2017 Citroen GRAND C4 PICASSO Owner's Manual

287
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
This kit is installed in the storage box, under the
boot floor.This kit consists of a compressor and a sealant cartridge.
It allows the temporary repair
of a tyre.
You are then able to go to the nearest garage.
It is designed to repair most punctures which could affect the tyre, located on the tyre tread or
shoulder.
Its compressor can be used to check and adjust the pressure of the tyre.
Temporary puncture repair kit
Access to the kit
Depending on version, the kit is stowed under
the front passenger's seat or in the storage box
under the second row footwell.
List of tools
* Depending on equipment. All of these tools are specific to your vehicle
and can vary depending on equipment. Do not
use them for other purposes.
1.
1

2 V compressor.
C

ontains a sealant cartridge for the
temporary repair of a tyre and can also be
used for adjusting tyre pressures.
2.
C
hocks* to immobilise the wheels of the
vehicle.
3.
W
heel bolt cover remover*.
F

or removing the wheel bolt covers on alloy
wheels.
4.
R
emovable towing eye and front protective
cover opening tool.
For more information on To w i n g , refer to the
corresponding section.
8
In the event of a breakdown

288
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
A. "Sealant" or "Air" position selector.
B. On "I" / off "O" switch.
C.
D

eflation button.
D.
P

ressure gauge (in bars and psi).
Description of the kit
The speed limit sticker H must be
affixed to the vehicle's steering wheel
to remind you that a wheel is in
temporary use.
Do not exceed a speed of 50 mph
(80
km/h) when driving with a tyre
repaired using this type of kit.
E.
C

ompartment housing a cable with an
adaptor for a 12 V socket.
F.
S

ealant cartridge.
G.
W

hite pipe with cap for repair and inflation.
H.
S

peed limit sticker.
The tyre inflation pressures are given on this
label.
Only the 12 V socket at the front of
the vehicle allows the connection of the
compressor for long enough to repair or
inflate a tyre.
The other 12 V sockets in the vehicle
are not suited to the use of the
compressor.
In the event of a breakdown

289
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
1. Sealing
Repair procedure
Avoid removing any foreign bodies
which have penetrated into the tyre.F

U
ncoil the white pipe G fully.
F
U
nscrew the cap from the white pipe.
F
C
onnect the white pipe to the valve of the
tyre to be repaired.
F

S

witch off the ignition.
F
T
urn the selector A to the
"sealant" position. F
C
onnect the compressor's electric plug to
the vehicle's 12 V socket.
F
S
tart the vehicle and leave the engine
running.Take care, this product is harmful if
swallowed and causes irritation to the eyes.
Keep this product out of the reach of
children.Do not start the compressor before
connecting the white pipe to the tyre
valve: the sealant product would be
expelled through the pipe.
F

C

heck that the switch B is in position "O"
.
8
In the event of a breakdown

290
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
F Switch on the compressor by moving the switch B to position "I" until the tyre
pressure reaches 2.0 bars.
T

he sealant is injected into the tyre under
pressure; do not disconnect the pipe from
the valve during this operation (risk of
splashing).
If after around 5 to 7 minutes the
pressure is not attained, this indicates
that the tyre is not repairable; contact
a CITROËN dealer or a qualified
workshop for assistance. F
R emove the kit and screw the cap back on
the white pipe.
T

ake care to avoid staining your vehicle
with traces of fluid. Keep the kit to hand.
F

D
rive immediately for approximately
three miles (five kilometres), at reduced
speed (between 12 and 37 mph (20 and
60
km/h)), to plug the puncture.
F

S
top to check the repair and the tyre
pressure using the kit.
Tyre under-inflation detection
After repair of the tyre, the warning
lamp will remain on until the system is
reinitialised.
For more information on Under-
inflation detection , refer to the
corresponding section.
In the event of a breakdown

291
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
2. Inflation
F Turn the selector A to the "Air" position. F
C onnect the compressor's electric plug to
the vehicle's 12 V socket.
F

S
tart the vehicle again and leave the
engine running.
As soon as possible, go to a CITROËN
dealer or a qualified workshop.
You must inform the technician that you
have used this kit. After inspection, the
technician will advise you on whether
the tyre can be repaired or if it must be
replaced. F
A djust the pressure using the compressor
(to inflate: switch B in position "I" ; to
deflate: switch B
in position "O" and press
button C ), in accordance with the vehicle's
tyre pressure label (located on the left-
hand door aperture).
A l

oss of pressure indicates that the
puncture has not been fully plugged;
contact a CITROËN dealer or qualified
workshop for assistance.
F

R
emove and stow the kit.
F

D
rive at reduced speed (50 mph [80 km/h]
max) limiting the distance travelled to
approximately 120 miles (200 km).
F

U

ncoil the white pipe G fully.
F

C

onnect the white pipe to the tyre valve.
8
In the event of a breakdown

292
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
Removing the pipe and cartridge
F Turn the pipe assembly 2 to the left until it contacts the unit.
F

D
isconnect the union 1 from the cartridge
by turning it a quarter turn anti-clockwise.
F

E
xtract the pipe assembly 2 , then
disconnect the union 3 from the air
delivery
pipe by turning it a quarter turn
anti-clockwise.
F

R
emove the pipe assembly 2 .
F

S
upport the compressor vertically.
F

U
nscrew the cartridge 4 from the bottom.
To fit the new cartridge and new pipe, carry out
these operations in reverse order. Beware of discharges of fluid.
The expiry date of the fluid is indicated
on the cartridge.
The sealant cartridge is designed for
single use; even if only partly used, it
must be replaced.
After use, do not discard the cartridge
into the environment, take it to an
authorised waste disposal site or a
CITROËN dealer.
Do not forget to obtain a new sealant
cartridge, available from CITROËN
dealers or from a qualified workshop.
In the event of a breakdown

293
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
Checking / adjusting tyre pressures
You can also use the compressor without
injecting any product, to check and if necessary
adjust your tyre pressures.
F
T
urn the selector A to the "Air"
position.
F

U
ncoil the white pipe G fully.
F

C
onnect the pipe to the tyre
valve. F
C onnect the compressor's electrical
connector to the vehicle's 12 V socket.
F

S
tart the vehicle and let the engine run.
F

A
djust the pressure using the compressor
(to inflate: switch B in position "I" ; to
deflate: switch B in position "O" and press
button C ), according to the vehicle's tyre
pressure label.
F

R
emove the kit then stow it.Should the pressure of one or more
tyres be adjusted, it is necessary to
reinitialise the under-inflation detection
system.
For more information on Under-
inflation detection
, refer to the
corresponding section.
8
In the event of a breakdown

294
C4-Picasso-II_en_Chap08_en-cas-panne_ed02-2016
Spare wheel
The tools are installed in the boot under the
f l o o r.
Remove the boot carpet for access to them.
Access to the tools
List of tools*
Procedure for changing a wheel with a punctured tyre for the spare wheel using the tools provided with the vehicle.All of these tools are specific to your
vehicle and can vary according to the level
of equipment. Do not use them for other
purposes.
1.
W

heelbrace.
F

or removing the wheel trim and removing
the wheel bolts.
2.
C

hock for immobilising the vehicle (except
versions with manual gearbox).
3.
J

ack with integral handle.
F

or raising the vehicle.
4.
W

heel bolt cover remover.
F

or removing the wheel bolt covers on alloy
wheels.
5.
S

ocket for the security bolts (located in the
glove box).
F

or adapting the wheelbrace to the special
"security" bolts.
6.
T

owing eye and front protective cover
opening tool.
For more information about To w i n g , refer to
the corresponding section.
* Depending on equipment.
