2019 TOYOTA SEQUOIA Owners Manual (in English)

2974-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C013U_19MY
■Shifting between “2WD” and “4H”
●When the ambient temperature is 5.0 °F (-15 °C) or lower, shifting from
“2WD” to “4H” cannot be performed with the vehicle speed above 43 mph
(70 km/h).
● If the “4HI” indicator does not go off when you shift from “4H” to “2WD”, drive
straight ahead while accelerating or decelerating, or drive in reverse.
■ Front-wheel drive usage frequency
You should drive in front-wheel drive for at least 10 miles (16 km) each
month.
This will assure that the front drive components are lubricated .
■ The center differential lock switch can be operated when
●The front-wheel drive control switch is in the “4H” or “4L” pos ition.
● The vehicle speed is less than 62 mph (100 km/h)
■ Center differential lock system
●When the front-wheel drive control switch is in the “4L” positi on and the cen-
ter differential is locked, the VSC is automatically turned off .
● When the front-wheel drive control switch is turned to the “2WD ” position,
the center differential is automatically unlocked.
● If the operation is not completed, the center differential lock indicator blinks.
If the indicator does not go off when unlocking the center diff erential, drive
straight ahead while accelerating or decelerating, or drive in reverse.

2984-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C013U_19MY■
If the “4LO” indicator, “4HI” indicator or the center different ial lock indi-
cator blinks
● If the “4LO” indicator continues to blink when shifting between “4H” and “4L”,
stop the vehicle completely, move the shift lever to N and oper ate the switch
again.
● If the shift lever is moved before the “4LO” indicator turns on /off, the transfer
mode may not be shifted completely. The transfer mode disengage s both
the front and rear driveshafts from the powertrain and allows the vehicle to
move regardless of the shift position. (At this time, the indic ator blinks and
the buzzer sounds.)
Therefore, the vehicle is free to roll even if the automatic tr ansmission is in
P. You or someone else could be seriously injured. You must complete the
shifting of the transfer mode.
To complete the shifting, stop the vehicle completely, return t he shift lever to
N, and confirm that the shift was completed (The indicator turn s on/off).
● If the engine coolant temperature is too low, transfer mode may not be able
to shift. When the engine is warmer, turn the switch again.
If the “4LO” indicator, “4HI” i ndicator or the center different ial lock indicator
continues to blink even after attempting the above, there may b e a malfunc-
tion in the engine, the brake system or the four-wheel drive sy stem. In this
case, you may not be able to shift between “2WD” and “4H”, “4H” and “4L”,
and the center differential lock may not be operable. Have the vehicle
inspected by your Toyota dealer immediately.
■ Shifting to the “4L” position
The VSC off indicator will come on.
If the center differential is locked, VSC is automatically turn ed off.

2994-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
■Shifting the front-wheel drive control switch from “2WD” to “4H ” while
driving
Never operate the front-wheel drive control switch if the wheel s are slipping.
Stop the slipping or spinning before shifting.
■ When the vehicle is parked
If the shift lever is moved before the “4LO” indicator turns on/off, the transfer
mode may not be shifted completely. The transfer mode disengage s both
the front and rear driveshafts from the powertrain and allows the vehicle to
move regardless of the shift position. (At this time, the indicator blinks and
the buzzer sounds.)
Therefore, the vehicle is free to roll even if the automatic tr ansmission is in
P. You or someone else could be seriously injured. You must complete the
shifting of the transfer mode before placing transmission in P. ( P. 298)
NOTICE
■To prevent damage to the center differential
● For normal driving on dry and hard surface roads, unlock the center differ-
ential.
● Unlock the center differential after the wheels are out of the ditch or off the
loose or bumpy surface.
● Do not push the center differential lock switch when the vehicle is corner-
ing or when its wheels are spinning freely off the ground.

3004-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C013U_19MY
AUTO LSD system
The system can be used on 2WD models and in 2WD mode on 4WD
models.
The system is activated when driving at a speed under 62 mph
(100 km/h).
The AUTO LSD system will be activated with the following two pr oce-
dures.
■TRAC off mode
Press briefly to turn on the
system. The “AUTO LSD” indi-
cator will come on.
To turn off the system, press
again.
■
AUTO LSD mode
Stop the vehicle completely,
and press for more than 3
seconds. The “AUTO LSD” and
VSC off indicators will come on.
To turn off the system, press
again.
The AUTO LSD system aids trac tion by using the traction con-
trol system to control engine performance and braking when
one of the drive wheels begins to spin.
The system should be used only when one of the drive wheels
spinning occurs in a ditch or rough surface.
System operation

3014-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C013U_19MY
■If the engine is turned off and restarted
The AUTO LSD system and the indicators are automatically turned off.
■ Reactivation of the VSC system linked to vehicle speed
When the AUTO LSD system is turned on, the VSC and TRAC systems will
turn on automatically if vehicle speed increase.
■ If the brake system overheats
The system will cease operation and a buzzer will alert the driver. At this time,
the “TRAC OFF” indicator will come on. Stop the vehicle in a safe place.
(There is no problem with continuing normal driving.) The syste m will be auto-
matically restored after a short time.
WARNING
■ To avoid an accident
Failure to do so, a much greater steering effort and more careful cornering
control will be required.
● Do not use the AUTO LSD system in conditions other than when on e of
the drive wheels spinning occurs in a ditch or rough surface.
● Do not drive with the AUTO LSD system continuously turned on.
NOTICE
■Activating while driving
Do not activate the AUTO LSD system if the wheel is slipping. S top the slip-
ping or spinning before activating.

3024-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C013U_19MY
Driving assist systems
◆ABS (Anti-lock Brake System)
Helps to prevent wheel lock when the brakes are applied suddenl y,
or if the brakes are applied while driving on a slippery road surface
◆Brake assist
Generates an increased level of braking force after the brake p edal
is depressed when the system de tects a panic stop situation
◆VSC (Vehicle Stability Control)
Helps the driver to control skidding when swerving suddenly or
turning on slippery road surfaces
◆Trailer Sway Control
Helps the driver to control trailer sway by selectively applying brake
pressure for individual wheels and reducing driving torque when
trailer sway is detected.
◆TRAC (Traction Control)
Helps to maintain drive power and prevent the drive wheels from
spinning when starting the vehicl e or accelerating on slippery roads
◆Hill-start assist control
Helps to reduce the backward movement of the vehicle when start -
ing on an uphill
To keep driving safety and perf ormance, the following systems
operate automatically in respon se to various driving situations.
Be aware, however, that these systems are supplementary and
should not be relied upon too heav ily when operating the vehi-
cle.

3034-5. Using the driving support systems
4
Driving
SEQUOIA_OM_USA_OM0C013U_19MY
The slip indicator will flash while
the TRAC/VSC/Trailer Sway Con-
trol systems are operating.
If the vehicle gets stuck in mud, dirt or snow, the TRAC system may
reduce power from the engi ne to the wheels. Pressing
to turn the
system off may make it easier for you to rock the vehicle in or der to
free it.
2WD models and 2WD mode on 4WD models
To turn the TRAC system off,
quickly press and release
.
The “AUTO LSD” indicator light
will come on.
Press
again to turn the sys-
tem back on.
When the TRAC/VSC/Trailer Sway control systems are operating
Disabling the TRAC system

3044-5. Using the driving support systems
SEQUOIA_OM_USA_OM0C013U_19MY
“4H” mode on 4WD models
To turn the TRAC system off,
quickly press and release
.
The “TRAC OFF” indicator light
will come on.
This mode can be used when the
transfer mode is “4H” mode and
the center differ ential is unlocked.
Press
again to turn the system back on.
■Turning off TRAC, VSC and Trailer Sway Control systems
2WD models and “2WD” mode on 4WD models
To turn the TRAC, VSC and Trailer Sway Control systems off, sto p the vehicle
completely, and press and hold for more than 3 seconds when AU TO
LSD system is on. ( P. 300)
The “TRAC OFF” indicator light and the VSC off indicator light will come on
*.
Press again to turn the systems back on.
“4H” mode on 4WD models and “4L” mode on 4WD models
To turn the TRAC, VSC and Trailer Sway Control systems off, pre ss and hold
for more than 3 seconds while the vehicle is stopped.
The “TRAC OFF” indicator light and the VSC off indicator light will come on
*.
Press again to turn the systems back on.
*: Pre-collision brake assist and pre-collision braking will als o be disabled.
The pre-collision system warning light will come on and the mes sage will be
shown on the multi-information display. ( P. 234)
