2019 MAZDA MODEL CX-9 Owners Manual (in English)

ItemFeatureFactory Set‐
ting Available Set‐
tings Settings
Change
Method
Lane-keep As‐
sist System
(LAS) & Lane
Departure Warn‐
ing System
(LDWS) (page
4-147) The system can be changed so that the steering
wheel assist does not operate.
On On/Off A ―
When the steering
wheel operation assis‐
tance is turned onThe sensitivity of the
steering assistance for
the Lane-keep Assist
System (LAS) & Lane
Departure Warning
System (LDWS) can
be changed.
High High/Low A ―
The system can be
changed so that the
lane departure warn‐
ing does not activate.
On On/Off A ―
When the steering
wheel operation assis‐
tance is turned offThe warning timing in
which the Lane-keep
Assist System (LAS)
& Lane Departure
Wa r n i n g S y s t e m
(LDWS) system deter‐
mines that the vehicle
may be deviating from
its lane can be
changed.
At At/Before A ―
The sensitivity of the
warning for the
Lane-keep Assist Sys‐
tem (LAS) & Lane
Departure Warning
System (LDWS) can
be changed.
Often Often/Rare A ―
The type of Lane-keep Assist System (LAS) &
Lane Departure Warning System (LDWS)
warning can be changed.
Vi b r a t i o n
Vibration/Beep/
Rumble. A―
The warning intensity/
volume of the
Lane-keep Assist Sys‐
tem (LAS) & Lane De‐
parture Warning Sys‐
tem (LDWS) system
can be changed. Vibration Low High/Low A ―
Rumble.
Low High/Mid/Low A ―
BeepLow High/Low A ―
Specifications
Personalization Features
9-11
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

ItemFeatureFactory Set‐
ting Available Set‐
tings Settings
Change
Method
Blind Spot Mon‐
itoring (BSM)
(page 4-114) The system can be chan
ged so that Blind Spot
Monitoring (BSM) does not operate.*1On On/Off A ―
Warning beep volume*2High High/
Low/ Off A―
Distance Recog‐
nition Support
System (DRSS)
(page 4-126) The system can be chan
ged so that Distance
Recognition Support System (DRSS) does not
operate.*1On On/Off A ―
The distance at which the vehicle ahead and
your vehicle indicated in the display flashes in
white can be changed. Near Far/Med./Near A ―
Traffic Sign
Recognition
System (TSR)
*3
(page 4-120)The Traffic Sign Recognition System (TSR)
can be set to inoperable.
*1On On/Off A ―
The warning pattern of the excessive speed
warning can be changed.
OffOff/
Vis u a l /
Audio & Visual A―
The activation timing fo
r the excessive speed
warning can be changed.00/5/10 A―
360° View Mon‐
itor (page 4-166) Setting can be changed so that the 360° view
monitor is automatically displayed when the
ignition is switched to ON.
Off On/Off A ―Setting can be changed so that the display of
the estimated forward l
ine of progress is not
displayed. On On/Off A ―
Setting can be changed so
that the top view/
front view displayed while the vehicle is mov‐
ing in the forward direc tion after reversing is
not displayed. On On/Off A ―
Parking sensor
system (page
4-225)
Display*4/non-display
On On/Off A ―
Specifications
Personalization Features
9-12
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

ItemFeatureFactory Set‐
ting Available Set‐
tings Settings
Change
Method
Ve h i c l e
Door locks
(page 3-16) Operation condition of auto lock/unlock func‐
tion Lock: When
Driving Un‐
lock: IGN Off Lock: Out of
Park Unlock: In Park/
Lock: Shifting
Out of Park/
Lock: When
Driving Unlock:
In Park/
Lock: When
Driving Unlock:
IGN Off/
Lock: When
Driving/
Off AD
Keyless entry
system (page
3-3)
Method for unlocking door using transmitter
Driver's:
Once, All
Doors: Twice All Doors:
Once/
Driver's: Once, All Doors:Tw i c e AE
Time for locking door automatically
60 seconds90 seconds/
60 seconds/
30 seconds A―
Advanced key‐
less entry system
(page 3-9) Method for unlocking door using request
switch/transmitter
Driver's:
Once, All
Doors: Twice All Doors:
Once/
Driver's: Once,
All Doors:Tw i c e A
E,
FTime for locking door automatically 60 seconds90 seconds/
60 seconds/
30 seconds A―
Auto-lock function operation/non-operational Off On/Off A ―
Beep volume when locking/unlocking
MediumHigh/
Medium/ Low/
Off A
E,
F
Specifications
Personalization Features
9-13
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

ItemFeatureFactory Set‐
ting Available Set‐
tings Settings
Change
Method
Illuminated en‐
try system (page
5-96) Time until interior lights turn off after closing
door
15 seconds60 seconds/
30 seconds/
15 seconds/
7.5 seconds A―
Time until interior lights turn off automatically
when any door is not closed completely
30 minutes60 minutes/
30 minutes/
10 minutes A―
Auto-wiper con‐
trol (page 4-74)
Operational/non-operational On or Off
On/Off*5A―
Daytime running
lights (page
4-72)Operational/non-operational On On/Off ― ―
Auto headlight
off*6 (page 4-68)
Time until headlights
turn off 30 seconds120 seconds/
90 seconds/
60 seconds/
30 seconds/
0 seconds
*7
A―
Auto-light con‐
trol (page 4-68) Timing by which lights turn on Medium High/
Med. High/ Medium/
Med. Low/ Low A―
High Beam Con‐
trol System
(HBC) (page
4-111)
Operational/non-operational
*1On On/Off A ―
Adaptive Front
Lighting System
(AFS) (page
4-110)Operational/non-operational
*1On On/Off A ―
Lights-on re‐
minder*8 (page
7-46) Warning beep volume High High/Low/Off A ―
Coming home
light (page 4-71)
Time until headlights
turn off 30 seconds 120 seconds/
90 seconds/
60 seconds/
30 seconds/ Off A―
Leaving home
light (page 4-71)
Operational/non-operational On On/Off A ―
Turn indicator
(page 4-73)Beep volume High High/Low A ―
Specifications
Personalization Features
9-14
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

ItemFeatureFactory Set‐
ting Available Set‐
tings Settings
Change
Method
Three-flash turn
signal (page
4-74) Operational/non-operational On On/Off A ―
Ambient Light‐
ing (page 5-93)
Ambient lights brightness*9MediumBright/
Medium/ Dim/
Off
*10
A―
Rear window
defogger (page
4-78) The operation time for the rear window defog‐
ger can be changed.
15 minutes15 minutes/
Continuous
*11――
System
Language Language indicated in display US EnglishDepends on
market
*12A―
Temperature Temperature unit indi cated in display °F or °C °F/°C A ―
Distance Distance unit indicated in display mi or km mi/km A ―
Fuel Economy Monitor (page 4-99)
Ending display On/off Off On/Off B ―
Fuel economy
resetting proce‐
dureLinkage/non-linkage with fuel economy reset
and trip meter reset
Off On/Off B ―
Specifications
Personalization Features
9-15
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

ItemFeatureFactory Set‐
ting Available Set‐
tings Settings
Change
Method
Active driving display (page 4-56)
Display Setting can be changed so that the Active Driv‐
ing Display is not displayed.
On On/Off C ―
The display height (up/down position) can be
changed.
013 steps up/
down from ini‐
tial setting (total: 27 steps) C―
The method for adjusting the display bright‐
ness (automatically/manually) can be changed.
Auto Auto/Man. C ―
The standard brightness with the automatic
brightness adjustment can be changed. 02 steps up/down
from initial set‐ ting (total: 5
steps) C―
The standard brightness with the manual
brightness adjustment can be changed.
020 steps up/
down from ini‐
tial setting (total: 41 steps) C―
The display angle can be changed.
03steps up/down
from initial set‐ ting (total:7steps) C―
Navigation guid‐
ance
Display/non-display On On/Off C ―
*1 Though these systems can be tur
ned Off, doing so will defeat the purpose of the system and Mazda
recommends that these systems remain On.
*2 Only the volume of the warning beep during Blind Spot Monitori ng (BSM) operation can be changed. The
volume of the warning beep durin g Rear Cross Traffic Alert (RCTA) operation cannot be changed.
*3 This system functions only when t he navigation system is functioning.*4 When the ultrasonic sensors detect an obstruction, the content s indicated on the center display switches to the
360°View Monitor. (Vehicles with 360°View Monitor)
*5 If the auto-wiper control is set to Off, the wiper lever position is set to in termittent operation.*6 If the setting is changed to O ff, the following operation is performed according to the headlight switch
position:
At position: Headlights turn off immediately after the ignition i s switched off.At any position other than : Headlights on/off conditions vary according to the headlight switch
position. Refer to Headlights on page 4-68.
*7 When set to 0 seconds, the lights-on reminder is operable.*8 The lights-on reminder settings can be changed at anytime, how ever, the lights-on reminder only operates
when the auto headlight function is set to Off. Refer to Lights-On Reminder on page 7-46.
*9 Change the ambient light illumin ation level with the parking lights or headlights turned on.*10 When set to OFF, the ambient lights remain turned off regardless of whether or not the parking lights or
headlights are on or off. However, they will turn on or off in conjunction with the illuminated entry system.
Specifications
Personalization Features
9-16
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

*11 The operation may stop in 15 minutes due to the effect of the outside temperature even if the operation time of
the rear window defogger has been changed to Continuous.
*12 Available only in display from the center display.
Specifications
Personalization Features
9-17
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27
