2016 TOYOTA PRIUS V CD player

TABLE OF CONTENTS4
PRIUS v_OM_OM47B12U_(U)5-1. Basic Operations
Audio system types .......... 268
Audio system .................... 269
Using the steering wheel
audio switches ................ 272
AUX Port/USB Port........... 273
Basic audio operations ..... 274
5-2. Setup
Setup menu ...................... 276
General settings ............... 277
Audio settings ................... 279
Display settings ................ 281
Voice settings ................... 284
5-3. Using the Multimedia
system
Selecting the audio
source ............................. 285
List screen operation ........ 286
Optimal use of the audio
system ............................ 288
Audio screen
adjustment ...................... 2895-4. Using the radio
Radio operation................. 290
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation .......... 292
5-6. Using an external device
Listening to an iPod .......... 298
Listening to a USB
memory device ............... 303
Using the AUX .................. 308
VTR ................................... 309
5-7. Connecting Bluetooth
®
Preparations to
use wireless
communication ................ 310
Registering a Bluetooth
®
audio player for the
first time .......................... 313
Registering a Bluetooth
®
phone for the first time .... 314
Registering a
Bluetooth
® device ........... 315
Connecting a
Bluetooth
® device ........... 317
Displaying a Bluetooth®
device details .................. 319
Detailed Bluetooth
®
system settings ............... 320
5-8. Bluetooth
® Audio
Listening to Bluetooth®
Audio............................... 321
5Audio system

471-1. For safe use
PRIUS v_OM_OM47B12U_(U)
1
For safety and security
WARNING
■SRS airbag precautions
●If breathing becomes difficult after the SRS airbags have deployed, open a
door or window to allow fresh air in, or leave the vehicle if it is safe to do
so. Wash off any residue as soon as possible to prevent skin irritation.
●If the areas where the SRS airbags are stored, such as the steering wheel
pad and front and rear pillar garnishes, are damaged or cracked, have
them replaced by your Toyota dealer.
●Do not place anything, such as a cushion, on the front passenger’s seat.
Doing so will disperse the passenger’s weight, which prevents the sensor
from detecting the passenger’s weight properly. As a result, the SRS front
airbags for the front passenger may not deploy in the event of a collision.
■Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications
without consulting your Toyota dealer. The SRS airbags may malfunction or
deploy (inflate) accidentally, causing death or serious injury.
●Installation, removal, disassembly and repair of the SRS airbags
●Repairs, modifications, removal or replacement of the steering wheel,
instrument panel, dashboard, seats or seat upholstery, front, side and rear
pillars or roof side rails
●Repairs or modifications of the front fender, front bumper, or side of the
occupant compartment
●Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows or
winches
●Modifications to the vehicle’s suspension system
●Installation of electronic devices such as mobile two-way radios and CD
players
●Modifications to your vehicle for a person with a physical disability

PRIUS v_OM_OM47B12U_(U)
1333-2. Opening, closing and locking the doors
3
Operation of each component
■Conditions affecting operation
The smart key system, wireless remote control and immobilizer system use
weak radio waves. In the following situations, the communication between
the electronic key and the vehicle may be affected, preventing the smart key
system, wireless remote control and immobilizer system from operating prop-
erly.
(Ways of coping: P. 536)
●When the electronic key battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise
●When carrying a portable radio, cellular phone, cordless phone or other
wireless communication devices
●When the electronic key is in contact with, or is covered by the following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When other wireless key (that emit radio waves) is being used nearby
●When carrying the electronic key together with the following devices that
emit radio waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
●If window tint with a metallic content or metallic objects are attached to the
rear window

267
PRIUS v_OM_OM47B12U_(U)
5Audio system
5-5. Playing an audio CD and
MP3/WMA/AAC discs
CD player operation.......... 292
5-6. Using an external device
Listening to an iPod .......... 298
Listening to a USB
memory device ............... 303
Using the AUX .................. 308
VTR .................................. 309
5-7. Connecting Bluetooth
®
Preparations to
use wireless
communication ............... 310
Registering a Bluetooth
®
audio player for the
first time .......................... 313
Registering a Bluetooth
®
phone for the first time.... 314
Registering a
Bluetooth
® device ........... 315
Connecting a
Bluetooth
® device ........... 317
Displaying a Bluetooth®
device details.................. 319
Detailed Bluetooth
®
system settings............... 320
5-8. Bluetooth
® Audio
Listening to Bluetooth®
Audio .............................. 3215-9. Bluetooth
® phone
Using a Bluetooth®
Phone ............................. 323
Making a call .................... 326
Receiving a call ................ 329
Speaking on the phone .... 330
Bluetooth
® phone
message function ........... 333
Using the steering wheel
switches.......................... 337
Bluetooth
® phone
settings ........................... 338
Contact/Call History
Settings .......................... 339
What to do if...
(Troubleshooting) ........... 348
5-10. Bluetooth
®
Bluetooth®........................ 352
5-11. Using the voice
command system
Voice command system ... 358

273
PRIUS v_OM_OM47B12U_(U)
5-1. Basic Operations
5
Audio system
AUX Por t/USB Por t
■iPod
Open the cover and connect an
iPod using an iPod cable.
Turn on the power of the iPod if
it is not turned on.
■
USB memory
Open the cover and connect the USB memory device.
Turn on the power of the USB memory device if it is not turned on.
■
Portable audio player
Open the cover and connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
Connect an iPod, USB memory device or portable audio player
to the AUX port/USB port as indicated below. Select “iPod”,
“USB”, “AUX” or “A/V” on the audio source selection screen
and the device can be operated via audio system.
Connecting the AUX port/USB port
WARNING
■While driving
Do not connect a device or operate the device controls.

292
PRIUS v_OM_OM47B12U_(U)
5-5. Playing an audio CD and MP3/WMA/AAC discs
CD player operation
Pressing the “AUDIO” button displays the audio control screen from
any screens of the selected source.
Audio source selection screen
appears
Displaying the track/file list
Random playback (
P. 275)
Repeat play (
P. 275)
Pause
Select to resume play.
Setting the sound (
P. 288)
Insert disc or select “CD” on the audio source selection screen
with a disc inserted to begin listening to a CD.
Audio control screen
1
2
3
4
5
6

PRIUS v_OM_OM47B12U_(U)
2935-5. Playing an audio CD and MP3/WMA/AAC discs
5
Audio system
■Displaying the title and artist name
If a CD-TEXT disc is inserted, the title of the disc and track will be displayed.
■Error messages
If an error message is displayed, refer to the following table and take the
appropriate measures. If the problem is not rectified, take the vehicle to your
Toyota dealer.
■Discs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc fea-
tures, or due to scratches, dirt or deterioration.
CDs with copy-protection features may not play correctly.
■CD player protection feature
To protect the internal components, playback is automatically stopped when a
problem is detected.
■If a disc is left inside the CD player or in the ejected position for
extended periods
Disc may be damaged and may not play properly.
■Lens cleaners
Do not use lens cleaners. Doing so may damage the CD player.
MessageCauseCorrection procedures
“Check DISC”• The disc is dirty or
damaged.
• The disc is inserted
upside down.
• The disc is not play-
able with the player.• Clean the disc.
• Insert the disc cor-
rectly.
• Confirm the disc is
playable with the
player.
“Disc Error”There is a malfunction
within the system.Eject the disc.
“No music files found.”No playable data is
included on the disc.Eject the disc.

PRIUS v_OM_OM47B12U_(U)
2975-5. Playing an audio CD and MP3/WMA/AAC discs
5
Audio system
NOTICE
■Discs and adapters that cannot be used
Do not use the following types of CDs.
Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs.
Doing so may damage the CD player and/or the CD insert/eject function.
●Discs that have a diameter that is not 4.7 in. (12 cm).
●Low-quality or deformed discs.
●Discs with a transparent or translucent recording area.
●Discs that have tape, stickers or CD-R labels attached to them, or that
have had the label peeled off.
■Player precautions
Failure to follow the precautions below may result in damage to the discs or
the player itself.
●Do not insert anything other than discs into the disc slot.
●Do not apply oil to the player.
●Store discs away from direct sunlight.
●Never try to disassemble any part of the player.
