2018 LEXUS LX570 Owners Manual

LX570_OM_OM60Q78U_(U) 3854-6. Driving tips
4
Driving NOTICE ■
Repairing or replacing snow tires
Request repairs or replacement of snow ti res from Lexus dealers or legitimate tire
retailers.
This is because the removal an d attachment of snow tires affects the operation of the
tire pressure warning va lves and transmitters.■
Fitting tire chains (vehicles with 20-inch tires)
The tire pressure warning valv es and transmitters may not function correctly when tire
chains are fitted.

386
LX570_OM_OM60Q78U_(U) 4-6. Driving tips
Off-road precautions ●
Specific design characteristics give it a higher center of gravity than ordinary
passenger cars. This vehicle design feature causes this type of vehicle to be
more likely to rollover. And, utility vehi cles have a significantly higher rollover
rate than other types of vehicles. ●
An advantage of the higher ground cl earance is a better view of the road
allowing you to anticipate problems. ●
It is not designed for cornering at the same speeds as ordinary passenger cars
any more than low-slung sports cars are designed to perform satisfactorily
under off-road conditions. Therefore, sharp turns at excessive speeds may
cause the vehicle to rollover.This vehicle belongs to the utility vehicl e class, which has higher ground clear-
ance and narrower tread in relation to the height of its center of gravity to
make it capable of performing in a wi de variety of off-road applications.
Off-road vehicle features

LX570_OM_OM60Q78U_(U) 3874-6. Driving tips
4
Driving WARNING ■
Off-road vehicle precautions
Always observe the following precautions to minimize the risk of death, serious injury
or damage to your vehicle: ●
In a rollover crash, an unbelted person is si gnificantly more likely to die than a person
wearing a seat belt. Therefore, the driver and all passengers should always fasten
their seat belts. ●
Avoid sharp turns or abrupt maneuvers, if at all possible.
Failure to operate this vehicle correctly may result in loss of control or vehicle rollover
causing death or serious injury. ●
Loading cargo on the roof lu ggage carrier will make the ce nter of the vehicle gravity
higher. Avoid high speeds, sudden starts, sharp turns, sudden braking or abrupt
maneuvers, otherwise it may re sult in loss of control or vehicle rollover due to failure
to operate this vehicle correctly. ●
Always slow down in gusty crosswinds. Be cause of its profile and higher center of
gravity, your vehicle is more sensitive to side winds than an ordinary passenger car.
Slowing down will allow you to have better control. ●
Do not drive horizontally across steep slopes . Driving straight up or straight down is
preferred. Your vehicle (or any similar off- road vehicle) can tip over sideways much
more easily than forward or backward.

388
LX570_OM_OM60Q78U_(U) 4-6. Driving tips
When driving your vehicle off-road, plea se observe the following precautions to
ensure your driving enjoyment and to he lp prevent the closure of areas to off-
road vehicles: ●
Drive your vehicle only in areas wher e off-road vehicles are permitted to
travel. ●
Respect private property. Get owner’s permission before entering private
property. ●
Do not enter areas that are closed. Honor gates, barriers and signs that
restrict travel. ●
Stay on established road s. When conditions are wet, driving techniques
should be changed or travel dela yed to prevent damage to roads.■
Additional information for off-road driving
For owners in U.S. mainland, Hawaii and Puerto Rico:
To obtain additional information pertaining to driving your vehicle off-road, consult the
following organizations: ●
State and Local Parks and Recreation Departments ●
State Motor Vehicle Bureau ●
Recreational Vehicle Clubs ●
U.S. Forest Service and Bu reau of Land ManagementOff-road driving

LX570_OM_OM60Q78U_(U) 3894-6. Driving tips
4
Driving WARNING ■
Off-road driving precautions
Always observe the following precautions to minimize the risk of death, serious injury
or damage to your vehicle: ●
Drive carefully when off the road. Do not ta ke unnecessary risks by driving in danger-
ous places. ●
Do not grip the steering wheel spokes when driving off-road. A bad bump could jerk
the wheel and injure your hands. Keep both hands and especially your thumbs on the
outside of the rim. ●
Always check your brakes for effectiveness immediately after driving in sand, mud,
water or snow. ●
After driving through tall grass, mud, rock , sand, rivers, etc., check that there is no
grass, bush, paper, rags, stone, sand, etc. adhering or trapped on the underbody.
Clear off any such matter from the underbody. If the vehicle is used with these materi-
als trapped or adhering to the underbody, a breakdown or fire could occur. ●
When driving off-road or in rugged terrain , do not drive at excessive speeds, jump,
make sharp turns, strike obje cts, etc. This may cause loss of control or vehicle rollover
causing death or serious injury. You are also risking expensive damage to your vehi-
cle’s suspension and chassis.

390
LX570_OM_OM60Q78U_(U) 4-6. Driving tips
NOTICE ■
To prevent the water damage
Take all necessary safety measures to ensure that water damage to the engine or other
components does not occur. ●
Water entering the engine air intake will cause severe engine damage. ●
Water entering the automatic transmission will cause deterioration in shift quality,
locking up of your transmission accompan ied by vibration, and ultimately damage.●
Water can wash the grease from wheel be arings, causing rusting and premature fail-
ure, and may also enter the differentials, tr ansmission and transfer case, reducing the
gear oil’s lubricating qualities. ■
When you drive through water
If driving through water, such as when cro ssing shallow streams, first check the depth of
the water and the bottom of the riverbed for firmness. Drive slowly and avoid deep
water. ■
Inspection after off-road driving ●
Sand and mud that has accumulated in brake drums and around brake discs may
affect braking efficiency and may damage brake system components. ●
Always perform a maintenance inspection afte r each day of off-road driving that has
taken you through rough terrain, sand, mud, or water. For scheduled maintenance
information, refer to the “Warranty and Se rvices Guide”, “Owner’s Manual Supple-
ment” or “Scheduled Maintenance”.

391
LX570_OM_OM60Q78U_(U) 5Interior features5-1. Remote Touch screen
Remote Touch/12.3-inch
display ..........................................392
5-2. Lexus Climate Concierge
Lexus Climate Concierge ..... 398
5-3. Using the air conditioning
system and defogger
Front automatic air
conditioning system ...............399
Rear air conditioning
system ........................................... 410
Heated steering wheel/seat
heaters/seat ve ntilators......... 413
5-4. Using the interior lights
Interior lights list........................... 417
• Interior lights ........................... 418
• Personal lights ........................ 419 5-5. Using the storage features
List of storage features ............ 420
• Glove box .................................421
• Console box.............................421
• Overhead console .............. 422
• Cup holders ........................... 423
• Bottle holders ........................ 424
• Card holder............................ 424
• Auxiliary boxes ..................... 425
Luggage compartment
features ....................................... 427
5-6. Using the other interior
features
Other interior features ............430
• Cool box..................................430
• Sun visors ................................. 431
• Vanity mirrors ........................ 431
• Clock ........................................ 432
• Power outlets......................... 433
• Wireless charger ................. 435
• Armrest .................................... 442
• Rear door sunshades ......... 443
• Coat hooks ............................. 443
• Assist grips.............................. 444
Garage door opener ............... 445
LEXUS Enform Safety
Connect ...................................... 452

392
LX570_OM_OM60Q78U_(U) 5-1. Remote Touch screen
Remote Touch/12.3-inch display
“MAP” button Press this button to display the vehicle’s current position.
“ ∧ • ∨ ” buttonPress this button to change map scale and scroll through lists.
Back button Press this button to display the previous screen.
“MENU” button Press this button to display the “Menu” screen.
Remote Touch knob Move in the desired direction to select a function, letter and screen button.
Press the knob to enter the selected function, letter or screen button.
“ENTER” button Press this button to enter the selected function, letter or screen button.The Remote Touch can be used to operate the Remote Touch screens.
Owners of models equipped with a navi gation system should refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.
Remote Touch operation
1
2
3
4
5
6
