2018 LEXUS RX450h Owners Manual

6497-3. Do-it-yourself maintenance
7
Maintenance and care
RX450h_RX450hL _U_OM48F85U■
LED lights
The headlight low beams, headlight high beams, front turn signal lights (vehicles with tri-
ple-beam headlights), parking lights and da ytime running lights, fog lights, cornering
lights (if equipped), front side marker lights (vehicles with triple-b eam headlights), side
turn signal lights, stop/tail lights, rear turn signal light (vehicles with triple-beam head-
lights), rear side marker lights, high mounted stoplight, license plate lights, and outer foot
lights consist of a number of LEDs. If any of the LEDs has burned out, take your vehicle to
your Lexus dealer to have the light replaced. ■
Condensation build-up on the inside of a lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:●
Large drops of water have built up on the inside of a lens. ●
Water has built up inside a headlight. ■
When replacing light bulbs
→ P. 634
WARNING ■
To prevent injury
Before performing any light bulb replacement procedure, be sure to turn the power
switch off. Failure to do so may result in burns from hot components or a part of your
body may get caught on an operating co mponent, possibly causing serious injury.■
Replacing light bulbs ●
Turn off the lights. Do not attempt to replac e the bulb immediately after turning off the
lights.
The bulbs become very hot and may cause burns. ●
Do not touch the glass portion of the light bu lb with bare hands. When it is unavoid-
able to hold the glass portion, use and hold with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is sc ratched or dropped, it may blow out or crack.●
Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or water entering th e headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.●
Do not attempt to repair or disassemble th e light bulbs, connector s, electric circuits
or component parts.
Doing so may result in death or se rious injury due to electric shock.■
To prevent damage or fire ●
Make sure bulbs are fully seated and locked. ●
Check the wattage of the bulb before installing to prevent heat damage.

650 7-3. Do-it-yourself maintenance
RX450h_RX450hL _U_OM48F85U

651
8When trouble arises
RX450h_RX450hL _U_OM48F85U 8-1. Essential information
Emergency flashers .................. 652
If your vehicle has
to be stopped in
an emergency .......................... 653
8-2. Steps to take in
an emergency
If your vehicle needs
to be towed................................ 654
If you think something is
wrong ........................................... 659
If a warning light turns on
or a warning buzzer
sounds..........................................660
If a warning message is
displayed..................................... 667
If you have a flat tire .................. 673
If the hybrid system will
not start .......................................690
If the electronic key does
not operate properly ............. 692
If the 12-volt battery is
discharged ................................. 695
If your vehicle overheats ......... 702
If the vehicle becomes
stuck ............................................. 706

652
RX450h_RX450hL _U_OM48F85U8-1. Essential information
Press the switch. All the turn signal lights will flash. To turn
them off, press the switch once again.
■
Emergency flashers
If the emergency flashers are used for a long time while the hybrid system is not operat-
ing (while the “READY” indicator is not illu minated), the 12-volt battery may discharge.
Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has
to be stopped on the road due to a breakdown, etc.

6538-1. Essential information
8
When trouble arises
RX450h_RX450hL _U_OM48F85USteadily step on the brake pedal with both feet and firmly depress it.Do not pump the brake pedal repeatedly as this will increase the effort required to
slow the vehicle.
Shift the shift lever to N. 
If the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the hybrid system. 
If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed as
much as possible.
To stop the hybrid system, press and
hold the power switch for 2 consec-
utive seconds or more, or press it
briefly 3 times or more in succes-
sion.
Stop the vehicle in a safe place by the road.If your vehicle has to be stopped in an emergencyOnly in an emergency, such as if it becomes impossible to stop the vehicle in
the normal way, stop the vehicl e using the following procedure:1
2
3
4
3
Press and hold for 2 seconds or more,
or press briefly 3 times or more4
WARNING ■
If the hybrid system has to be turned off while driving
Power assist for the steering wheel will be lost, making the steering wheel heavier to
turn. Decelerate as much as possible before turning off the hybrid system.5

654
RX450h_RX450hL _U_OM48F85U8-2. Steps to take in an emergency
The following may indicate a problem wi th your hybrid transmission. Contact
your Lexus dealer or commercial towing service before towing. ●
The hybrid warning message shows on and the vehicle does not move. ●
The vehicle makes an abnormal sound.
Do not tow with a sling-type truck to
prevent body damage.If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or commercial towing se rvice, using a wheel-lift type truck or
flatbed truck.
Use a safety chain system for all towing, and abide by all state/provincial and
local laws.
If towing your vehicle with a wheel-lift type truck, use a towing dolly.
( → P. 655, 657)
Situations when it is necessary to contact dealers before towing
Towing with a sling-type truck

6558-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL _U_OM48F85UIf your vehicle is transported by a flat-
bed truck, it should be tied down at the
locations shown in the illustration.
If you use chains or cables to tie down
your vehicle, the angles shaded in black
must be 45 ° .
Do not overly tighten the tie downs or
the vehicle may be damaged.Towing with a wheel-lift type truck 
From the front 
From the rear
Use a towing dolly under the rear
wheels. Use a towing dolly under the front
wheels.
Using a flatbed truck Front

656 8-2. Steps to take in an emergency
RX450h_RX450hL _U_OM48F85UTake out the towing eyelet. ( → P. 674)
Remove the eyelet cover.
Insert the towing eyelet into the hole
and tighten partially by hand.
Tighten down the towing eyelet
securely using a wheel nut wrench
or hard metal bar.
Securely attach cables or chains to the towing eyelet.
Take care not to damage the vehicle body.
Enter the vehicle being towed and start the hybrid system.
If the hybrid system does not start, turn the power switch to ON mode.
Shift the shift lever to N and release the parking brake.
When the shift lever cannot be shifted: → P. 250Emergency towing procedure (vehicles with a towing eyelet) 1
2
3
4
5
6
7
