screwing in the anti-theft wheel bolt (wheel cover)

s with a wheel cover, the anti-theft wheel bolt must be screwed into position
Fig. 2

Tightening torque of wheel bolts
Specified tightening torque for wheel bolts for steel or alloy wheels:
Nm
If the wheel bolts are corroded and difficult to turn, they must be replaced before the tightening
torque is checked and the wheel hub threads cleaned.
Never grease or oil the wheel bolts or the threads of the wheel hub.
The tightening torque should be checked with a properly functioning torque wrench immediately
after changing a wheel.

WARNING
Incorrectly tightened wheel bolts can loosen while the vehicle is in motion and cause accidents,
serious injury, and loss of control of the vehicle.
easily.
bolts.
the wheel bolts only by approximately one turn before raising the vehicle with the vehicle
jack.
loosen while the vehicle is in motion, even if they have been tightened with the specified tightening
torque.
-on rings.
while the vehicle is in motion. The wheel bolts and the threads could be damaged if the tightening
torque is too high. Check the tightening torque regularly using a torque wrench.

WARNING
The wrong wheel bolts can loosen while the vehicle is in motion and cause accidents, serious injury,
and loss of control of the vehicle.

piece wheel bolts: use only two-piece wheel bolts.
Lifting the vehicle with the jack

Fig. 205 Jacking points.

Fig. 206 Jack fitted at the rear on the left-side of the vehicle.
First read and observe the introductoryinformation and safety warnings
The jack may be positioned only at the reinforcements on the underbody, which are located behind
the markings on the body Fig. 205
working on
Checklist
For your own safety, carry out the following points in the specified order

Choose a firm and level surface suitable for lifting the vehicle.

Switch off the engine. Select a gear on vehicles with a manual gearbox or move the selector lever to
position P on vehicles with DSG

Loosen the wheel bolts Wheel bolts.

Find the jacking point under the vehicle which is closest to the wheel that is being changed.

Insert the crank into the opening on the jack (depends on the vehicle equipment).

Crank up the jack until it just fits under the jacking point of the vehicle.

Ensure that the entire surface of the foot of the jack is resting securely on the floor, and that the
foot of the jack is positioned fully underneath the point of application and .

Position the jack and simultaneously continue to crank the claw up until it is in position around the
vertical rib underneath the vehicle .

Crank the jack further until the wheel is just clear of the ground.

WARNING
Incorrect use of the vehicle jack could cause the vehicle to slip off the jack. This could lead to severe
injuries. Observe the following points in order to reduce the risk of injuries:
jacks could slip out of position this includes vehicle jacks supplied with other Volkswagen models.
the vehicle to slip off the jack. If necessary, use a large, sturdy board or similar support for the
vehicle jack.

side member securely Fig. 206
lace any part of your body (e.g. an arm or leg) underneath the vehicle if the latter is
supported only by the vehicle jack.

cle when the engine is running, or if the vehicle is tilted to one side or on a
gradient.
cause the vehicle to fall off the vehicle jack.

WARNING
Ignoring any of the items on this important safety checklist can lead to accidents and severe injuries.

Changing a wheel

Fig. 207 Changing a wheel: removing the wheel bolts with the screwdriver handle.
First read and observe the introductoryinformation and safety warnings
Removing a wheel
Preparations for changing a wheel
Wheel bolts
Lifting the vehicle with the jack
Fig. 207
wheel bolts and place them on a clean surface.

Fitting the spare wheel or temporary spare wheel
y attention to the tyre direction of rotation Tyre lettering and tyre type

theft wheel bolt using the adapter at position Fig.
0

l the other wheel bolts in clockwise direction and tighten them slightly.

tighten the bolts in order but always in diagonally opposite sequence.
Hubcaps

WARNING
Incorrect tightening torque or incorrect use of wheel bolts can lead to a loss of control of the vehicle,
and cause accidents and serious injuries.
ep all wheel bolts and threads in the wheel hubs clean and free from oil and grease. The
wheel bolts must be easy to turn and be tightened to the specified torque.
not use
for loosening or tightening them.
After changing a wheel
First read and observe the introductoryinformation and safety warnings
luggage compartment Vehicle toolkit

Tightening torque of wheel
bolts
as possible.

After changing a wheel, the indicator lamp for the tyre monitoring system may indicate a fault in the
system T
Breakdown set
Introduction
This chapter contains information on the followingsubjects:
Contents of the breakdown set
Preparations
Sealing and inflating tyres
