IN AN EMERGENCY
132
❒ insert the electrical connector
6 fig. 108 into the 12V socket on
the vehicle and start the engine;
❒ turn on the compressor by pressing
the ON-OFF button 5 fig. 107.
When the pressure shown in the
"Wheels" paragraph in the
“Technical data” chapter or on the
specific label appears on the
pressure gauge 7, stop the
compressor by pressing the
ON-OFF button 5 again;
107DVDF0S0232
❒ disconnect the cartridge 1 from the
compressor by pressing the
release button 8 and lifting the
cartridge 1 up fig. 109.
108DVDF0S0231
109DVDF0S0233
If the pressure gauge 7 fig. 107 shows
a pressure less than 1.8 bar / 26 psi
15 minutes after turning on the
compressor, switch off the
compressor, disconnect the sealant
hose 4 from the tyre valve and remove
the cartridge 1 from the compressor
fig. 105.
Move the vehicle about 10m to
distribute the sealant; stop the vehicle
safely, engage the handbrake and
restore the pressure using the black
inflation hose 9 fig. 110 until the
required pressure is reached. If also in
this case, the pressure is lower than
1.8 bar / 26 psi 15 minutes after
turning on, do not resume driving but
contact a Fiat Dealership.
110DVDF0S0235

165
TECHNICAL DATA
IDENTIFICATION
DATA
VIN PLATE
The plate can be found on the left side
of the boot floor and it bears the
following identification data fig. 148:
A Name of Manufacturer
B Type-approval number.
C Vehicle type identification code.
D Chassis manufacture number.
E Maximum authorised weight of
vehicle when fully laden plus trailer.F Maximum authorised weight of
vehicle when fully laden plus trailer.
G Maximum authorised weight on first
axle (front).
H Maximum authorised weight on
second axle (rear).
I Engine type.
L Bodywork version code.
M Spare part number.
N Smoke opacity index (for diesel
engines).
148DVDF0S0209c
BODY PAINTWORK
IDENTIFICATION PLATE
This can be found on the external rear
door pillar (left-hand side) and it bears
the following information fig. 149:
A Paint manufacturer.
B Colour name.
C Fiat colour code.
D Respray and touch up code.
149DVDF0S0134c

TECHNICAL DATA
166
CHASSIS MARKING
The plate can be found on the right side
of the boot floor and it bears the
following identification data fig. 150:
❒ vehicle model;
❒ the chassis progressive number.
150DVDF0S0135c
ENGINE MARKING
It is stamped on the cylinder block and
includes the type and the engine serial
number.

TECHNICAL DATA
168
GENERAL0.9TwinAir 60 HP (*)0.9TwinAir 80 HP (*)
Engine code 312A6000 312A5000
Cycle Otto Otto
Number of cylinders and position 2 straight 2 straight
Piston diameter and stroke (mm) 83.5 x 88 83.5 x 88
Total capacity (cm3
) 964 875
Compression ratio 11.1 : 1 10 ± 02 : 1
Maximum power (EEC) (kW) 44 59
Maximum power (EEC) (HP) 60 80
corresponding engine speed (rpm) 6250 5500
Maximum torque (EEC) (Nm) 88 145
Maximum torque (EEC) (kgm) 8.9 14.8
corresponding engine speed (rpm) 3500 1900
Spark plugs NGK T20182U NGK LKR9CI-8 oppure NGK PLKR9C8
Fuel
95 RON unleaded petrol
(EN228 specifications)95 RON unleaded petrol
(EN228 specifications)
(*) For versions/markets, where provided

TECHNICAL DATA
170
GENERAL1.3 16V
Multijet 95 HP
EURO 51.3 16V
Multijet 95 HP
EURO 61.3 16V
Multijet 78 HP
EURO 6
Engine code 199B1000 312B1000 312B5000
Cycle Diesel Diesel Diesel
Number and position of cylinders 4 straight 4 straight 4 straight
Piston diameter and stroke (mm) 69.6 x 82 69.6 x 82 69.6 x 82
Total capacity (cm3
) 1248 1248 1248
Compression ratio 16.8 : 1 16.8 : 1 16.8 : 1
Maximum power (EEC) (kW) 70 70 57.3
Maximum power (EEC) (HP) 95 95 78
corresponding engine speed (rpm) 4000 4000 3750
Maximum torque (EEC) (Nm) 200 200 200
Maximum torque (EEC) (kgm) 20.4 20.4 20.4
Corresponding engine speed (rpm) 1500 1500 1500
Fuel
Diesel for motor
vehicles
(EN590 specifications)Diesel for motor
vehicles
(EN590 specifications)Diesel for
motor vehicles
(EN590 specifications)
(*) For versions/markets, where provided

TECHNICAL DATA
172
0.9 TwinAir 60 HP 5½Jx14H2-ET35 175/65 R14 82T 175/65 R14 82Q (M+S)
5½Jx14H2-ET35 175/65 R14 86T 175/65 R14 82Q (M+S)
4.00Bx14 ET43 135x80 R14 84M
6Jx15H2-ET35  185/55 R15 82H  185/55 R15 82Q (M+S)
6½Jx16H2-ET35  195/45 R16 84H  195/45 R16 84Q (M+S)
0.9 TwinAir 65 HP 5½Jx14H2-ET35 175/65 R14 82 T 175/65 R14 82Q (M+S)
5½Jx14H2-ET35 175/65 R14 82 T 175/65 R14 82Q (M+S)
4.00Bx14 ET43 135x80 R14 84M
0.9 TwinAir 80 HP 6Jx15H2-ET35  185/55 R15 82H  185/55 R15 82Q (M+S) 4.00Bx14 ET43 135x80 R14 84P
0.9 TwinAir 85 HP 6½Jx16H2-ET35  195/45 R16 84H  195/45 R16 84Q (M+S) 4.00Bx14 ET43 135x80 R14 80P (*)
0.9 TwinAir105 HP 6Jx15H2-ET35  185/55 R15 82H  185/55 R15 82Q (M+S) 4.00Bx14 ET43 135x80 R14 84P
6½Jx16H2-ET35  195/45 R16 84H  195/45 R16 84Q (M+S) 4.00Bx14 ET43 135x80 B14 80P
VersionsRimsTyres
providedSnow
tyresSpace-saver wheel
WHEELS 30) 32) 39) 43) 15)
RimTyre
4.00Bx14 ET43 135x80 B14 84M4.00Bx14 ET43 135x80 B14 84M (**)
For versions/markets, where provided  Alloy rim  Not suitable for snow chains
(*) For 0.9 TwinAir 80 HP versions only (**) Excluding 0.9 TwinAir 80 HP version
RIMS AND TYRES
Alloy or pressed steel rims. Tubeless radial carcass tyres. All approved tyres are listed in the Registration Document.
IMPORTANT In the event of discrepancies between the information provided in this Owner Handbook and the Log Book, the
latter takes precedence. For safe driving, the car must be fitted with tyres of the same make and type on all wheels.
IMPORTANT Do not use inner tubes with tubeless tyres.
WHEEL GEOMETRY
Total front toe-in 0.5 ± 1 mm The values refer to the car in running order.

TECHNICAL DATA
174
175/65 R14 82T/86T 2.4 (*) 2.2 (*) 2.4 (*)
2.2 (*)(1.2 ECO versions)
2.2 (**) 2.0 (**) 2.3 (**) 2.2 (**)
175/65 R14 82T 2.2 2.0 2.3
2.2
175/65 R14 86T 2.2 2.0 2.3 2.2 2.8
185/55 R15 82H 2.2 2.1 2.3 2.3
195/45 R16 84H 2.2 2.1 2.4 2.3
TyresMedium load (bar)
rearfront
Full load (bar)
rearfront
Space-saver
spare(bar)
(*) ECO
(**) COMFORT: ECO consumption is not guaranteed with comfort pressures
(
) For versions/markets, where provided
TYRE INFLATION PRESSURES 33) 39)
When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. However, recheck
that the value is correct with the tyre cold.
SNOW CHAINS 15)
The use of snow chains should be in compliance with local regulations of each country. Snow chains can be fitted to the
tyres of the front wheels (drive wheels) only. Check the tension of the snow chains after the first few metres have been
driven.
IMPORTANT Snow chains cannot be fitted to the space-saver spare wheel. If a front tyre is punctured, replace a rear wheel
with the space-saver wheel and move the rear wheel to the front axle. In this way, with two normal drive wheels at the front,
snow chains can be fitted.
