2019 TOYOTA SEQUOIA Owners Manual (in English)

1293-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY■
Folding down the third
seats (manual type)
Pull the head restraint lock
release lever to fold the head
restraint.
Pull the lever to unlock the seatback and then fold the seatbac k
down.
1
2
From rear door sideFrom back door side

1303-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY■
Folding down the third
seat (power type)
Press and hold the seatback folding switch until the seatback f olds
down fully and the buzzer sounds.
The outside head restraints are folded automatically.
■ The power third seat can be folded down/returned when
Turn the engine switch to the “LOCK” position or the shift leve r is in P, with the
rear door opened (from rear door side) or back door opened (fro m back door
side).
From rear door sideFrom back door side

1313-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
■When folding the rear seatbacks down
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shi ft the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Do not depress the second seat release pedal from the third seat while the
second seat is occupied.
■ After returning the rear seatback to the upright position
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seatback.

1323-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
NOTICE
■Stowing the seat belts
The seat belts and the buckles must be stowed.
■ Second seatback board weight capacity (if equipped)
Do not place any object heavier than 220 lb. (100 kg) on the se cond seat-
back board.
■ Before sliding the second center seat to the most forward posit ion
(vehicles with bench type second seat)
Ensure that the cup holder on the front console box is closed.

1333-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
Driving position memor y
The steering wheel will automatically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have
been performed, the steering
wheel will automatically
adjusted to a position that
allows driver to enter and exit
the vehicle easily. • The shift lever has been shifted to P.
• The engine switch has been turned to the “ON” position.
• The driver’s seat belt has been unfastened.
When any of the following has be en performed, the steering wheel
will automatically return to their original positions. • The engine switch has been turned to the “ACC” or “ON” posi- tion.
• The driver’s seat belt has been fastened.
: If equipped
This feature automatically adjusts the front seats, steering wh eel
and outside rear view mirrors to make entering and exiting the
vehicle easier or to suit your preferences.
Power easy access system

1343-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
Your preferred driving position (the position of the driver’s seat, steer-
ing wheel and outside rear view mirrors) can be recorded and re called
by pressing a button.
Two different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the engine switch to “ON” position.
Adjust the driver’s seat, steerin g wheel, and outside rear view
mirrors to the desired positions.
While pressing the “SET”
button, or within 3 seconds
after the “SET” button is
pressed, press button “1” or
“2” until the buzzer sounds.
If the selected button has
already been preset, the previ-
ously recorded position will be
overwritten.
■
Recall procedure
Check that the shift lever is in P.
Turn the engine switch to “ON” position.
Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.
Driving position memory
1
2
3
4
1
2
3

1353-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
● Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).
■ Seat positions that can be memorized ( P. 120)
The adjusted positions other than the position adjusted by lumb ar support
switch can be recorded.
■ Operating the driving position m emory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be sl ightly different
when it is recalled.

1363-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
Each key can be registered to recall your preferred driving position.
■Registering procedure
Record your driving position to button “1” or “2” before perfor ming
the following:
Carry only the key you want to register, and then close the dri ver’s
door.
If 2 or more keys are in the vehicle, the driving position cann ot be
recorded properly.
Check that the shift lever is in P.
Turn the engine switch to “ON” position.
Recall the driving position that you want to record.
While pressing the recalled
button, press and hold the
door lock switch (either lock
or unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds contin-
uously for approximately 3
seconds.
■
Recall procedure
Make sure that the doors are locked before recalling the drivin g
position. Carry the key that has been registered to the driving
position, and then unlock and open the driver’s door using the
wireless remote control.
The driving position will move to the recorded position (not in cluding the
steering wheel).
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.
Turn the engine switch to the “ACC” or “ON” position, or fasten a
seat belt.
The seat and steering wheel will move to the recorded position.
Memory recall function
1
2
3
4
1
2
