CAMSHAFT
• Before starting engine, check oil/fluid levels, including engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-11, "
Fluids and Lubricants".
• Use procedure below to check for fuel leaks.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leaks
at connection points.
• Start engine. With engine speed increased, che ck again for fuel leaks at connection points.
• Run engine to check for unusual noise and vibration. NOTE:
If hydraulic pressure inside timing chain tensioner drops after removal and installation, slack in the guide
may generate a pounding noise during and just after engine start. However, this is normal. Noise will stop
after hydraulic pressure rises.
• Warm up engine thoroughly to make sure there is no leak s of fuel, exhaust gas, or any oils/fluids including
engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec- ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc.
InspectionINFOID:0000000012431722
INSPECTION AFTER REMOVAL
Oil Filter
• Check that there is no foreign material on the oil filter (1) and check it for clogging.
• Check the oil filter for damage.
• If there is some damage, replace the oil filter, the plug, and the washer as a set.
CAUTION:
Do not reuse the washer.
Camshaft Runout
1. Put V-block on a precise flat table, and support No. 2 and 5 jour- nals of camshaft.
CAUTION:
Do not support No. 1 journal (on the side of camshaft
sprocket) because it has a differe nt diameter from the other
four locations.
2. Set a suitable tool vertically to No. 3 journal.
3. Turn camshaft to one direction, and measure the camshaft runout using suitable tool. (Total indicator reading)
Item Before starting engine Engine runningAfter engine stopped
Engine coolant LevelLeaks Level
Engine oil LevelLeaks Level
Transmission/
transaxle fluid CVT Models
LeaksLevel/Leaks Leaks
M/T Models Level/Leaks LeaksLevel/Leaks
Other oils and fluids* LevelLeaks Level
Fuel LeaksLeaksLeaks
Exhaust gas —Leaks —
PBIC3693E
PBIC2499E
Revision: August 2015 2016 Versa Note

cardiagn.com

EM-70
< REMOVAL AND INSTALLATION >[HR16DE]
CAMSHAFT
1. Install camshaft in cylinder head. Refer to
EM-60, "Removal and Installation" for tightening procedure.
2. Install a suitable tool (A) in thrust direction on front end of cam- shaft. Measure the camshaft end play using suitable tool when
camshaft is moved forward/backward (in direction of axis).
• Measure the following parts if out of the standard.
- Dimension “A” for cylinder head No. 1 journal bearing
- Dimension “B” for camshaft thrust
• Refer to the standards above, and then replace camshaft and/
or cylinder head.
Camshaft Sprocket Runout
1. Put V-block on precise flat table, and support No. 2 and 5 journals of camshaft. CAUTION:
Do not support No. 1 journal (on the side of cam shaft sprocket) because it has a different diameter
from the other four locations.
2. Measure the camshaft sprocket runout using suitable tool (A). (Total indicator reading)
• If it exceeds the limit, replace camshaft sprocket.
Valve Lifter
Check if surface of valve lifter has any wear or cracks.
• If anything above is found, replace valve lifter. Refer to EM-117,
"Camshaft".
Valve Lifter Clearance
VALVE LIFTER OUTER DIAMETERStandard and Limit : Refer to
EM-117, "
Camshaft".
PBIC3694E
Standard : 4.000 - 4.030 mm (0.1574 - 0.1586 in)
Standard : 3.877 - 3.925 mm (0.1526 - 0.1545 in)
KBIA3345J
Limit : 0.15 mm (0.0059 in)
JPBIA4193ZZ
KBIA0182E
Revision: August 2015 2016 Versa Note

cardiagn.com

CYLINDER BLOCKEM-107
< UNIT DISASSEMBLY AND ASSEMBLY > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
• Measure the dimensions at four different points as shown on each
main journal and pin journal using suitable tool.
• Out-of-round is indicated by the difference in dimensions between
(a) and (b) at (c) and (d).
• Taper is indicated by the diff erence in dimension between (c) and
(d) at (a) and (b).
• If the measured value exceeds the limit, correct or replace crankshaft.
• If corrected, measure the bearing oil clearance of the corrected main journal and/or pin journal. Then select main bearing and/or connecting rod bearing. Refer to EM-125, "
Connecting Rod Bearing" and/or EM-124,
"Main Bearing".
CRANKSHAFT RUNOUT
• Place a V-block on a precise flat table to support the journals on both ends of the crankshaft.
• Place a suitable tool (A) straight up on the No. 3 journal.
• While rotating crankshaft, read the movement of the pointer on the
suitable tool. (Total indicator reading)
• If it exceeds the limit, replace crankshaft.
CONNECTING ROD BEARING OIL CLEARANCE
Method by Calculation
• Install connecting rod bearings (2) to connecting rod (3) and con- necting rod cap (1), and tighten connecting rod cap bolts to the
specified torque. Refer to EM-94, "
Disassembly and Assembly".
• Measure the inner diameter of connecting rod bearing using suit- able tool.
(Bearing oil clearance) = (Connecting rod bearing inner diameter)
– (Crankshaft pin journal diameter)
• If clearance exceeds the limit, select proper connecting rod bearing according to connecting rod big end diameter and crankshaft pin journal diameter to obtain specified bearing oil clearance. Refer to EM-125,
"Connecting Rod Bearing".
Method of Using Plastigage
• Remove engine oil and dust on crankshaft pin and the surfaces of each bearing completely.
• Cut a plastigage slightly shorter than the bearing width, and place it in crankshaft axial direction, avoiding oil
holes.
• Install connecting rod bearings to connecting rod and c ap, and tighten connecting rod cap bolts to the speci-
fied torque. Refer to EM-94, "
Disassembly and Assembly".
CAUTION:
Do not rotate crankshaft. Limit:
Out-of-round [Difference between (a) and (b)]
Taper [Difference between (c) and (d)] : Refer to EM-121, "
Cylinder Block".JPBIA0229ZZ
Standard and Limit : Refer to EM-121, "Cylinder
Block".
PBIC3458J
(A) : Example
(B) : Inner diameter measuring direction
Standard and Limit : Refer to EM-125, "Connecting Rod Bearing".
PBIC3275J
Revision: August 2015 2016 Versa Note

cardiagn.com
