PCS-6
< SYSTEM DESCRIPTION >[IPDM E/R]
SYSTEM
RELAY CONTROL SYSTEM : Fail-safe
INFOID:0000000012433269
CAN COMMUNICATION CONTROL
When CAN communication with ECM and BCM is impossible, IPDM E/R performs fail-safe control. After CAN
communication recovers normally, it also returns to normal control.
If No CAN Communication Is Available With ECM
If No CAN Communication Is Available With BCM
Control relay Input/outputTransmit unit Control part Reference page
• Headlamp low relay
• Headlamp high relay • Low beam request signal
• High beam request signal
BCM (CAN)
• Headlamp LO
• Headlamp HI EXL-8
Tail lamp relay
Position light request signal BCM (CAN) •Parking lamp
• Side marker lamp
• License plate lamp
• Tail lamp
EXL-11
Illuminations
INL-9
• Front wiper relay
• Front wiper high relayFront wiper request signal BCM (CAN)
Front wiper motorWW-8Front wiper stop position sig-
nal Front wiper motor
Starter control relay Starter control relay signal BCM (CAN)
Starter motorSTR-8
(without Intelli-
gent Key)
STR-9
(with Intelligent
Key)
Transmission range switch
signal (CVT models)
Transmission range
switch
Clutch interlock switch signal
(M/T models) Clutch interlock switch
• Cooling fan low relay
• Cooling fan high relay Cooling fan speed request sig-
nal
ECM (CAN)
Cooling fan EC-38
A/C relayA/C compressor request sig-
nal
ECM (CAN)A/C compressor
(Magnet clutch)
HAC-11
Ignition relay-1Ignition switch ON signal BCM (CAN)
Each control unit,
sensor, actuator and
relay (Ignition power
supply) EC-35Vehicle speed signal (Meter)
Combination meter
(CAN)
Push-button ignition switch
signal Push-button ignition
switch
Control part
Fail-safe operation
Cooling fan • The cooling fan relay turn ON when the ignition switch is turned ON (Cooling fan HI operation)
• The cooling fan relay turn OFF when the ignition switch is turned OFF
A/C compressor A/C relay OFF
Generator Outputs the power generation command signal (PWM signal) 0%
Control part Fail-safe operation
Headlamp • Turns ON the headlamp low relay when the ignition switch is turned ON
• Turns OFF the headlamp low relay when the ignition switch is turned OFF
• Headlamp high relay OFF
•Parking lamp
• Side marker lamp
• License plate lamp
• Illumination
• Tail lamp • Turns ON the tail lamp relay when the ignition switch is turned ON
• Turns OFF the tail lamp relay when the ignition switch is turned OFF
Revision: August 2015
2016 Versa Note

cardiagn.com

PCS
DIAGNOSIS SYSTEM (IPDM E/R)PCS-11
< SYSTEM DESCRIPTION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
ECU IDENTIFICATION
The IPDM E/R part number is displayed.
SELF DIAGNOSTIC RESULT
Refer to
PCS-20, "DTCIndex".
DATA MONITOR
ACTIVE TEST
Data Monitor The IPDM E/R input/output data is displayed in real time.
Active Test The IPDM E/R activates outputs to test components.
CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed.
Direct Diagnostic Mode
Description
Monitor Item [Unit]Main
Signals Description
MOTOR FAN REQ [1/2/3/4] ×Indicates cooling fan speed signal received from ECM on CAN communication
line
AC COMP REQ [On/Off] ×Indicates A/C compressor request signal received from ECM on CAN commu-
nication line
TAIL&CLR REQ [On/Off] ×Indicates position light request signal
received from BCM on CAN communica-
tion line
HL LO REQ [On/Off] ×Indicates low beam request signal received from BCM on CAN communication
line
HL HI REQ [On/Off] ×Indicates high beam request signal received from BCM on CAN communication
line
FR FOG REQ [On/Off] ×Indicates front fog light request signal received from BCM on CAN communica-
tion line
FR WIP REQ [Stop/1LOW/Low/Hi] ×Indicates front wiper request signal received from BCM on CAN communication
line
WIP AUTO STOP [STOP P/ACT P] ×Indicates condition of front wiper auto stop signal
WIP PROT [Off/BLOCK] ×Indicates condition of front wiper fail-safe operation
IGN RLY1 -REQ [On/Off] Indicates ignition switch ON signal received from BCM on CAN communication
line
IGN RLY [On/Off] ×Indicates condition of ignition relay
PUSH SW [On/Off] Indicates condition of push-button ignition switch
INTER/NP SW [On/Off] Indicates condition of CVT shift position
ST RLY CONT [On/Off] Indicates starter relay status signal received from BCM on CAN communication
line
IHBT RLY -REQ [On/Off] Indicates starter control relay signal received from BCM on CAN communication
line
ST/INHI RLY [Off/ ST /INHI] Indicates condition of starter relay and starter control relay
DETENT SW [On/Off] Indicates condition of CVT shift selector (park position switch)
DTRL REQ [Off] Indicates daytime running light request signal received from BCM on CAN com-
munication line
THFT HRN REQ [On/Off] Indicates theft warning horn request signal received from BCM on CAN commu-
nication line
HORN CHIRP [On/Off] Indicates horn reminder signal received from BCM on CAN communication line
Test item Description
HORN This test is able to check horn operation [On].
FRONT WIPER This test is able to check wiper motor operation [Hi/Lo/Off].
Revision: August 2015 2016 Versa Note

cardiagn.com

PCS
SYSTEMPCS-35
< SYSTEM DESCRIPTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
TION
The power supply position changing operation can be performed with the following operations.
NOTE:
• When an Intelligent Key is within the detection area of inside key antenna and when Intelligent Key backside
is contacted to push-button ignition switch, it is equivalent to the operations below.
• When starting the engine, the BCM monitors under the engine start conditions:
- Brake pedal operating condition
- Selector lever position
- Vehicle speed
Vehicle speed: less than 4 km/h (2.5 MPH)
Vehicle speed: 4 km/h (2.5 MPH) or more
Emergency stop operation
• Press and hold the push-button ignition switch for 2 seconds or more.
• Press the push-button ignition switch 3 times or more within 1.5 seconds.
Fail-safeINFOID:0000000012567363
BCM performs fail-safe control when the following DTCs are detected.
Power supply position Engine start/stop condition
Push-button
ignition switch
operation frequency
With CVT
With M/T
Selector lever position Brake pedal condition Clutch pedal condition
OFF → ACC —Released Released 1
OFF → ACC → ON —Released Released 2
OFF → ACC → ON →
OFF —
Released Released 3
OFF → START
ACC → START
ON → START P (Park) or N (Neutral) Depressed
Depressed1
Engine is running → OFF ——— 1
Power supply position Engine start/stop condition
Push-button
ignition switch
operation frequency
With CVT
With M/T
Selector lever position Brake pedal condition Clutch pedal condition
Engine is running →
ACC ———
Emergency stop
operation
Engine stall return opera-
tion while driving N (Neutral)
ReleasedDepressed 1
CONSULT Display Fail-safe Cancellation
B2192: ID DISCORD BCM-ECM Inhibit engine cranking Erase DTC
B2193: CHAIN OF BCM-ECM Inhibit engine cranking Erase DTC
B2195: ANTI SCANNING Inhibit engine cranking Ignition switch ON → OFF
B2196: DONGLE NG Inhibit engine cranking Erase DTC
B2198: NATS ANTENNA AMP Inhibit engine cranking Erase DTC
B2557: VEHICLE SPEED —When the following CAN signal status (vehicle speed signal) becomes
consistent
• Vehicle spee
d signal (ABS)
• Vehicle speed signal (Meter)
B2601: SHIFT P SIGNAL —500 ms after the following signal reception status becomes consistent
• Park position switch signal
• P range signal (CAN)
Revision: August 2015
2016 Versa Note

cardiagn.com

PCS-38
< SYSTEM DESCRIPTION >[POWER DISTRIBUTION SYSTEM]
DIAGNOSIS SYSTEM (BCM)
INTELLIGENT KEY
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)INFOID:0000000012542492
SELF DIAGNOSTIC RESULT
Refer to
BCS-50, "DTCIndex".
DATA MONITOR
ACTIVE TEST
Monitor Item [Unit] Main Description
REQ SW -DR [On/Off] ×Indicates condition of door request switch LH.
REQ SW -AS [On/Off] ×Indicates condition of door request switch RH.
REQ SW -BD/TR [On/Off] ×Indicates condition of back door request switch.
PUSH SW [On/Off] Indicates condition of push-button ignition switch.
CLUCH SW [On/Off] ×Indicates condition of clutch interlock switch.
BRAKE SW 1 [On/Off] ×Indicates condition of brake switch.
BRAKE SW 2 [On/Off] Indicates condition of brake switch.
DETE/CANCL SW [On/Off] ×Indicates condition of P (park) position.
SFT PN/N SW [On/Off] ×Indicates condition of P (park) or N (neutral) position.
UNLK SEN -DR [On/Off] ×Indicates condition of door unlock sensor.
PUSH SW -IPDM [On/Off] Indicates condition of push-button ignition switch received from IPDM E/R on
CAN communication line.
IGN RLY1 -F/B [On/Off] Indicates condition of ignition relay 1 received from IPDM E/R on CAN commu-
nication line.
DETE SW -IPDM [On/Off] Indicates condition of detent switch received from TCM on CAN communication
line.
SFT PN -IPDM [On/Off] Indicates condition of P (park) or N (neutral) position from TCM on CAN com-
munication line.
SFT P -MET [On/Off] Indicates condition of P (park) position from TCM on CAN communication line.
SFT N -MET [On/Off] Indicates condition of N (neutral) position from IPDM E/R on CAN communica-
tion line.
ENGINE STATE [Stop/Start/Crank/Run] ×Indicates condition of engine state from ECM on CAN communication line.
VEH SPEED 1 [mph/km/h] ×Indicates condition of ve
hicle speed signal receiv ed from ABS on CAN commu-
nication line.
VEH SPEED 2 [mph/km/h] ×Indicates condition of vehicle speed signal received from combination meter on
CAN communication line.
DOOR STAT -DR [LOCK/READY/UNLK] ×Indicates condition of driver side door status.
DOOR STAT -AS [LOCK/READY/UNLK] ×Indicates condition of passenger side door status.
ID OK FLAG [Set/Reset] Indicates condition of Intelligent Key ID.
PRMT ENG STRT [Set/Reset] Indicates condition of engine start possibility.
RKE OPE COUN1 [0-19] ×When remote keyless entry receiver receives the signal transmitted while oper-
ating on Intelligent Key, the numerical value start changing.
RKE OPE COUN2 [0-19] ×When remote keyless entry receiver receives the signal transmitted while oper-
ating on Intelligent Key, the numerical value start changing.
RKE-LOCK [On/Off] Indicates condition of lock signal from Intelligent Key.
RKE-UNLOCK [On/Off] Indicates condition of unlock signal from Intelligent Key.
RKE-PANIC [On/Off] Indicates condition of panic signal from Intelligent Key.
RKE-MODE CHG [On/Off] Indicates condition of mode change signal from Intelligent Key.
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-1
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
C
DE
F
G H
I
J
L
M
SECTION SEC
A
B
SEC
N
O P
CONTENTS
SECURITY CONTROL SYSTEM
WITH INTELLIGENT KEY SYSTEM
PRECAUTION ....... ........................................
5
PRECAUTIONS .............................................. .....5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
Precaution for Work ..................................................5
PREPARATION ............................................6
PREPARATION .............................................. .....6
Special Service Tool ........................................... ......6
SYSTEM DESCRIPTION ..............................7
COMPONENT PARTS ................................... .....7
Component Parts Location .................................. ......7
CVT Shift Selector (Park Position Switch) ................9
BCM ..........................................................................9
ECM ..........................................................................9
IPDM E/R ................................................................10
NATS Antenna Amp. ...............................................10
Combination Meter ..................................................10
Door Switch .............................................................10
Outside Key Antenna ..............................................10
Inside Key Antenna .................................................10
Remote Keyless Entry Receiver .............................10
Intelligent Key ..........................................................10
Push-button Ignition Switch .....................................10
Security Indicator Lamp ...................................... ....10
Starter Relay ...........................................................10
Stop Lamp Switch ...................................................11
Transmission Range Switch ....................................11
SYSTEM .............................................................12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION ............................................................. ....
12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION : System Description ............................
12
NISSAN ANTI-THEFT SYSTEM ................................14
NISSAN ANTI-THEFT SYST EM : System De-
scription ............................................................... ....
15
DIAGNOSIS SYSTEM (BCM) ...........................18
COMMON ITEM ..................................................... ....18
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) .....................................................
18
INTELLIGENT KEY ................................................ ....19
INTELLIGENT KEY : CONSULT Function (BCM -
INTELLIGENT KEY) ................................................
19
THEFT ALM ........................................................... ....21
THEFT ALM : CONSULT Function (BCM -
THEFT) ....................................................................
21
IMMU ...................................................................... ....21
IMMU : CONSULT Function (BCM - IMMU) ............21
ECU DIAGNOSIS INFORMATION ..............23
ECM, IPDM E/R, BCM .......................................23
List of ECU Reference ......................................... ....23
WIRING DIAGRAM ......................................24
INTELLIGENT KEY SYSTEM/ENGINE
START FUNCTION ...........................................
24
Wiring Diagram .................................................... ....24
NVIS - WITH INTELLIGENT KEY SYSTEM .....37
Wiring Diagram ........................................................37
BASIC INSPECTION ...................................46
DIAGNOSIS AND REPAIR WORK FLOW .......46
Work Flow ............................................................ ....46
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT ................................................
49
ECM ........................................................................ ....49
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-2
ECM : Description ...................................................49
ECM : Work Procedure ...........................................49
BCM ........................................................................ ...49
BCM : Description ...................................................49
BCM : Work Procedure ...........................................49
DTC/CIRCUIT DIAGNOSIS ...................... ...51
P1610 LOCK MODE ....................................... ...51
Description ........................................................... ...51
DTC Logic ...............................................................51
Diagnosis Procedure ..............................................51
P1611 ID DISCORD, IMMU-ECM ......................52
DTC Logic ............................................................ ...52
Diagnosis Procedure ..............................................52
P1612 CHAIN OF ECM-IMMU ...........................53
DTC Logic ............................................................ ...53
Diagnosis Procedure ..............................................53
B2192 ID DISCORD, IMMU-ECM ......................54
DTC Logic ............................................................ ...54
Diagnosis Procedure ..............................................54
B2193 CHAIN OF ECM-IMMU ...........................55
DTC Logic ............................................................ ...55
Diagnosis Procedure ..............................................55
B2195 ANTI-SCANNING ...................................56
DTC Logic ............................................................ ...56
Diagnosis Procedure ..............................................56
B2196 DONGLE UNIT .......................................57
Description ........................................................... ...57
DTC Logic ...............................................................57
Diagnosis Procedure ..............................................57
B2198 NATS ANTENNA AMP. .........................59
DTC Logic ............................................................ ...59
Diagnosis Procedure ..............................................59
B2555 STOP LAMP ...........................................62
DTC Logic ............................................................ ...62
Diagnosis Procedure ..............................................62
Component Inspection ............................................63
B2556 PUSH-BUTTON IGNITION SWITCH .....65
DTC Logic ...............................................................65
Diagnosis Procedure ..............................................65
Component Inspection ............................................66
B2557 VEHICLE SPEED ...................................67
DTC Logic ............................................................ ...67
Diagnosis Procedure ..............................................67
B2601 SHIFT POSITION ...................................68
DTC Logic ............................................................ ...68
Diagnosis Procedure ..............................................68
B2602 SHIFT POSITION ...................................70
DTC Logic ............................................................ ...70
Diagnosis Procedure ...............................................70
Component Inspection ............................................72
B2603 SHIFT POSITION ...................................73
DTC Logic ...............................................................73
Diagnosis Procedure ...............................................73
Component Inspection (Transmission Range
Switch) ....................................................................
76
Component Inspection [CVT Shift Selector (Park
Position Switch)] .....................................................
76
B2604 SHIFT POSITION ...................................77
DTC Logic ...............................................................77
Diagnosis Procedure ...............................................77
Component Inspection ............................................79
B2605 SHIFT POSITION ...................................80
DTC Logic ...............................................................80
Diagnosis Procedure ...............................................80
B2608 STARTER RELAY .................................82
DTC Logic ...............................................................82
Diagnosis Procedure ...............................................82
Component Inspection ............................................83
B260F ENGINE STATUS ..................................84
Description ..............................................................84
DTC Logic ...............................................................84
Diagnosis Procedure ...............................................84
B261F ASCD CLUTCH SWITCH ......................85
DTC Logic ...............................................................85
Diagnosis Procedure ...............................................85
Component Inspection ............................................87
B2620 PARK/NEUTRAL POSITION SWITCH ...88
DTC Logic ............................................................ ...88
Diagnosis Procedure ...............................................88
Component Inspection ............................................90
B26E8 CLUTCH INTERLOCK SWITCH ...........91
DTC Logic ............................................................ ...91
Diagnosis Procedure ...............................................91
Component Inspection (Clutch Interlock Switch) ....93
B26F3 STARTER CONTROL RELAY ..............94
DTC Logic ............................................................ ...94
Diagnosis Procedure ...............................................94
B26F4 STARTER CONTROL RELAY ..............95
DTC Logic ............................................................ ...95
Diagnosis Procedure ...............................................95
B26F7 BCM .......................................................96
DTC Logic ............................................................ ...96
Diagnosis Procedure ...............................................96
B26FB CLUTCH SWITCH .................................97
DTC Logic ............................................................ ...97
Diagnosis Procedure ...............................................97
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-3
C
DE
F
G H
I
J
L
M A
B
SEC
N
O P
B26FC KEY REGISTRATION ........................ ....98
DTC Logic ........................................................... ....98
Diagnosis Procedure ...............................................98
B210B STARTER CONTROL RELAY ...............99
DTC Logic ........................................................... ....99
Diagnosis Procedure ...............................................99
B210C STARTER CONTROL RELAY .............100
DTC Logic ........................................................... ..100
Diagnosis Procedure .............................................100
B210D STARTER RELAY ................................102
DTC Logic .............................................................102
Diagnosis Procedure .............................................102
B210E STARTER RELAY ................................104
DTC Logic .............................................................104
Diagnosis Procedure .............................................104
B210F SHIFT POSITION/CLUTCH INTER-
LOCK SWITCH .................................................
106
DTC Logic ........................................................... ..106
Diagnosis Procedure .............................................106
B2110 SHIFT POSITION/CLUTCH INTER-
LOCK SWITCH .................................................
108
DTC Logic ........................................................... ..108
Diagnosis Procedure .............................................108
VEHICLE SECURITY INDICATOR ..................110
Description .......................................................... ..110
Component Function Check ................................110
Diagnosis Procedure .............................................110
SYMPTOM DIAGNOSIS ............................112
ENGINE DOES NOT START WHEN INTELLI-
GENT KEY IS INSIDE OF VEHICLE .............. ..
112
Description .......................................................... ..112
Diagnosis Procedure .............................................112
SECURITY INDICATOR LAMP DOES NOT
TURN ON OR BLINK .......................................
113
Description .......................................................... ..113
Diagnosis Procedure .............................................113
REMOVAL AND INSTALLATION .............114
NATS ANTENNA AMP. .................................. ..114
Removal and Installation .......................................114
PUSH-BUTTON IGNITION SWITCH .............. ..115
Removal and Installation .......................................115
REMOTE KEYLESS ENTRY RECEIVER ...... ..116
Removal and Installation .......................................116
WITHOUT INTELLIGE NT KEY SYSTEM
PRECAUTION ....... .....................................
117
PRECAUTIONS .............................................. ..117
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ..
117
Precaution for Work ...............................................117
PREPARATION .........................................118
PREPARATION ...............................................118
Special Service Tool ............................................ ..118
SYSTEM DESCRIPTION ...........................119
COMPONENT PARTS ....................................119
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS ..119
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Component Parts Location .......................
119
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : CVT Shift Selector (Park Position Switch) ..
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : BCM ..........................................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : ECM ..........................................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : IPDM E/R ..................................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Combination Meter ....................................
121
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Door Switch ...............................................
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Remote Keyless Entry Receiver ...............
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Security Indicator Lamp .......................... ..
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Starter Relay .............................................
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Stop Lamp Switch .....................................
122
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : Transmission Range Switch .....................
122
SYSTEM ..........................................................123
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS ..123
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : System Diagram .......................................
123
NISSAN VEHICLE IMMOBILIZER SYSTEM-
NATS : System Description ...................................
123
DIAGNOSIS SYSTEM (BCM) .........................125
COMMON ITEM ..................................................... ..125
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) ...................................................
125
IMMU ...................................................................... ..126
IMMU : CONSULT Function (BCM - IMMU) ..........126
DIAGNOSIS SYSTEM (IPDM E/R) .................127
Diagnosis Description ............................................127
CONSULT Function (IPDM E/R) ...........................128
ECU DIAGNOSIS INFORMATION ............131
Revision: August 2015 2016 Versa Note

cardiagn.com

SEC-8
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
3. ABS actuator and electric unit (control unit) ABS actuator and electric unit (control unit)
transmits the vehicle speed signal to BCM via
CAN communication.
BCM also receives the vehicle speed signal
from the combination meter via CAN commu-
nication. BCM compares both signals to de-
tect the vehicle speed.
Refer to
BRC-8, "
ABS Actuator and Electric
Unit (Control Unit)" for detailed installation lo-
cation.
4. Intelligent Key warning buzzer Intelligent Key warning buzzer warns the us-
er, who is outside the vehicle, of operation
confirmation according to Intelligent Key op-
eration and door request switch operation, or
of an inappropriate operation.
5. Transmission range switch Transmission range switch detects the CVT
shift selector lever position.
6. IPDM E/R Starter control relay is integrated in IPDM E/R
and used for the engine starting function.
Starter relay is controlled by BCM, and starter
control relay is controlled by IPDM E/R while
communicating with BCM. IPDM E/R sends
the starter control rela
y and starter relay sta-
tus signal to BCM.
7. BCM BCM controls INTELLIGENT KEY SYSTEM
(ENGINE START FUNCTION), NISSAN VE-
HICLE IMMOBILIZER SYSTEM-NATS [NVIS
(NATS)] and VEHICLE SECURITY SYSTEM.
BCM performs the ID verification between
BCM and Intelligent Key when the Intelligent
Key is carried into the detection area of inside
key antenna, and push-button ignition switch
is pressed. If the ID verification result is OK,
ignition switch operation is available.
Then, when the ignition switch is turned ON,
BCM performs ID verification between BCM
and ECM. If the ID verification result is OK,
ECM can start engine.
Refer to
BCS-6, "
BODY CONTROL SYSTEM
: Component Parts Location" for detailed in-
stallation location.
8. Clutch interlock switch Clutch interlock switch detects that clutch
pedal is depressed, and then transmits ON/
OFF signal to the BCM.
9. Stop lamp switch Stop lamp switch detects that brake pedal is
depressed, and then transmits ON/OFF sig-
nal to the BCM.
10. Main power window and door lock/unlock switch Door lock and unlock switch is integrated into
the main power window and door lock/unlock
switch.
Door lock and unlock switch transmits door
lock/unlock operation signal to BCM.
Refer to
PWC-7, "
Main Power Window And
Door Lock/Unlock Switch".
11. CVT shift selector (park position switch) Park position switch is integrated into the
CVT shift selector and detects that the selec-
tor lever is in the P (park) position, then trans-
mits ON/OFF signal to the BCM and IPDM E/
R.
No.
Component Function
Revision: August 2015 2016 Versa Note

cardiagn.com
