2018 MAZDA MODEL 3 HATCHBACK Owners Manual (in English)

Electrical specifications:
Voltage: 9-16V, Frequency: 2.4Ghz, Current: 270mA(Typ)
Ty p e B
U.S.A. and Canada
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-47
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Mexico
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-48
Mazda3_8GE4-EA-17F_Edition12017-4-7 11:59:21

▼Distance Recognition Sup
port System (DRSS)/Mazda Radar Cruise C ontrol
(MRCC)/Smart Bra ke Support (SBS)
Customer Information and Reporting Safety Defects
Declaration of Conformity
8-49
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

MEMO
8-50
Mazda3_8GE4-EA-17F_Edition12017-4-7 11:59:21

9Specifications
Technical information about your Mazda.
Identification Numbers..................... 9-2 Vehicle Information Labels.......... 9-2
Specifications..................................... 9-4 Specifications............................... 9-4
Personalization Feat ures.................9-12
Personalization Features............. 9-12
9-1
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Vehicle InformationLabels
▼Vehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on a
plate attached to the cowl panel located on
the left corner of the dashboard. This plate
can easily be seen through the windshield.
▼Motor Vehicle Safety Standard
Label (U.S.A. and Canada)
▼ Chassis Number
Open the cover shown in the figure to
check the chassis number.
▼Vehicle Emission Control
Information Label (U.S.A. and
Canada)
▼Tire Pressure Label
Specifications
Identification Numbers
9-2
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

▼Engine Number
Forward
Specifications
Identification Numbers
9-3
Mazda3_8GE4-EA-17F_Edition1
2017-4-7 11:59:21

Specifications
▼Engine
Item Specification
SKYACTIV-G 2.0 SKYACTIV-G 2.5
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 83.5 × 91.2 mm (3.29 × 3.59 in) 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 1,997.6 ml (1,997.6 cc) 2,488.5 ml (2,488.5 cc)
Compression ratio 13.0
▼Electrical System
Item
Classification
Battery Q-85
*1
12V-60Ah/20HR*2 or 12V-65Ah/20HR*2
Spark-plug number
Mazda Genuine spark
plug*3PE5R-18-110 or PE5S-18-110
*1 Q-85 is designed for i-ELOOP sys
tem. Only Q-85 should be used to ensure correct operation of i-ELOOP
system. Consult an Authorized Mazda Dealer for details.
*2 Not for i-ELOOP system.*3 This spark plug provides the SK YACTIV-G engine with optimum performance. Contact an Authorized Mazda
Dealer for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-23.
Manual transaxle oil API Service
GL-4
SAE 75W-80
Automatic transaxle fluid Mazda Genuine ATF FZ
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
Specifications
Specifications
9-4
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21
