2018 FIAT PANDA Owner handbook (in English)

Panda Cross versions
ABCDE FGH I
3705 772.5 2300 632.51656.5 /
1635(*)
1406 /
1412(*)–
1422
(*)16621403 /
1416(*)–
1426
(*)1882
(*) Panda Cross 4x2 versions
138F1D0121
167

WEIGHTS
Panda versions
Weights (kg) 0.9 TwinAir 60HP / 65HP0.9 TwinAir Turbo 80HP
/ 85HP0.9 TwinAir Turbo
Natural Power
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):955 975 / 980
1080/1090(***)
Payload including the driver:(*)480 (4-seater) / 500
(5-seater)480 (4-seater) / 500
(5-seater)460 (4-seater) /450(***)
(4-seater) / 470 (5-seater)
/ 460
(***)(5-seater)
Maximum permitted loads
(**)
- front axle: 770 855 875
– rear axle: 760 760 810
- total:1435 (4-seater) / 1455
(5-seater)1455 (4 seats) / 1460 (4
seats)
(°)/ 1475 (5-seater)
/ 1480 (5-seater)
(°)
1540 (4-seater) / 1550
(5-seater)
Towable loads
– braked trailer: 800 800
(°°)
– non-braked trailer: 400 400(°°)
Maximum load on roof: 55 55 55
Maximum load on ball joint (braked trailer): 60 60
(°°)
(***) For versions/markets, where foreseen (*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads.
(**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted
loads.
(°) Versions equipped with the "Dualogic" gearbox
(°°)IMPORTANT A trailer cannot be towed so there are no provisions for fitting a tow hook.
168
TECHNICAL DATA

Weights (kg) 1.2 8V 69 HP 1.2 8V 69 HP LPG1.3 16V Multijet 80HP/
95HP
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):940/965(****)980 1045
Payload including the driver:
(*)
480 (4-seater) / 455(****)
(4-seater) / 500 (5-seater)
/ 475
(****)(5-seater)470480 (4-seater)
(1)/ 470
(4-seater)
(2)/ 500
(5-seater)
(1)/ 490
(5-seater)
(2)
Maximum permitted loads(**)
- front axle: 770 770 855
– rear axle: 760 760 760
- total:1420 (4-seater) / 1440
(5-seater)14501515 (4-seater) / 1535
(5-seater)
Towable loads
– braked trailer: 800
(***)900
– non-braked trailer: 400
(***)400
Maximum load on roof: 55 55 55
Maximum load on ball joint (braked trailer): 60
(***)60
(****) For versions/markets, where foreseen (*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads. (1) 80 HP
(2) 95 HP
(**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted
loads.
(***)IMPORTANT A trailer cannot be towed so there are no provisions for fitting a tow hook.
169

Panda Cross and Panda 4x4 versions
Weights (kg)0.9 TwinAir Turbo 85
HP0.9 TwinAir Turbo 90
HP1.2 8V 69 HP1.3 16V Multijet 80HP/
95HP
Unladen weight (with all fluids,
fuel tank 90% full and without
optional equipment):1050 1090 10001125(°)/ 1090(°°)/
1165
(°°°)
Payload including the driver:(*)480 (4-seater) / 500
(5-seater)440 (4 seats) / 495 (5
seats)455 (4 seats) / 475 (5
seats)470 (4-seater)
(°)/ 425
(4-seater)
(°°)/ 430
(4-seater)
(°°°)/ 490
(5-seater)
(°)/ 445
(5-seater)
(°°)/ 460
(5-seater)
(°°°)
Maximum permitted loads(**)
- front axle: 875 875 855
875 / 855(°°)
– rear axle: 810 810 760
810 / 760(°°)
(°) Panda 4x4 versions
(°°) Panda Cross 4x2 versions
(°°°) Panda Cross 4x4 versions
(*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads.
(**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted
loads.
170
TECHNICAL DATA
- total:1530 (4-seater) / 1550
(5-seater)1530 (4 seats) / 1585 (5
seats)1455 (4 seats) / 1475 (5
seats)1595 (4 seats) / 1515 (4
seats)
(°°)/ 1615
(5-seater)
(°)/ 1535
(5-seater)
(°°)/ 1625
(5-seater)
(°°°)

Weights (kg)0.9 TwinAir Turbo 85
HP0.9 TwinAir Turbo 90
HP1.2 8V 69 HP1.3 16V Multijet 80HP/
95HP
Towable loads
– braked trailer: 800 800 800 900
– non-braked trailer: 400 400 400 400
Maximum load on roof: 55
60
(***)60
60(***) (°°°°)
Maximum load on ball joint
(braked trailer):60 60 60 60
(***) Load evenly distributed (°°°°) Panda Cross 4x2 and 4x4 versions
171

Panda VAN versions
Weights (kg) 0.9 TwinAir 65 HP0.9 TwinAir Turbo
85 HP0.9 TwinAir Turbo
85 HP 4x40.9 TwinAir Turbo
Natural Power
Unladen weight (with all fluids, fuel tank
90% full and without optional
equipment):950 (2-seater) / 960
(4-seater)980 1035 1075
Payload including the driver:
(*)505 (2-seater) / 490
(4-seater)500 (2 seats) / 490 (4
seats)510
420(°)/ 460
Maximum permitted loads
(**)
- front axle: 770 855 875 875
– rear axle:770 (2-seats / 780
(4-seats)770 (2 seats) / 780 (4
seats)810 810
- total:1455 (2-seats) / 1450
(4-seats)1480 (2 seats) / 1470
(4 seats)1545
1495
(°)/ 1535
Towable loads
– braked trailer: 800 800 800
(***)
– non-braked trailer: 400 400 400(***)
Maximum load on roof: 60 60 60 60
Maximum load on ball joint (braked
trailer):60 60 60
(***)
(*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads.
(°) Versions with reduced capacity (**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted
loads.
(***)IMPORTANT A trailer cannot be towed so there are no provisions for fitting a tow hook.
172
TECHNICAL DATA

Weights (kg) 1.2 8V 69 HP 1.2 8V 69 HP LPG1.3 16V MultiJet 80
HP1.3 16V MultiJet 4x4
80 HP
Unladen weight (with all fluids, fuel tank
90% full and without optional
equipment):935 (2-seater) / 945
(4-seater)9751040 (2-seater) / 1050
(4-seater)1110
Payload including the driver:
(*)505 (2-seater) / 490
(4-seater)470400 (2-seater)(°)/
495 (2-seater) / 485
(4-seater)485
Maximum permitted loads
(**)
- front axle: 770 770855 (2-seater) / 875
(4-seater)875
– rear axle:770 (2-seats) / 780
(4-seats)770770 (2-seats) / 780
(4-seats)810
- total:1440 (2-seater) / 1435
(4-seater)14451440 (2-seater)
(°)/
1535 (2-seater) / 1535
(4-seater)1595
(*) If special equipment is fitted (trailer towing equipment, etc.) the empty weight will increase and consequently the payload will decrease in relation to the maximum
permitted loads.
(°) Versions with reduced capacity (**) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or on the load platform within the maximum permitted
loads.
(***)IMPORTANT A trailer cannot be towed so there are no provisions for fitting a tow hook.
173

Weights (kg) 1.2 8V 69 HP 1.2 8V 69 HP LPG1.3 16V MultiJet 80
HP1.3 16V MultiJet 4x4
80 HP
– non-braked trailer: 400(***)400 400
Maximum load on roof: 60 60 60 -
Maximum load on ball joint (braked
trailer):60
(***)60 60
(***)IMPORTANT A trailer cannot be towed so there are no provisions for fitting a tow hook.
174
TECHNICAL DATA
Towable loads
– braked trailer: 800
(***)900 900
