2019 MAZDA MODEL CX-9 Owners Manual (in English)

SignalWarning Page
(Red)
*Seat Belt Warning Light (Rear seat) 7-37
*Low Washer Fluid Level Warning Indication
7-37
Door-Ajar Warning Indication
7-37
Liftgate-Ajar Warning Indication 7-37
Door-Ajar Warning Light7-37
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If t he light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is appl ied.
▼Indication/Indicator Lights
These lights turn on or flash to
notify the user of the system operation status or a system
malfunction.
Signal Indicator Page
(Green)
*Seat Belt Indicator Light (Rear seat) 2-32
Front Passenger Air Bag Deactivation Indicator Light*12-78
Security Indicator Light*13-44
Wrench Indication
4-27
Shift Position Indication4-61
Lights-On Indication/Indicator Light 4-68
When Driving
Instrument Cluster and Display
*Some models.4-25
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

SignalIndicator Page
Headlight High-Beam Indicator Light Headlight
High-Low Beam 4-71
Flashing the Headlights 4-71
Turn Signal/Hazard Warning Indicator Lights Turn and
Lane-Change Signals4-73
Hazard Warning Flasher4-80
*Mazda Radar Cruise Control with Stop & Go func tion (MRCC with Stop
& Go function) indicator Light*14-143
TCS/DSC Indicator Light*1
Traction Control System (TCS) 4-95
Dynamic Stabil‐ ity Control(DSC)4-97
Turns on 7-31
TCS OFF Indicator Light*14-96
Select Mode Indication 4-102
(Green)High Beam Control System (HBC) Indicator Light 4-112
Blind Spot Monitoring (BSM) OFF Indicator Light*1
Malfunction
7-31
Except malfunc‐ tion
4-119
(White)
*Mazda Radar Cruise Control with Stop & Go func tion (MRCC with Stop
& Go function) Main Indication 4-138
(Green)
*Mazda Radar Cruise Control with Stop & Go func
tion (MRCC with Stop
& Go function) Set Indication 4-138
When Driving
Instrument Cluster and Display
4-26*Some models.
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

SignalIndicator Page
Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) Indication 4-150
*Lane-keep Assist System (LAS) & Lane Departure Warning System
(LDWS) OFF Indicator Light*14-154
*Smart City Brake Support (SCBS) Indication Advanced Smart
City Brake Sup‐ port (Advanced
SCBS)
4-160
Smart City
Brake Support (SCBS)4-163
*Smart Brake Support/Smart City B rake Support (SBS/SCBS) OFF Ind ica‐
tor Light*1
Advanced Smart City Brake Sup‐ port (Advanced SCBS)4-160
Smart City
Brake Support (SCBS)
4-163
Smart Brake
Support (SBS) System4-165
(White)
*Cruise Main Indication 4-204
(Green)
*Cruise Set Indication4-204
*1 The light turns on when the ignition is switched on for an ope
ration check, and turns off
a few seconds later or when the engine is started. If the light does not turn on or remains
turned on, have the vehicle inspected at an Authorized Mazda De aler.
▼Wrench Indicator Light
The wrench indication is displayed under
the following conditions.
When the preset maintenance period has
arrived.
Refer to Maintenance Monitor on page
6-16.
When the engine oil replacement period
has arrived.
When Driving
Instrument Cluster and Display
*Some models.4-27
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

NOTE
The wrench indication may display
earlier than the preset period depending
on vehicle usage conditions.
Whenever the engine oil is replaced, a
reset of the vehicle engine control unit
necessary.
Your Authorized Mazda Dealer will be
able to reset the engine control unit or
see page 6-24 for the Vehicle engine
control unit reset procedure.

When Driving
Instrument Cluster and Display
4-28
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

Instrument Cluster (Type B)

ƒSpeedometer.......................................................................................................... page 4-29
„ Tachometer............................................................................................................ page 4-2 9
… Multi-information Display (Type B)............................. ........................................ page 4-30
† Dashboard Illumination.........................................................................................page 4-34
▼Speedometer
The speedometer indicates the speed of the
vehicle.
▼Tachometer
The tachometer shows engine speed in
thousands of revolutions per minute (rpm).
CAUTION
Do not run the engine with the tachometer
needle in the RED ZONE.
This may cause severe engine damage.

STRIPED
ZONE
RED ZONE
NOTE
When the tachometer needle enters the
STRIPED ZONE, this indicates to the
driver that the gears should be shifted
before entering the RED ZONE.
When Driving
Instrument Cluster and Display
4-29
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

▼Multi-information Display (Type B)
INFO switchMulti-information Display (Type B)
The multi-information display in
dicates the following information.
Odometer
Trip meter
Engine coolant temperature gauge
Fuel gauge
Outside temperature
Distance-to-empty
Average fuel economy
Current fuel economy
Maintenance Monitor
Blind Spot Monitoring (BSM) Display
Distance Recognition Support System (DRSS) Display
Mazda Radar Cruise Control with S top & Go function (MRCC with Stop & Go function)
System Display
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) Display
Cruise Control Display
Compass Display
Warning message
When Driving
Instrument Cluster and Display
4-30
CX-9_8HB2-EA-18G_Edition1 2018-5-11 13:09:27

The screen content changes each time the INFO switch is pressed.
Press the INFO switch
Press the INFO switch
Press the INFO switch Press the INFO switch
Press the INFO switch Press the INFO switch
Current Fuel Economy,
Trip Meter A, Average
Fuel Economy, Outside
Temperature,
Odometer, Fuel Gauge
Current Fuel Economy,
Trip Meter B, Average
Fuel Economy, Outside
Temperature,
Odometer, Fuel Gauge
Engine Coolant
Temperature Gauge,
Maintenance Monitor,
Outside Temperature,
Odometer, Fuel Gauge i-ACTIVSENSE display,
Outside Temperature,
Odometer, Fuel Gauge Warning message,
Outside Temperature,
Odometer, Fuel Gauge
*1
*1: Displayed only when a warning occurs. Engine Coolant
Temperature Gauge,
Compass,
Distance-to-empty,
Outside Temperature,
Odometer, Fuel Gauge
When Driving
Instrument Cluster and Display
4-31
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27

▼Odometer, Trip Meter and Trip
Meter Selector
The odometer is constantly displayed on
the screen when the
ignition is switched
ON, and the TRIP A or TRIP B screen can
be displayed by operating the INFO
switch.

Press the INFO switch INFO switch
Odometer,
Trip meter A
Odometer,
Trip meter B
Odometer
The odometer records the total distance
the vehicle has been driven.
Trip meter
The driving distance for a specified
interval is indicated. Two types (TRIP A,
TRIP B) of interval distance and the
average fuel economy for each can be
measured.

For instance, trip meter A can record the
distance from the point of origin, and trip
meter B can record the distance from
where the fuel tank is filled.

When trip meter A is selected, TRIP A
will be displayed. Wh en trip meter B is
selected, TRIP B will be displayed.

The trip meter and average fuel economy
can be reset by pressi ng the INFO switch
for 1.5 seconds or more while in each
mode.
NOTE
Only the trip meters record tenths of
kilometers (miles).
The trip record will be erased when:
The power supply is interrupted
(blown fuse or the battery is
disconnected).
The vehicle is driven over 9999.9 km
(mile).
▼ Engine Coolant Temperature Gauge
Displays the engine coolant temperature.
The blue gauge indicates that the engine
coolant temperature is low, and the red
gauge indicates that the engine coolant
temperature is high and overheating.

When Driving
Instrument Cluster and Display
4-32
CX-9_8HB2-EA-18G_Edition1
2018-5-11 13:09:27
