2019 TOYOTA SEQUOIA Owners Manual (in English)

3375-2. Using the interior lights
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY■
Front
Turns the lights on/off
■Center
Turns the lights on/off
■Rear
Turns the lights on/off
Personal/interior lights
Ty p e AType B

3385-2. Using the interior lights
SEQUOIA_OM_USA_OM0C013U_19MY
Door position on
The interior light comes on when a
back door is opened. It turns off
when the door is closed.
Off
On
■Illuminated entry system
The lights automatically turn on/off according to the engine sw itch position,
whether the doors are locked/unlocked, and whether the doors ar e open/
closed.
■ To prevent the battery from being discharged
If the lights remain on when the door is not fully closed and the personal/inte-
rior light main switch is in door position, the lights will go off automatically
after 20 minutes.
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be c hanged.
(Customizable features: P. 516)
Interior light
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than necessary when the engin e is not
running.

3395-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
List of storage features
Overhead console ( P. 344)
Glove boxes ( P. 340)
Auxiliary boxes ( P. 350)
Bottle holders ( P. 349)
Cup holders ( P. 345)
Rear console box
(if equipped) ( P. 342) Front console box (
P. 340)
• Card holder
• Map holder
• Pen holder
• Tissue pocket
Map holder ( P. 342)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into c ontact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may r elease
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, k eep the
lids closed. In the event of sudden braking or sudden swerving, an acci-
dent may occur due to an occupant being struck by an open lid o r the
items stored inside.

3405-3. Using the storage features
SEQUOIA_OM_USA_OM0C013U_19MY
Lower glove box: The glove box light turns on when the tail lig hts are on.
Lift the lid while pulling up the
knob to release the lock.
Glove boxes
Upper glove boxLower glove box
Open (push button) Unloc k with the master key
Lock with the master key
Open (pull the lever)
Front console box

3415-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
●When using the front console box lid as
an armrest, pull the knob up and slide
the lid forward as needed.
When the lid is forward, it cannot be
lifted.
● The tray in the console box slides for-
ward/ backward.
● To remove the tray, lift up the remove
position.
● To remove the box, lift up.
● The following items can be stowed on
the backside of the console box lid.
Card holder
Map holder
Tissue holder
Pen holder

3425-3. Using the storage features
SEQUOIA_OM_USA_OM0C013U_19MY
Push the tab down to release
the lock and remove the lid.
Stow the lid.
Map holder (center console)
1
2
Rear console box (if equipped)
Upper boxLower box
Push the knob and lift the lid. P ush the knob and lift the lid.

3435-3. Using the storage features
5
Interior features
SEQUOIA_OM_USA_OM0C013U_19MY
●The separator can be used at either of
two positions, change the separator
position.
● The separator can be stowed, stow the
separator to the lid.
● When using the back side tray, open the
upper box
● The inside tray can be removed, pull the
tray up.
● When closing the rear console box lid,
close the rear console box by lifting the
grip on the inside of the upper box.

3445-3. Using the storage features
SEQUOIA_OM_USA_OM0C013U_19MY
The overhead console is useful for temporarily storing sunglass es and
similar small items.
Push the knob forward to open the
console.
WARNING
■ When opening/closing the lower box
Be careful not to get your hands or feet caught between the low er box and
the upper box.
Failure to do so may result in serious injury.
■ When opening the lower box
Make sure that the upper box is locked. Items stored inside may fall out and
cause injury.
Overhead console
