2018 LEXUS RX450h Owners Manual

1853-3. Adjusting the seats
3
Operation of each component
RX450h_RX450hL _U_OM48F85U■
Cancelation procedure
Carry only the key you want to cance l and then close the driver’s door.
If 2 or more keys are in the vehicle, the driving position cannot be canceled
properly.
Turn the power switch to ON mode.
While pressing the “SET” button, pr ess and hold the door lock switch
(either lock or unlock) un til the buzzer sounds twice.If it button could not be canceled, the buzzer sounds continuously for approxi-
mately 3 seconds.■
Recalling the driving position using the memory recall function●
Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be di fferent depending on the key being carried.●
If a door other than the driver’s door is unlocked with the smart access system with
push-button start, the driving position cannot be recalled. In this case, press the driving
position button which has been set. ■
Customization
Some functions can be customized. ( → P. 736)
WARNING ■
Seat adjustment caution
Take care during seat adjustment so that th e seat does not strike the rear passenger or
squeeze your body against the steering wheel. 1
2

186 3-3. Adjusting the seats
RX450h_RX450hL _U_OM48F85U◆ Vertical adjustment
Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button.
◆ Horizontal adjustment (if equipped)
The position of the head restraint
can be adjusted forward in 4 stages. If the head restrain t is pulled forward
from the foremost position, it will
return to the rearmost position.
Up Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button.Head restraints Head restraints are provided for all seats.
Front seats
Lock release button1
2
Second-row seats
Lock release button1
2

1873-3. Adjusting the seats
3
Operation of each component
RX450h_RX450hL _U_OM48F85UUp Pull the head restraints up.
Down Push the head restraint down while
pressing the lock release button. ■
Removing the head restraints 
Front and second-row seats 
Third-row seatsThird-row seats (RX450hL)
Lock release button1
2
Pull the head restraint up while pressing the lock
release button.
If the head restraint to uches the ce iling, making
the removal difficult, change the seat height or
angle. ( → P. 167, 168)
Pull the head restraint up while pressing the lock
release button.
If the head restraint to uches the ce iling, making
the removal difficult, change the seat angle.
( → P. 168) Lock release button
Lock release button

188 3-3. Adjusting the seats
RX450h_RX450hL _U_OM48F85U■
Installing the head restraints 
Front and second-row seats 
Third-row seats
■
Adjusting the height of the head restraints
■
Adjusting the second-row center an d third-row seat head restraints
Always raise the head restraint one leve l from the stowed position when using.Align the head restrain t with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint.
Align the head restrain t with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint.
Make sure that the head restraints are adjusted
so that the center of the head restraint is closest
to the top of your ears.
WARNING ■
Head restraint precautions
Observe the following precautions regarding the head restraints.
Failure to do so may result in death or serious injury.●
Use the head restraints design ed for each respective seat.●
Adjust the head restraints to th e correct position at all times.●
After adjusting the head restraints, push down on them and make sure they are
locked in position. ●
Do not drive with the head restraints removed. Lock release button
Lock release
button

189
3
Operation of each component
RX450h_RX450hL _U_OM48F85U 3-4. Adjusting the steering wheel and mirrors
Operating the switch moves the steering wheel in the following directions:
Up
Down
Toward the driver
Away from the driver
When the power switch is turned off,
the steering wheel returns to its stowed
position by moving up and away to
enable easier driv er entry and exit.Turning the power switch to ACCES-
SORY or ON mode will return the
steering wheel to the original position.
To sound the horn, press on or close to
the mark.Steering wheel Adjustment procedure 1
2
3
4
Auto tilt away
Horn

190 3-4. Adjusting the steering wheel and mirrors
RX450h_RX450hL _U_OM48F85U■
The steering wheel can be adjusted when
The power switch is in ACCESSORY or ON mode
* .
* : If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of
power switch mode. ■
Automatic adjustment of the steering position (if equipped)
A desired steering position ca n be entered to memory and recalled automatically by the
driving position memory system. ( → P. 181)■
Power easy access system
The steering wheel and driver’s seat (on so me models) move in ac cordance with power
switch mode and the driver’s seat belt condition. ( → P. 181)■
Customization
Some functions can be customized. ( → P. 736)
WARNING
Do not adjust the steeri ng wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an accident, result-
ing in death or serious injury.

1913-4. Adjusting the steering wheel and mirrors
3
Operation of each component
RX450h_RX450hL _U_OM48F85UThe height of the rear view mirror can be adjusted to suit your driving posture.
Adjust the height of the rear view mir-
ror by moving it up and down.
Responding to the level of brightness of the headlights of vehicles behind, the
reflected light is automatically reduced.
Changing automatic anti-glare func-
tion mode
ON/OFF When the automatic anti-glare function
is in ON mode, the indicator illuminates.
The function will set to ON mode each
time the power switch is turned to ON
mode.
Pressing the button turns the function to
OFF mode. (The indicator also turns
off.)Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirma-
tion of the rear view.
Adjusting the height of rear view mirror
Auto anti-glare function
Indicator

192 3-4. Adjusting the steering wheel and mirrors
RX450h_RX450hL _U_OM48F85U■
To prevent sensor error
To ensure that the sensors operate properly, do
not touch or cover them.
WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident, resulting in
death or serious injury.
