INSTRUMENT PANEL
KNOWING YOUR CAR
1a
A direction indicator stalk – B audio controls on steering wheel – C instrument panel – D headlight alignment corrector – E audio controls on
steering wheel – F windscreen wiper/washer and rear window wiper/washer stalk – G dualdrive power steering (CITY function)
H display: audio system/Uconnect™ – I central air diffusers – L fog lights/rear fog lights – M passenger airbag – N side air diffusers
O glove box – P emergency lights and switch – Q climate control system controls – R right electric window – S gear lever
T left electric window – U ASR-OFF button– V ignition switch – Z driver airbag – X steering wheel adjustment lever – W Cruise Control/Speed
Limiter lever
DVDF0S0219c

KNOWING YOUR CAR
8
DASHBOARD WITH SPORT STEERING WHEEL
1b
A direction indicator stalk – B audio controls on steering wheel – C instrument panel – D headlight alignment corrector – E audio controls on
steering wheel – F windscreen wiper/washer and rear window wiper/washer stalk – G dualdrive power steering (CITY function)
H display: audio system/Uconnect™ – I central air diffusers – L fog lights/rear fog lights – M passenger airbag – N side air diffusers
O glove box – P emergency lights and switch – Q climate control system controls – R right electric window – S gear lever
T left electric window – U ASR-OFF button– V ignition switch – Z driver airbag – X steering wheel adjustment lever – W Cruise Control/Speed
Limiter lever
DVDF0S0220c

KNOWING YOUR CAR
42
Emergency manoeuvre
If the switches fail, the soft top can be
moved manually proceeding as
described below:
❒ take the key provided and located in
the boot together with the tool box
or the Fix&Go kit;
❒ fit the wrench in the special housing
A-fig. 37 inside the luggage
compartment, under the parcel
shelf;
❒ turn in clockwise direction to open
the soft top and counter-clockwise
to close it.
37DVDF0S176c
Initialisation procedure
The soft top must be re-initialised after
disconnecting the battery or if the
relevant protection fuse is blown.
Proceed as follows:
❒ before carrying out any other
operation, make sure the engine is
on during the whole initialisation
procedure;
❒ keep the opening button A-fig. 34
pressed until the soft top is
completely open;
❒ when the soft top is completely
open, keep the button pressed for
at least 2 seconds;
❒ keep the closing button B-fig. 34
pressed until the soft top is
completely closed;
❒ when the soft top is completely
closed, keep the button B-fig. 34
pressed for at least 2 seconds.When the procedure is terminated, the
soft top will automatically carry out a
complete opening and closing cycle
(up to 25 cm from the completely
closed position) to inform the driver
that correct operation has been
restored.
Important notes
❒ The horizontal and vertical parts of
the soft top can be operated at any
speed lower than 100 and 80 km/h
respectively.
❒ The top can be operated at any
temperature in the range from
-18 to +80°C.
❒ It is recommended to have the
engine running always when
opening or closing the soft top.
❒ If required, remove the battery with
open or closed soft top, but NOT
when the soft top is moving.
❒ Do not fix a roof rack to the top and
do not travel with objects resting on
the open top.

141
NUMBER PLATE LIGHTS
To replace the bulbs, proceed as
follows:
❒ apply pressure to the point shown
by the arrow fig. 126 and remove
the lens;
❒ change the bulb, releasing it from
the side contacts;
❒ fit the new bulb and make sure that
it is correctly clamped between the
contacts;
❒ then refit the lens.
126DVDF0S0126c
REPLACING FUSES
35) 19)
DASHBOARD FUSES
To access the fuses you must remove
the press-fitted cover A-fig. 127.
127DVDF0S067c
The fuse box fig. 128 is located in the
lower area next to the pedal unit.
The 5A fuse for door mirror demisting
is located in the diagnostic socket area
fig. 129.
128DVDF0S068c
129DVDF0S069c

IN AN EMERGENCY
142
FuseAmpereDescription
F13 5 •
Left dipped headlight and headlight alignment control unit power supply
F36 15 Diagnosis socket, radio, climate control, EOBD
F37 5 Brake light switch, instrument panel node
F38 15 Central door locking
F43 15 Windscreen/rear window washer pump
F47 20 Driver’s side power window
F48 20 Passenger’s side power window
F49 5 Parking sensor, control backlighting, electric mirrors
F51 7.5 Climate control, brake lights, clutch, sunroof, electric mirrors
F53 5 Instrument panel node
•
For versions/markets, where provided
ENGINE COMPARTMENT
JUNCTION BOX
The fuse box is located on the right
side of the engine compartment.
To access the fuses, proceed as
follows:
❒ Fully press the screw A fig. 130;
❒ at the same time slowly rotate the
screw anticlockwise, until resistance
is encountered (do not overtighten);
❒ slowly release the screw;
❒ opening is indicated by the entire
screw head coming out of its
housing;
❒ remove cover B, sliding it upwards
on the side guides, as indicated in
the figure.
❒ after replacing the fuse, refit the
cover, making sure that it is closed
properly.
130DVDF0S0201c

143
LPG versions
The LPG system components are
protected by specific fuses.
Contact a Fiat Dealership for
replacement.
The number identifying the electrical
component corresponding to each
fuse is shown on the cover fig. 131.
FuseAmpereDescription
F02 20 Hi-Fi
F08 30 Climate control system fan
F09 30 Headlight washers
F10 10 Horns
F14 15 Main beam headlights
F15 20 Electric sunroof motor
F16 7.5 Dualogic gearbox control unit power supply
(+ignition)
F20 30 Heated rear window
F30 15 Fog lights
F84 10 Dualogic gearbox control unit
F85 20 Front power socket
(with or without cigar lighter)
131DVDF0S0202c

IMPORTANT INFORMATION AND RECOMMENDATIONS
198
PERSONAL SAFETY
(CONTINUED)
Do not use the jack for loads higher than the one shown on its
label. Never start the engine with vehicle raised. If the vehicle is
raised more than necessary, everything can become more
unstable, with the risk of the vehicle dropping violently.
Thus, lift the vehicle only as needed in order to access the
spare tyre.
33) FIX&GO QUICK TYRE REPAIR KIT
•The information required by the applicable regulation is
indicated on the Fix&Go kit package label. Carefully read the
label on the cartridge before use, avoid improper use. The kit
should be used by adults and cannot be used by children.
IMPORTANT: Do not exceed 80 km/h. Avoid sudden
acceleration or braking. The kit provides a temporary repair,
therefore the tyre must be examined and repaired by a
specialist as soon as possible. Before using the kit, ensure that
the tyre is not excessively damaged and that the rim is in good
condition, otherwise do not use it and call roadside assistance.
Do not remove foreign bodies from the tyre. Do not let the
compressor turned on for more than 20 consecutive minutes -
overheating hazard.
34) CHANGING A BULB
•Modifications or repairs to the electric system that are not
carried out properly or do not take the system technical
specifications into account can cause malfunctions leading to
the risk of fire.
•Halogen bulbs contain pressurised gas, in the case of
breakage they may burst causing glass fragments to be
projected outwards.
•Due to the high power supply voltage, gas discharge bulbs
(Xenon) should only be replaced by specialised personnel:
danger of death! Contact a Fiat Dealership.35) REPLACING FUSES
•If the replaced fuse blows again, contact a Fiat Dealership.
•Never replace a fuse with metal wires or anything else.
•Never replace a fuse with another with a higher amp rating; RISK
OF FIRE.
•If a general fuse (MEGA-FUSE, MIDI-FUSE,
MAXI-FUSE) blows contact a Fiat Dealership.
•Before replacing a fuse, make sure that the ignition key has
been removed and that all the other services are switched off
and/or disengaged.
•Contact Fiat Dealership if a safety system (airbags, brakes),
engine system
(engine, gearbox) or steering system general protection fuse
blows.
36) BATTERY RECHARGING
•Battery fluid is poisonous and corrosive:
avoid contact with your skin and eyes. The battery should be
charged in a well ventilated place, away from naked flames or
possible sources of sparks: danger of explosion and fire.
•Do not attempt to charge a frozen battery: it must be thawed
first, otherwise it may explode.
If freezing has occurred, the battery should be checked by skilled
personnel to make sure that the internal elements are not
damaged and that the body is not cracked, with the risk of leaking
poisonous and corrosive acid.
37) TOWING THE CAR
•Before tightening the ring clean the threaded housing thoroughly.
Make sure that the ring is fully fastened in the housing before
towing the car.
(CONTINUES)

205
VEHICLE SAFETY
(CONTINUES) (CONTINUED)
If the above indication occurs immediately after refuelling,
water may have entered the tank: turn the engine off
immediately and contact a Fiat Dealership.
19) BULBS AND FUSES
• Halogen bulbs must be handled holding the metallic part
only. Touching the transparent part of the bulb with your
fingers may reduce the intensity of the emitted light and even
compromise duration of the lamp. In the event of accidental
contact, wipe the bulb with a cloth moistened with alcohol and
let the bulb dry.
• Where possible, it is advisable to have bulbs changed at a
Fiat Dealership.
The correct operation and direction of the external lights are
absolutely essential for the safety of the car and of compliance
with the law.
• The intervention must be carried out taking all precautions
necessary to avoid damaging the bodywork (use a sufficiently
rigid and appropriately thick plastic card).
• If you need to wash the engine compartment, take care not
to directly hit the engine compartment fuse box
with the water jet.
20) LIFTING THE CAR
For versions equipped with side-skirts, pay particular attention
when positioning the lift arms at the workshop.
21) SCHEDULED SERVICING PLAN
• Petrol versions: If the vehicle is used mainly around town or
is driven less than 10,000 km annually, the engine oil and
engine oil filter must be changed every 12 months. • Diesel versions: If the car is used mainly for town driving, the
engine oil and filter should be changed every 12 months.
22) SERVICING: CHECKING LEVELS
• When topping up, take care not to mix up the various types of
fluids: they are not compatible with each other and could
seriously damage the car.
• Do not add oil with specifications other than those
of the oil already existing in the engine.
• The use of products with specifications other than those
indicated above could cause damage to the engine not covered
by the warranty.
• Prevent brake fluid, which is highly corrosive, from coming into
contact with painted parts while checking.
Should it happen, immediately wash with water.
23) PARAFLU
UP
PARAFLUUPanti-freeze is used in the engine cooling system.
Use the same fluid as in the cooling system when topping up.
PARAFLU
UPcannot be mixed with any other type of fluid.
If this occurs, do not start the engine and contact your Fiat
Dealership immediately.
24) BATTERY REPLACEMENT
Incorrect installation of electric and electronic devices may cause
severe damage to your car. After purchasing your vehicle, if you
wish to install any accessories (anti-theft, etc.), go to a Fiat
Dealership, which will suggest the most suitable devices and
advise you whether a higher capacity battery needs to be
installed.
