2017 TOYOTA TACOMA Owners Manual (in English)

617
10
For owners
■Cargo weight rating
NO.Engine
Transmissi on
DriveCabBedGrade
Pass
enge rV. C . W
Cargo
Weig ht
Ratin
g
lbslbs
12TR6AT
2WDAccess Long SR5 4 1,500
900
2 2TR 6AT Double Short SR5 5 1,400
650
3 2GR 6AT Access Long SR5 4 1,400
800
4 2GR 6AT Double Short SR5 5 1,200
450
5 2GR 6AT Double Short Limited 5 1,250
500
6 2GR 6AT Double Long SR5 5 1,200
450
7 2GR 6AT Double Long Limited 5 1,200
450
82TR5MT
4WDAccess Long SR5 4 1,350
750
9 2TR 6AT Access Long SR5 4 1,300
700
10 2GR 6MT Access Long SR5 4 1,100
500
11 2GR 6AT Access Long SR5 4 1,150
550
12 2GR 6MT Double Short SR5 5 950
200
13 2GR 6AT Double Short SR5 5 1,000
250
14 2GR 6AT Double Short Limited 5 1,000
250
15 2GR 6AT Double Long SR5 5 950
200
16 2GR 6AT Double Long Limited 5 950
200
WARNING
■ Overloading
Be careful — overloading can cause dangerous braking and handling
problems, and can damage your vehicle and its tires.

618
Secure loose items to prevent weight shifts that could affect the
balance of your vehicle. When the truck camper is loaded, drive to a
scale and weigh on the front and on the rear wheels separately to
determine axle loads. Individual axle loads should not exceed either
of the Gross Axle Weight Ratings (GAWR). The total of the axle loads
should not exceed the Gross Vehi cle Weight Rating (GVWR). These
ratings are given on the vehicle certification label wh ich is located on
the door latch post on the left side of the vehicle. (→P. 571) If weight
ratings are exceeded, move or remove items to bring all weights
below the ratings.
Gross axle weight rating
Front GAWR
Rear GAWR
Gross vehicle weight rating
Not exceed GVWR
Gross axle and vehicle weight ratings
1
2
1

619
10
For owners
■GAWR and GVWR
*:The model code is indicated on the Certification Label. (→P. 5 7 1)
Model code*GAWRGVWRFrontRear
Except GRN310L-PRTSHA/
GRN310L-PRTLHA
2910 lb.
(1320 kg)
3280 lb.
(1490 kg)5600 lb.
(2545 kg)
GRN310L-PRTSHA/
GRN310L-PRTLHA
3040 lb.
(1380 kg)

620

621
Index
What to do if... (Troubleshooting) .................... 622
Alphabetical index ..................... 626
For vehicles with Entune Audio Plus or Entune Premium Audio,
refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL” for information regarding the multimedia
system.
Audio system types: →P. 284

622What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine mechanical keys
can be made by your Toyota dealer. ( →P. 105)
●If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact your Toyota dealer immediately. (→P. 108)
●Is the key battery weak or depleted? ( →P. 485)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( →P. 193)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. ( →P. 124)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 1 1 3 )
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened (Double Cab models only)

623What to do if... (Troubleshooting)
●Vehicles with an automatic transmission:
Is the shift lever in P? (→P. 189)
●Vehicles with a manual transmission:
Do you turn the key with the clutch pedal depressed firmly? ( →P. 189)
●Is the battery discharged? (→P. 559)
●Did you press the engine switch while firmly depressing the brake pedal?
(→P. 192)
●Is the shift lever in P? ( →P. 194)
●Is the electronic key anywhere detectable inside the vehicle? ( →P. 122)
●Is the steering wheel unlocked? (→P. 194)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. (→P. 557)
●Is the battery discharged? (→P. 559)
●Vehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. ( →P. 200)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( →P. 200)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)
The shift lever cannot be shifted from P even if you depress
the brake pedal (vehicles with an automatic transmission)

624What to do if... (Troubleshooting)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. (→P. 190)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( →P. 195)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( →P. 145)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( →P. 194)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( →P. 516)
●The parking brake indicator is on
Is the parking brake released? (→P. 205)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 516, 529)
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. ( →P. 523)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is turned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
