4. Release the sail panel retainers from the body sidechannel at the rear corners of the vehicle.
NOTE: When releasing the sail panel retainers, it is
helpful to pull down on the rear roof bow. 5. Fold the sail panels so that they rest on top of the soft
top.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263

6. Fold header rearward, pulling the fabric to the rear.7. Release Sunrider latch (both sides).
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

8. Open the swing gate and lower the top.NOTE:Ensure the fabric does not overhang the sides of
the vehicle.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265

Quick Steps For Raising The Soft Top
1. Open the swing gate and raise the top, engaging theSunrider latches (another person may be needed to
help with this operation).
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Install rear corner panels.3. Rotate the header forward.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267

4. Engage the header latches.5. Install the back window.
268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Install the side windows.7. To install the side windows, affix the window tempo-
rarily by attaching to the Velcro in the rear corner. Start
the zipper but close only about 1 in (2.5 cm).
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269

8. Insert the front retainer of the window into the doorchannel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do
so can result in wind and water leaks or damage to the
window.
1 — Incorrect Insertion
2 — Correct Insertion
