2017 Lexus GX460 Navigation Manual

191
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
No.Function
Select to display the audio source selection screen.
•Displays cover art
• Select to display a track/file list.
•Audio CD: Select to display a track list.
• MP3/WMA/AAC disc: Select to display a folder list. To return to the top screen, select
“Now Playing” on the list screen.
Select to display the sound setting screen.
Select to display the audio setting screen.
Select to set random playback.
Select to set repeat playback.
Shows progress.
Select to play/pause.
Select to select a folder.
•Turn to select a track/file.
• Turn to move the cursor up/down on the list.
• Press to select the list.
•Press to select a track/file.
• Press and hold to fast forward/rewind.
•Turn to adjust volume.
• Press to turn the audio system on/off.
• Press and hold to restart the audio system.
Press to eject a disc.
Disc slot
GX_Navi_OM60N98U_(U).book Page 191 Monday, May 30, 2016 2:28 PM

192
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
INFORMATION
●
If a disc contains CD-DA files and MP3/WMA/AAC files, only the CD-DA files can be
played back.
●If a CD-TEXT disc is inserted, the title of the di sc and track will be displayed. Up to 32 char-
acters can be displayed.
GX_Navi_OM60N98U_(U).book Page 192 Monday, May 30, 2016 2:28 PM

193
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat
→ off
1Select .
zEach time is selected, the mode
changes as follows:
•random (1 disc random)
→ off
PLAYING AN AUDIO CD
REPEATING
The track currently being listened to can
be repeated.
INFORMATION
●
When is selected, “RPT” appears
on the screen.
RANDOM ORDER
Tracks can be automatically and ran-
domly selected.
INFORMATION
●
When is selected, “RAND”
appears on the screen.
GX_Navi_OM60N98U_(U).book Page 193 Monday, May 30, 2016 2:28 PM

194
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
1Select .
zEach time is selected, the mode
changes as follows:
X When random playback is off
• file repeat → folder repeat → off
XWhen random playback is on
• file repeat → off
1Select .
zEach time is selected, the mode
changes as follows:
•random (1 folder random)
→ folder random (1 disc random) → off
PLAYING AN MP3/WMA/
AAC DISC
REPEATING
The file or folder currently being listened
to can be repeated.
INFORMATION
●
Each time is selected, “RPT”/
“FLD.RPT” appears on the screen.
RANDOM ORDER
Files or folders can be automatically and
randomly selected.
INFORMATION
●
Each time is selected, “RAND”/
“FLD.RAND” appears on the screen.
GX_Navi_OM60N98U_(U).book Page 194 Monday, May 30, 2016 2:28 PM

195
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
2. DVD
For safety reasons, the DVD video discs can only be viewed when the following con-
ditions are met:
(a) The vehicle is completely stopped.
(b) The engine switch is in ACCESSORY or IGNITION ON mode.
(c) The parking brake is applied.
While driving in DVD video mode, only the DVD’s audio can be heard.
The playback condition of some DVD discs may be determined by the DVD software
producer. This DVD player plays a disc as the software producer intended. As such,
some functions may not work properly. Be sure to read the instruction manual that
comes with the individual DVD disc. ( →P.268)
OVERVIEW
The DVD operation screen can be reached by the following methods:
XInserting a disc ( →P.162)
Press the “A U D I O ” button to display the audio control screen.
Select “Source” and select “DISC”.
GX_Navi_OM60N98U_(U).book Page 195 Monday, May 30, 2016 2:28 PM

196
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
■CONTROL SCREEN
■ CONTROL PANEL
GX_Navi_OM60N98U_(U).book Page 196 Monday, May 30, 2016 2:28 PM

197
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
4
AUDIO/VISUAL SYSTEM
No.Function
Select to display the audio source selection screen.
Select to display the password input screen.
Select to display the menu screen.
Select to display the option screen. (→P.199)
Select to display the sound setting screen.
Select to display the DVD setting screen.
Shows progress
•During playback: Select to fast forward.
• During a pause: Select to slow forward.
Select to play/pause.
Select to stop the video screen.
Select to rewind.
Select to display th e menu control key.
Select to display full screen video.
Turn to select a chapter.
•Press to select a chapter.
• Press and hold to fast forward/rewind.
•Turn to adjust volume.
• Press to turn the audio system on/off.
• Press and hold to restart the audio system.
Press to eject a disc.
Disc slot
GX_Navi_OM60N98U_(U).book Page 197 Monday, May 30, 2016 2:28 PM

198
3. MEDIA OPERATION
GX460_Navi_OM60N98U_(U)16.05.30 14:27
CAUTION
●Conversational speech on some DVDs is recorded at a low volume to emphasize the
impact of sound effects. If you adjust the volume assuming that the conversations represent
the maximum volume level that the DVD will play, you may be startled by louder sound
effects or when you change to a different audio source. The louder sounds may have a sig-
nificant impact on the human body or pose a driving hazard. Keep this in mind when you
adjust the volume.
INFORMATION
●
According to the DVD disc, some menu items ca n be selected directly. (For details, see the
manual that comes with the DVD disc provided separately.)
●If appears on the screen when a control is selected, the operation relevant to the control
is not permitted.
GX_Navi_OM60N98U_(U).book Page 198 Monday, May 30, 2016 2:28 PM
