short daily trips (approximately 10
miles/16 km) which correspond to an
annual total of 4000 miles/6000 km.
Please note that allowing the battery
to go dead repeatedly can cause
premature wear on the internal cells
and greatly reduce their life, leading
to problems with the ignition system
and other electrical/electronic systems.
The Authorized Maserati Dealer is
available to advise you on how to
recharge your battery correctly and
give you useful information on battery
care and maintenance.
NOTE:
The Authorized Maserati Dealer can
provide you with any information
about the Maserati approved “Battery
Charger and Conditioner”, available in
the “Genuine Accessories” range.
WARNING!
The process of charging or recharging
the battery produces hydrogen, a
dangerous gas that can explode and
cause serious injuries. When charging
or recharging the battery, follow the
recommended precautions at all
times:
• always charge or recharge the battery in a well-ventilated
environment;
• never charge or recharge a battery
that has frozen;
• ensure that any sparks or open
flames are nowhere near the battery
while it is charging;
• before using a charger to charge or
maintain the battery charge status,
carefully follow the instructions
provided to ensure the charger is
connected to the battery safely and
correctly. Maintenance and Care
7
357

Maintenance and Care
358

8 – Features and Specifications Refillings ............................................. 360
Fuel Consumption ...................................... 363
Technical Data ......................................... 364
Tire Inflation Pressure ................................... 370
359

Refillings NOTE:
Maserati reserves the right to change or revise specifications without prior notification.
CAUTION!
To guarantee vehicle’s integrity and maintain performance level always use genuine parts approved and recommended by
Maserati.
Refillings and Recommended Products Parts to be refilled Quantity Product specifications
Fuel tank 21 Gallons/80 litres
(including 4.2 Gallons/16 litres of
reserve) Premium unleaded fuel with no less than 91 CLC or
AKI (95 RON/85 MON).
Engine 7.7 Quarts/7.3 litres (max)
(Difference among MIN and MAX
level: 1.1 Quarts/1 litre) Synthetic multigrade lubricants SAE 10W-60 that
meet API SN/CF and ACEA A3, B3, B4 specifications.
Recommended oil: PENNZOIL Platinum Maserati
10W-60 (1).Engine
(AWD version) 8.8 Quarts/8.3 litres (max)
(Difference among MIN and MAX
level: 1.1 Quarts/1 litre)
Windshield washer fluid
tank 3.7 Quarts/3.5 litres Mix of water and detergent fluid, in the proportions
indicated on the product package. If the temperature
is below –4°F (–20°C), use pure detergent fluid.
Detergent fluid: Mix of CUNA NC 956-II surfactants
and alcohols.
Recommended fluid: WUERTH Windshield Washer
Fluid with antifreeze or AREXONS DP1.Features and Specifications
8
360

Parts to be refilled Quantity Product specifications
Engine cooling circuit 9.7 Quarts/9.2 litres Mixture of water and coolant, proportionally 50/50%.
Coolant: protective, antifreeze action and ethylene
glycol-based with organic inhibitors compatible with
regulations:
• ASTM D 3306, ASTM D 2570
• ASTM D 4340, ASTM D 2809
• SAE J 1034
• CUNA NC 956/16.
Recommended fluid: PETRONAS Paraflu Up 50/50.Automatic transmission
cooling circuit 2.64 Quarts/2.5 litres
(2) Automatic transmission 8 Quarts/7.6 litres First equipment oil: SHELL ATF L- 12108 or ZF
Lifeguard 8.
(2) Differential 1.4 Quarts/1.3 litres Synthetic Axle Lubricant SAE 75W-85 – FE Hypoid
Gear Lubricant.
(2) Front differential
(AWD version) 0.47 Quarts/0.45 litres First equipment oil: SHELL TF 0951B.
(2) Transfer case (AWD version) 0.65 Quarts/0.62 litres First equipment oil: SHELL TF 0870.
Braking system 0.93 Quarts/0.88 litres +/- 4% Synthetic fluid: FMVSS 116 DOT 4, ISO 4925 Class 4,
ENSAYOS INTA-UNE 26-109-88, SAE J1703, SAE J1704,
CUNA NC 956-01.
Recommended fluid: PETRONAS Tutela TOP 4/S.
CAUTION!
For each oil refilling and/or replacement, please contact an Authorized Maserati Dealer .
Air conditioning system 24 oz +/-0.7 oz
680 g +/-20 g Coolant: r134a.
(1) In countries where it is not available, recommended oil “PENNZOIL Platinum 10W-60”.
(2) No change and/or topping up expected in scheduled maintenance. Features and Specifications
8
361

WARNING!
California Proposition 65
Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including such
as, engine exhaust, carbon monoxide, phthalates and lead, that which are known to the State of California to cause
cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently
when servicing your vehicle. For more information go to: www.P65Warnings.ca.gov/passenger-
vehicle
Engine Oil Identification
Symbol This symbol means that the oil has been certified by the American Petroleum Institute (API). Maserati only
recommends API Certified engine oils.
CAUTION!
Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Damage caused by use of
non-approved chemicals is not covered by the new Vehicle Limited Warranty.
Engine Oil Viscosity (SAE Grade) SAE 10W-60 engine oil is recommended for all operating temperatures.
The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil
filler cap location, refer to chapter “Maintenance Procedures” in section “Maintenance and Care”.
Lubricants that do not have both the engine oil certification mark and the correct SAE viscosity grade number should not
be used.Features and Specifications
8
362

Fuel Consumption NOTE:
• The technical data, values and specifications in this Owner’s Manual are provided as guidance only. The vehicle specific
data can deviate from the information provided, for example, as a result of optional or special equipment ordered with
the vehicle, vehicle loads, and country specific measurement methods.
• The specifications described below can change without prior notification.
The fuel consumption values shown (Miles Per Gallon - MPG) are established using EPA test guidelines.
Ghibli S Q4 (AWD version) Ghibli S Ghibli
City 19.8 MPG 20.1 MPG 20.7 MPG
Highway 33.1 MPG 32.7 MPG 33.5 MPG
Combined 24.1 MPG 24.3 MPG 25 MPG
CAUTION!
• Actual fuel economy results will vary for many reasons, including driving conditions and how you drive and maintain
your vehicle.
• The type of route, traffic and weather conditions, driving style, general condition of the vehicle, equipment/accessories
in the vehicle, use of the air conditioning system, vehicle load and other items or situations which may negatively affect
the vehicle aerodynamics or wind resistance lead to consumption ratios differing from the indicated ones. Features and Specifications
8
363

Technical Data NOTE:
The technical data, values and specifications in this Owner’s Manual are provided as guidance only. The vehicle specific
data can vary from the information provided, for example, as a result of optional or special equipment ordered with the
vehicle, vehicle loads, and country specific measurement methods.
Engine Data Data Ghibli S Q4 (AWD version)
Ghibli S Ghibli
Cylinder number and position 6 - 60° V 6 - 60° V
Number of valves per cylinder 4 4
Bore x stroke 86.5 x 84.5 mm 86.5 x 84.5 mm
Total displacement 2,979 cm 3
2,979 cm 3
Compression ratio 9.7 : 1 9.7 : 1
Maximum power output (EC) 316 kW – 424 HP 257 kW – 345 HP
- corresponding RPM 5,750 RPM 5,500 RPM
Peak and overboost torque (EC) 428 ft-lb (580 N-m) 369 ft-lb (500 N-m)
- corresponding RPM 1,750 – 4,500 RPM 1,600 – 4,500 RPM
Properties
Timing The timing system uses two overhead camshafts with timing variator.
Timing system control Timing chain.
Supply Over-supplied with turbocompressor and related intercooler for each bank.
Injection – Ignition High pressure 2900 PSI (200 bar) direct fuel injection system. Static ignition with digital
electronic control system included and controlled by a single microprocessor ECU.Features and Specifications
