2018 FIAT 500L Owner handbook (in English)

PERFORMANCE
Top speeds after the initial period of usage of the car.
500L VERSIONS
Versionskm/h
0.9 TwinAir Turbo Natural Power
167(*)/ 163(**)
0.9 TwinAir Turbo 105 HP180
1.4 16V 95 HP178
1.4 16V 95 HP PRO178
1.4 16V 120 HP189
1.4 16V 120 HP LPG189
1.3 16V 85CV Multijet165
1.3 16V 85 HP Multijet PRO165
1.3 16V 85 HP Multijet Dualogic164
1.3 16V 95 HP Multijet171
1.3 16V 95 HP Multijet PRO171
1.3 16V 95CV MultiJet Dualogic169
1.6 16V 105 HP MultiJet181
1.6 16V 105 HP Multijet PRO181
1.6 16V 120 HP MultiJet189
1.6 16V 120 HP Multijet PRO189
(*) Running on petrol
(**) Running on methane
191

500L CROSS VERSIONS
Versionskm/h
0.9 TwinAir Turbo 105 HP173
1.4 16V 95 HP165
1.4 16V 120 HP183
1.4 16V 120 HP LPG183
1.3 16V 85CV Multijet160
1.3 16V 85 HP Multijet Dualogic158
1.3 16V 95 HP Multijet166
1.3 16V 95CV MultiJet Dualogic163
1.6 16V 105 HP MultiJet175
1.6 16V 120 HP MultiJet183
192
TECHNICAL DATA

500L WAGON VERSIONS
Versionskm/h
0.9 TwinAir Turbo Natural Power
167(*)/ 163(**)
0.9 TwinAir Turbo 105 HP180
1.4 16V 95 HP178
1.4 16V 120 HP189
1.3 16V 85CV Multijet165
1.3 16V 85 HP Multijet Dualogic164
1.3 16V 95 HP Multijet171
1.3 16V 95CV MultiJet Dualogic169
1.6 16V 105 HP MultiJet181
1.6 16V 120 HP MultiJet189
(*) Running on petrol
(**) Running on methane
193

WEIGHTS
NOTE Towing trailers is not permitted on versions for Cyprus.
500L / 500L CROSS VERSIONS
Weights (kg) 0.9 TwinAir Turbo Natural Power 0.9 TwinAir Turbo 105 HP
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1390
1260 / 1270(*)/ 1300(*) (**)
Payload including the driver(***)505
560 / 545(*)/ 520(*) (**)
Maximum permitted loads(****)
1050 1050 - front axle:
– rear axle: 1000 1000
- total:
1895 1820 / 1815
(*)/ 1820(*) (**)
Towable loads
– 1000
– braked trailer:
– non-braked trailer: – 400
Maximum load on roof: 60 60
Maximum load on ball joint (braked trailer): – 60
(*) Cross versions
(**) Version for specific markets
(***) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to the maximum
permissible loads.
(****) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted
loads.
194
TECHNICAL DATA

Weights (kg) 1.4 16V 95 HP 1.4 16V 120 HP
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1245 / 1255(*)/ 1270(**)1290 / 1300(*)
Payload including the driver(***)560 / 545(*)/ 575(**)560
Maximum permitted loads
(****)
1050 1050 - front axle:
– rear axle: 1000 1000
- total:
1805 / 1800
(*)/ 1845(**)1850 / 1860(*)
Towable loads
1000 1000
– braked trailer:
– non-braked trailer: 400 400
Maximum load on roof: 60 60
Maximum load on ball joint (braked trailer): 60 60
(*) Cross versions
(**) PRO versions
(***) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to the maximum
permissible loads.
(****) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted
loads.
195

Weights (kg) 1.4 16V 120 HP LPG 1.3 16V 85CV Multijet1.3 16V 85 HP Multijet
Dualogic
Unladen weight (with all fluids, fuel tank 90%
full and without optional equipment):1310 / 1320(*)1295 / 1305(*)/ 1320(**)1300 / 1310(*)
Payload including the driver(****)560
550 / 545(*)/ 575(**)560 / 545(*)
Maximum permitted loads(*****)
1050 1050 1050 - front axle:
– rear axle: 1000 1000 1000
- total:
1870 / 1880
(*)1845 / 1850(*)/ 1895(**)1850 / 1855(*)
Towable loads
1000 1000 1000
– braked trailer:
– non-braked trailer: 400 400 400
Maximum load on roof: 60 60 60
Maximum load on ball joint (braked trailer): 60 60 60
(*) Cross versions
(**) PRO versions
(****) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation tothe maximum
permissible loads.
(*****) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted
loads.
196
TECHNICAL DATA

Weights (kg) 1.3 16V 95 HP Multijet 1.3 16V 95CV MultiJet Dualogic
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1305 / 1315(*)/ 1320(**)1305 / 1315(*)
Payload including the driver(****)540 / 575(**)545 / 540(*)
Maximum permitted loads(*****)
1050 1050 - front axle:
– rear axle: 1000 1000
- total:
1845 / 1855
(*)/ 1895(**)1850 / 1855(*)
Towable loads
1000 1000
– braked trailer:
– non-braked trailer: 400 400
Maximum load on roof: 60 60
Maximum load on ball joint (braked trailer): 60 60
(*) Cross versions
(**) PRO versions
(****) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation tothe maximum
permissible loads.
(*****) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted
loads.
197

Weights (kg) 1.6 16V 105 HP MultiJet 1.6 16V 120 HP Multijet Euro 5
Unladen weight (with all fluids, fuel tank 90% full and
without optional equipment):1365 / 1375(*)/ 1365(**)1370 / 1380(*)
Payload including the driver(***)560 / 550(*)/ 575(**)550
Maximum permitted loads
(****)
1050 1050 - front axle:
– rear axle: 1000 1000
- total:
1925 / 1940
(**)1920 / 1930(*)
Towable loads
1100 1100
– braked trailer:
– non-braked trailer: 400 400
Maximum load on roof: 60 60
Maximum load on ball joint (braked trailer): 60 60
(*) Cross versions
(**) PRO versions
(***) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases, thus reducing the specified payload in relation to the maximum
permissible loads.
(****) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitted
loads.
198
