2019 MASERATI GHIBLI Owners Manual

Brakes Self-ventilating disc brakes on the four wheels. The Electric Parking Brake (EPB) acts on the rear wheels.
Braking System
Dual Cast Base
Front disc diameter 14 in (360 mm) 13.6 in (345 mm)
Rear disc diameter 13.6 in (345 mm) 13 in (330 mm)
Transmission ZF automatic transmission with 8 speeds, torque converter, lock-up clutch and anti-slip function.
Sequential and traditional control type.
Automatic transfer case (AWD version).
TRANSAXLE-type transmission.
Traction system equipped with rear self-locking differential.
Suspension Front suspensions with double wishbone independent wheels.
Multilink system rear suspensions on independent wheels.
Optional Skyhook active suspensions with electronic controlled dampening.
Steering Electric Power Steering (EPS) system, axis parallel type.
Steering diameter = 12.9 yd (11.8 m).
No. of steering wheel turns = 1.37 (to the left and right). Features and Specifications
8
365

Wheels NOTE:
• Maserati recommends Maserati Genuine Tires marked with “MGT” logo specifically designed for its models.
• In order to maintain high performance and safety level, Maserati recommends to use tires equivalent to the original
size.
WARNING!
• The maximum speed reachable with the tires is indicated by the tire manufacturer. Always comply with the regulations
in force in the Country you are driving in.
• Never exceed the maximum speed indicated for the tires: failure to respect the max. speed may damage these tires.
Danger: risk of accident!
Standard Wheel Dimension
Allowed tires size Ghibli - Ghibli S - Ghibli S Q4:
Basic version - GranLusso Ghibli - Ghibli S - Ghibli S Q4:
GranSport
Light alloy rims (M+S) 19” x 8,5J (front)
19” x 10J (rear) 20” x 8,5J (front)
20” x 10,5J (rear)
- Front tires 245/45 ZR 19 98Y 245/40 ZR 20 99Y XL
- Rear tires 275/40 ZR 19 101Y 285/35 ZR 20 100Y
- Front winter tires 245/45 ZR 19 102W XL M+S 245/40 R 20 99W XL M+S
- Rear winter tires 275/40 ZR 19 101W M+S 285/35 R 20 100W M+S
- Front all-season tires 245/45 R 19 98V M+S 245/40 R 20 99W XL M+S
- Rear all-season tires 275/40 R 19 101V M+S 285/35 R 20 100W M+S
Spare rim 18” x 6J
- Spare tire 175/55 18Features and Specifications
8
366

Optional Wheel Dimension
Allowed tires size Ghibli - Ghibli S - Ghibli S Q4:
Basic version - GranLusso Ghibli - Ghibli S - Ghibli S Q4:
GranSport
Light alloy rims 20” x 8,5J (front)
20” x 10,5J (rear) -
- Front tires 245/40 ZR 20 99Y XL -
- Rear tires 285/35 ZR 20 100Y -
- Front winter tires 245/40 R 20 99W XL M+S -
- Rear winter tires 285/35 R 20 100W M+S -
- Front all-season tires 245/40 R 20 99W XL M+S -
- Rear all-season tires 285/35 R 20 100W M+S -
Light alloy rims 21” x 8,5J (front)
21” x 10,5J (rear) 21” x 8,5J (front)
21” x 10,5J (rear)
- Front tires 245/35 ZR 21 96Y XL 245/35 ZR 21 96Y XL
- Rear tires 285/30 ZR 21 100Y XL 285/30 ZR 21 100Y XL
- Front winter tires 245/35 R 21 96W XL M+S 245/35 R 21 96W XL M+S
- Rear winter tires 285/30 R 21 100W XL M+S 285/30 R 21 100W XL M+S Features and Specifications
8
367

Performance NOTE:
The specifications described can change without prior notification.
Ghibli S Q4 (AWD version) Ghibli S Ghibli
Maximum speed 176.5 mph (284 km/h) 177 mph (285 km/h) 166 mph (267 km/h)
Accelerations from 0 to 60 mph 4.7 seconds 4.9 seconds 5.5 seconds
Weights NOTE:
The specifications described can change without prior notification.
Ghibli S Q4 (AWD version) Ghibli S Ghibli
Unladen vehicle weight (with
tank and reservoirs filled, tools
and accessories) 4,565 lb (°) 4,400 lb (°) 4,400 lb (°)
Approved Gross Vehicle Weight
Rating (GVWR) 5,573 lb
(2,621 lb front axle –
2,952 lb rear axle) 5,420 lb
(2,468 lb front axle –
2,952 lb rear axle) 5,420 lb
(2,468 lb front axle –
2,952 lb rear axle)
(°) Base configuration without options.Features and Specifications
8
368

Dimensions Basic version - GranLusso GranSport
Wheel base 118.03 in (2998 mm) 118.03 in (2998 mm)
Total length 195.82 in (4974 mm) 195.94 in (4977 mm)
Width without mirrors 76.57 in (1945 mm) 76.57 in (1945 mm)
Width with mirrors 82.67 in (2100 mm) 82.67 in (2100 mm)
Front track (*) 64.09 ÷ 64.29 in (1628 ÷ 1633 mm) 64.09 ÷ 64.29 in (1628 ÷ 1633 mm)
Rear track (*) 64.33 ÷ 65.31 in (1634 ÷ 1659 mm) 64.33 ÷ 65.31 in (1634 ÷ 1659 mm)
Front overhang 36.77 in (934 mm) 36.88 in (937 mm)
Rear overhang 41.02 in (1042 mm) 41.02 in (1042 mm)
Height (*) 57.44 ÷ 58.30 in (1459 ÷ 1481 mm) 57.55 ÷ 57.95 in (1462 ÷ 1472 mm)
Boot compartment volume 17.6 cu ft. (500 l) 17.6 cu ft. (500 l)
(*) Variable size according to the motorization, the tire size and the optional installed. Features and Specifications
8
369

Tire Inflation Pressure Cold tire inflation pressure value under the following loading conditions listed in the table below:
• PLC (Partial Loading Condition): considering 2 passengers + luggage.
• FLC (Full Loading Condition): considering 4 or 5 passengers + luggage.
(*) Speed driving higher than
124 mph (200 km/h)
Load PLC FLC PLC - FLC
Wheel Front and rear Front and rear Front and rear
Pressure 220 kPa – 32 PSI (2.2 bar) 260 kPa – 38 PSI (2.6 bar) 260 kPa – 38 PSI (2.6 bar)
Spare tire pressure 350 kPa – 51 PSI (3.5 bar)
(*) Not for winter and all-season tires.
NOTE:
• The pressure values indicated in the table are also indicated on the driver-side door pillar information label.
• For more information about the pressure check methods, see “Tires – General Information” in section “Driving”.
WARNING!
• Improperly inflated tires are dangerous.
• Under-inflation increases tire flexing and can result in tire overheating and failure.
• Over-inflation reduces a tire's ability to cushion shock. Objects on the road and potholes can cause damage that results
in tire failure.
• Over-inflated or under-inflated tires can affect vehicle handling and can fail suddenly, resulting in loss of vehicle control.
• Unequal tire pressures can cause steering problems.
• Unequal tire pressures from one side of the vehicle to the other can cause the vehicle to drift to the right or left.
• Always drive with each tire inflated to the recommended cold tire inflation pressure.Features and Specifications
8
370

9 – Index
371

Abbreviations .................8
Accessories
Aftermarket Parts and Accessories
Statement .................13
Active Blind Spot Assist - ABSA . . . .271
Adaptive Cruise Control (ACC) . . . .247
Activation/Deactivation ...... .250
Display Warnings and
Maintenance ............. .255
Precautions while Driving with
ACC ................... .256
Setting the Following Distance . .252
Setting the Speed .......... .251
Airbag.....................64
Advanced Front Air Bag
Properties .................65
Air Bag Deployment Result .....70
Air Bag Deployment Sensors and
Controls ..................15
Air Bag System Components .....64
Front Air Bag Inflator Units .....68
Passenger Air bag Labels .......20
Supplemental Driver Side Knee Air
bag......................67
Supplemental Restraint System
(SRS) .....................64
Supplemental Seat-mounted Side
Air Bags (SAB) ..............66
Supplemental Side Air Bag Inflatable
Curtain (SABIC) ..............67
Transport of persons with
disability ..................71
Air Conditioning (A/C) System . . . .197 A/C Distribution ........... .142
Alarm, Vehicle Security ..........27
ALR (Automatic Locking Retractor) . .61
Anti-Lock Braking System (ABS) and
Electronic Brake-force Distribution
(EBD) ................... .239
Assistance ...................11
Assistance, if you need ..........11
ATC (Automatic Temperature
Control) ................. .202
Audio Controls .............. .176
Audio Controls on Central
Console ................. .176
Steering Wheel Audio Controls . .176
Audio, setting .............. .191
Audio System ............... .177
Automatic Transmission
Manual Release of Transmission .315
AWD
All-Wheel Drive, drive mode . . . .223
BAS (Brake Assist System) ...... .240
Battery ................... .332
Battery Recharge .......... .335
Battery Remote Posts Position. . .313
Maintaining Battery Charge . . . .356
To Disconnect the Battery .... .332
To Reconnect the Battery ..... .334
Blind Spot Alert ............. .266
RCP - Rear Cross Path ........ .268
Bluetooth, Customer settings .... .192
Bodywork
Maintenance and
Care . .350
Pre-Short Drop Function ..... .353 Protection from Atmospheric
Agents ................. .350
Useful Advice to Keep the Bodywork
in Good Condition ......... .351
Brakes
Brake and Stability Control System
(ESC) ................... .238
Brake Overheating ......... .242
Brake System ............. .238
Manual Release of Parking
Brake .................. .311
Parking Brake ............. .233
Using the Brakes ........... .241
Capacity/Refillings ........... .360
Cargo Area ................ .133
Loading with Rear Seatbacks Folded
Down .................. .134
Vehicle Load Carrying Capacity . .133
Child Restraint Systems ..........72
Children too large for Booster
Seats .....................73
Infants and Child Restraints .....72
Installing Child Restraint Systems
using the Vehicle Seat Belt equipped
with ALR ..................74
Lower Anchors and Tether for
Children (LATCH) ............75
Older Children and Child
Restraints .................73
Tips on getting the most out of your
child restraint ...............74
Climate Control ............. .197Index
9 372
