Front Panel(s) Removal
NOTE: Left panel must be removed before removing
right panel.
1. Fold down the sun visor, and move it to the side.
2. Turn the rear fasteners (knobs) (located on the over-head speaker bar assembly) counterclockwise until
they can be removed.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207

3. Turn the center L-shaped locks (two) from the centerof the roof panel. 4. Turn the rear L-shaped lock (located above the shoul-
der belt anchorage).
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

5. Unlatch the header panel latch located at the top of thewindshield.
6. Remove the left-hand panel.
To remove the right panel, follow the steps above
except for Step 3.Freedom Top Storage Bag
Vehicles equipped with a Freedom Top Modular Hard
Top, come with a Freedom Top storage bag that allows
you to store your Freedom Top panels. The storage bag
contains two compartments and fits behind the rear seat.
Lay the Freedom bag down so the loops and hooks are
facing downward. Unzip the bag and fold back the outer
flap. Release the Velcro on the black panel divider and
fold it back.
NOTE: Ensure the front Freedom Top panel latch is
closed prior to inserting the panel into the Freedom bag.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209

Insert the right side Freedom panel into the bag with the
latches facing downward.Unfold the black panel divider (ensure the divider is
laying flat). Secure the Velcro, located at the center of the
divider.
210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Insert the left-side Freedom panel into the bag with the
latches facing upward.
NOTE:Ensure the front Freedom panel latch is closed
prior to inserting the panel into the bag. Unfold the outer flap and zip the Freedom bag closed.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211

Install the seat attachment strap (at the top of the bag)
through the loops.Lift the Freedom bag into the vehicle with the hooks and
straps facing the back of the rear seat. Attach the clips at
the bottom of the bag to the child restraint anchorages,
located at the base of the rear seat.
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Wrap the upper strap around the rear head restraints and
loop the strap through the buckle. Pull on the strap to
tighten the Freedom bag securely against the rear seat.Front Panel(s) Installation
NOTE:Set the panels on the windshield frame so that
there is no overhang. Also, make sure that the panels are
sitting flush with the body.
1. Install the right panel first, then the left panel.
2. Reinstall the panel(s) using the same steps for removal in reverse order.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213

Front Panel(s) Installation With Rear Hard Top
Removed
1. Turn the left and right panels over and move thespacer block (located on the rear of the panel) upward
90 degrees. NOTE:
The front panel(s) must be positioned properly
to ensure sealing. Set the panels on the windshield frame
so that there is no overhang. Also, make sure that the
panels are sitting flush with the body.
2. Install the right panel first, then the left panel.
3. Reinstall the panel(s) using the same steps for removal in reverse order.
Rear Hard Top Removal
1. Remove both front panels. Refer to “Front Panel(s)Removal” in this section.
2. Open both doors.
3. Remove the two Torx head screws that secure the hard top at the B-pillar (near the top of the door) using a #40
Torx head driver (Four–Door Only).
