2017 TOYOTA TACOMA Owners Manual (in English)

1694-1. Before driving
4
Driving
Vehicle load limits
◆Total load capacity (vehicle capacity weight): →P. 569
Total load capacity means the comb ined weight of occupants, cargo
and luggage.
◆Seating capacity
Access Cab models
Vehicles without rear seats: 2 occupants
Vehicles with rear seats: 4 occupants (Front 2, Rear 2)
Double Cab models
5 occupants (Front 2, Rear 3)
Seating capacity means the maxi mum number of occupants whose
estimated average weight is 150 lb. (68 kg) per person.
Even if the number of occupants are within the seating capacity, do
not exceed the total load capacity.
◆TWR (Trailer Weight Rating): → P. 174
TWR means the maximum gross trailer weight (trailer weight plus
its cargo weight) that your vehicle is able to tow.
◆Cargo capacity
Cargo capacity may increase or decrease depending on the weight
and the number of occupants.
■Total load capacity and seating capacity
These details are also described on the tire and loading information label.
(→ P. 476)
Vehicle load limits include total load capacity, seating capacity,
TWR (Trailer Weight Rating) and cargo capacity.
WARNING
■Overloading the vehicle
Do not overload the vehicle.
It may not only cause damage to the tires, but also degrade steering
and braking ability, resu lting in an accident.

1704-1. Before driving
Trailer towing
Contact your Toyota dealer for further information about additional
requirements such as a towing kit, etc.
Your vehicle is designed primarily as a passenger-and-load-car-
rying vehicle. Towing a trailer can have an adverse impact on
handling, performance, braking, durability, and fuel consump-
tion. For your safety and the safe ty of others, you must not over-
load your vehicle or trailer. You must also ensure that you are
using appropriate towing equipmen t, that the towing equipment
has been installed correctly an d used properly, and that you
employ the requisite driving habits.
Vehicle-trailer stability and braking performance are affected by
trailer stability, brake performance and setting, trailer brakes,
the hitch and hitch systems (if equipped).
To tow a trailer safely, use extreme care and drive the vehicle in
accordance with your trailer’s characteristics and operating
conditions.
Toyota warranties do not appl y to damage or malfunction
caused by towing a trailer for commercial purposes.

1714-1. Before driving
4
Driving
■GCWR (Gross Combination Weight Rating)
The maximum allowable gross
combination weight. The gross
combination weight is the sum
of the total vehicle weight
(including the occupants, cargo
and any optional equipment
installed on the vehicle) and the
weight of the trailer being towed
(including the cargo in the
trailer).
■GVWR (Gross Vehicle Weight Rating)
The maximum allowable gross
vehicle weight. The gross vehi-
cle weight is the total weight of
the vehicle. When towing a
trailer, it is the sum of the vehi-
cle weight (including the occu-
pants, cargo and any optional
equipment installed on the vehi-
cle) and the tongue weight.
■GAWR (Gross Axle Weight Rating)
The maximum allowable gross
axle weight. The gross axle
weight is the load placed on
each axle (front and rear).
Towing related terms
Front GAWR
Rear GAWR

1724-1. Before driving
■TWR (Trailer Weight Rating)
The maximum allowable gross
trailer weight. The gross trailer
weight is the sum of the trailer
weight and the weight of the
cargo in the trailer.
TWR is calculated assuming
base vehicle with one driver,
one front passenger, towing
package (if available), hitch and
hitch systems (if required).
Additional optional equipment, passengers and cargo in the vehicle will
reduce the trailer weight rating so as not to exceed GCWR, GVWR and
GAWR.
If the gross trailer weight exceeds 3000 lb. (1360 kg), it is recommended
to use a trailer with 2 or more axles.
■
Unbraked TWR (Unbraked Trailer Weight Rating)
The trailer weight rating for tow-
ing a trailer without a trailer ser-
vice brake system.
■Tongue Weight
The load placed on the trailer
hitch ball. ( →P. 178)
(With brakes)
(Without brakes)

1734-1. Before driving
4
Driving
●The gross trailer weight must never exceed the TWR described in
the table. ( →P. 174)
● The gross combination weight must never exceed the GCWR
described in the table. ( →P. 174)
● The gross vehicle weight must never exceed the GVWR indicated
on the Certification Label.
● The gross axle weight on each axle must never exceed the GAWR
indicated on the Certification Label.
● If the gross trailer weight is over the unbraked TWR, trailer service
brakes are required.
● If the gross trailer weight is over 2000 lb. (907 kg), a sway control
device with sufficient capacity is required.
● If the gross trailer weight is over 5000 lb. (2268 kg), a weight distrib-
uting hitch with sufficient capacity is required.
Weight limits
Access Cab modelsDouble Cab models

1744-1. Before driving
Confirm that the gross trailer weight, gross combination weight, gross
vehicle weight, gross axle weight and tongue weight are all within the
limits.
■GCWR* and TWR*
Access Cab models
*1: The model code is indicated on the Certification Label. (→P. 571)
*2: Vehicles without a towing package
*3: Vehicles with a towing package
GCWR, TWR, Unbraked TWR, Fifth wheel and Gooseneck towing
TWR
*: These models meet the tow-vehicle trailering requirement of SAE International per SAE J2807.
Model code*1EngineDriving
systemGCWRTWR
TRN265L-CRTSKA 2TR-FE engine 2WD
7810 lb.
(3540 kg) 3500 lb.
(1590 kg)
TRN245L-CRMSKA 4WD8020 lb.
(3635 kg) 3500 lb.
(1590 kg)
TRN245L-CRTSKA 8050 lb.
(3650 kg) 3500 lb.
(1590 kg)
GRN325L-CRTSHA
2GR-FKS engine 2WD
7890 lb.
*2
(3590 kg) 3500 lb.*2
(1590 kg)
11310 lb.
*3
(5130 kg) 6800 lb.*3
(3085 kg)
GRN305L-CRFSHA 4WD8150 lb.
*2
(3695 kg) 3500 lb.*2
(1590 kg)
11280 lb.
*3
(5115 kg) 6500 lb.*3
(2950 kg)
GRN305L-CRTSHA 8130 lb.
*2
(3685 kg) 3500 lb.*2
(1590 kg)
11360 lb.
*2
(5150 kg) 6500 lb.*3
(2950 kg)

1754-1. Before driving
4
Driving
Double Cab models
Model code*1EngineDriving
systemGCWRTWR
TRN265L-PRTSKA 2TR-FE
engine
2WD7920 lb.
(3590 kg) 3500 lb.
(1590 kg)
GRN325L-PRTSHA
2GR-FKS engine 8010 lb.
*2
(3630 kg)
3500 lb.
*2
(1590 kg)
11330 lb.
*3
(5135 kg) 6700 lb.
*3
(3040 kg)
GRN325L-PRTLHA 8060 lb.
*2
(3655 kg)
3500 lb.
*2
(1590 kg)
11280 lb.
*3
(5115 kg) 6600 lb.
*3
(2995 kg)
GRN330L-PRTSHA 8060 lb.
*2
(3655 kg)
3500 lb.
*2
(1590 kg)
11280 lb.
*3
(5115 kg) 6600 lb.
*3
(2995 kg)
GRN330L-PRTLHA 8110 lb.
*2
(3670 kg)
3500 lb.
*2
(1590 kg)
11330 lb.
*3
(5135 kg) 6600 lb.
*3
(2995 kg)

1764-1. Before driving
*1: The model code is indicated on the Certification Label. (→P. 571)
*2: Vehicles without a towing package
*3: Vehicles with a towing package
■
Unbraked TWR*
1000 lb. (450 kg)
■Fifth wheel and gooseneck towing TWR*
Toyota does not recommend fifth wheel and gooseneck towing.
Model code*1EngineDriving
systemGCWRTWR
GRN305L-PRFSHA
2GR-FKS engine 4WD8270 lb.
*2
(3750 kg)
3500 lb.
*2
(1590 kg)
11300 lb.
*3
(5125 kg) 6400 lb.
*3
(2900 kg)
GRN305L-PRTSHA 8250 lb.
*2
(3740 kg)
3500 lb.
*2
(1590 kg)
11280 lb.
*3
(5115 kg) 6400 lb.
*3
(2900 kg)
GRN305L-PRTLHA 8310 lb.
*2
(3765 kg)
3500 lb.
*2
(1590 kg)
11330 lb.
*3
(5135 kg) 6400 lb.
*3
(2900 kg)
GRN310L-PRTSHA 8310 lb.
*2
(3765 kg)
3500 lb.
*2
(1590 kg)
11330 lb.
*3
(5135 kg) 6400 lb.
*3
(2900 kg)
GRN310L-PRTLHA 8360 lb.
*2
(3790 kg)
3500 lb.
*2
(1590 kg)
11090 lb.
*3
(5030 kg) 6000 lb.
*3
(2720 kg)
*: These models meet the tow-vehicle trailering requirement of SAE
International per SAE J2807.
