2016 TOYOTA PRIUS V display

254
PRIUS v_OM_OM47B12U_(U)
4-5. Using the driving support systems
■Changing the alert timing of the pre-collision system
Each time the PCS switch is
pressed, the response to the
distance changes as follows.
Far
Middle
*
Near
*: Default setting
■
Turning off the pre-collision system
Press the PCS switch for 3 sec-
onds or more seconds.
The PCS warning light turns on
and a message is shown on the
multi-information display.
To turn on the system, press the
PCS switch again. The system
is set to ON each time the power
switch is turned to ON mode.
Changing the pre-collision system
1
2
3

PRIUS v_OM_OM47B12U_(U)
2574-5. Using the driving support systems
4
Driving
■Automatic cancelation of the pre-collision system
When a malfunction occurs due to sensor contamination, etc. that results in
the sensors being unable to detect obstacles, the pre-collision system will be
automatically disabled. In this case, the system will not activate even if there
is a collision possibility.
■When there is a malfunction in the system, or if the system is tempo-
rarily unusable
The PCS warning light flashes and a warning message is shown on the multi-
information display. If a warning message is shown on the multi-information
display, read the message and follow the instructions. (P. 490, 503)
■Certification for the pre-collision system
For vehicles sold in the U.S.A.
For vehicles sold in Canada

266
PRIUS v_OM_OM47B12U_(U)
5-1. Basic OperationsAudio system types .......... 268
Audio system .................... 269
Using the steering wheel audio switches ................ 272
AUX Port/USB Port .......... 273
Basic audio operations ..... 274
5-2. Setup Setup menu ...................... 276
General settings ............... 277
Audio settings ................... 279
Display settings ................ 281
Voice settings ................... 284
5-3. Using the Multimedia system
Selecting the audio source............................. 285
List screen operation ........ 286
Optimal use of the audio system ............................ 288
Audio screen adjustment ...................... 289
5-4. Using the radio Radio operation ................ 290
5Audio system

267
PRIUS v_OM_OM47B12U_(U)
5Audio system
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation.......... 292
5-6. Using an external device
Listening to an iPod .......... 298
Listening to a USB
memory device ............... 303
Using the AUX .................. 308
VTR .................................. 309
5-7. Connecting Bluetooth
®
Preparations to
use wireless
communication ............... 310
Registering a Bluetooth
®
audio player for the
first time .......................... 313
Registering a Bluetooth
®
phone for the first time.... 314
Registering a
Bluetooth
® device ........... 315
Connecting a
Bluetooth
® device ........... 317
Displaying a Bluetooth®
device details.................. 319
Detailed Bluetooth
®
system settings............... 320
5-8. Bluetooth
® Audio
Listening to Bluetooth®
Audio .............................. 3215-9. Bluetooth
® phone
Using a Bluetooth®
Phone ............................. 323
Making a call .................... 326
Receiving a call ................ 329
Speaking on the phone .... 330
Bluetooth
® phone
message function ........... 333
Using the steering wheel
switches.......................... 337
Bluetooth
® phone
settings ........................... 338
Contact/Call History
Settings .......................... 339
What to do if...
(Troubleshooting) ........... 348
5-10. Bluetooth
®
Bluetooth®........................ 352
5-11. Using the voice
command system
Voice command system ... 358

269
PRIUS v_OM_OM47B12U_(U)
5-1. Basic Operations
5
Audio system
Audio system
“AUDIO” button
Display the “Select Audio Source” screen or audio top screen.
(P. 285)
“SETUP” button
Press this button to customize the function settings. (P. 276)
“CAR” button
Press this button to access the vehicle information. (P. 108)
button
Press this button to access the Bluetooth
® hands-free system.
(P. 323)
: If equipped
Operations such as listening to audio, using the hands-free
phone, confirming vehicle information and changing audio sys-
tem settings are started by using the following buttons.
Audio system operation buttons
1
2
3
4

PRIUS v_OM_OM47B12U_(U)
2715-1. Basic Operations
5
Audio system
■When using the touch screen
●If the screen is cold, the display may be dark, or the system may seem to be
operating slightly slower than normal.
●The screen may seem dark and hard to see when viewed through sun-
glasses. Change your angle of viewing, adjust the display on the “Display
Settings” screen (P. 281) or remove your sunglasses.
●Flick operations may not be performed smoothly in high altitudes.
NOTICE
■To avoid damaging the touch screen
●To prevent damaging the screen, lightly touch the screen buttons with your
finger.
●Do not use objects other than your finger to touch the screen.
●Wipe off fingerprints using a glass cleaning cloth. Do not use chemical
cleaners to clean the screen, as they may damage the touch screen.

274
PRIUS v_OM_OM47B12U_(U)
5-1. Basic Operations
Basic audio operations
Press this knob to turn the audio system on and off, and turn it to
adjust the volume.
Insert a disc into the disc slot.
Turn this knob to select radio station bands, tracks and files. Also
the knob can be used to select items in the list display.
Press to pause or resume playing music.
Press the “” or “” button to seek up or down for a radio station, or
to access a desired track or file.
: Select to pause music.
: Select to resume playing music.
Press this button to eject a disc.
Basic audio operations and functions common to each mode are
explained in this section.
Operating the audio system
1
2
3
4
5
6
7

276
PRIUS v_OM_OM47B12U_(U)
5-2. Setup
Setup menu
Press the “SETUP” button to display the “Setup” screen.
Select to adjust the settings for
operation sounds, screen ani-
mation, etc. (P. 277)
Select to set the voice settings.
(P. 284)
Select to adjust the settings for
contrast and brightness of the
screen. (P. 281)
Select to adjust the settings for registering, removing, connecting
and disconnecting Bluetooth
® devices. (P. 312)
Select to adjust the settings for contact, message, etc. (P. 338)
Select to set audio settings. (P. 279)
Select to turn the screen off.
Select to set the vehicle customization. (P. 575)
You can adjust the audio system to your desired settings.
Display “Setup” screen
1
2
3
4
5
6
7
8
