2016 JEEP WRANGLER Owners Manual

19. Close the header latches and return the sun visors totheir secured position.SUNRIDER (TWO-DOOR MODELS) — IF
EQUIPPED
CAUTION!
Operating the top, opening a door or lowering a
window while the top is wet may allow water to drip
into the vehicle’s interior.
NOTE: If you are going to be driving faster than 40 mph
(64 km/h) with the Sunrider feature open, it is recom-
mended that you remove the rear window of the vehicle.3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255

Opening The Sunrider
1. Unclip and move the sun visors to the side.
2. Release the header latches from the loops on thewindshield frame.
3. Make sure to slide the plastic sleeves forward to unlock the Sunrider links. 4. Grasp the header and lift the top back. Make sure the
material is folded back as shown.
NOTE: The Sunrider latch on the door rail should not be
activated for Sunrider use. If activated, the soft top must
be reinstalled starting from the sail panels.
256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

5. Locate the straps to secure the side bows. Wrap thestraps around the bows as shown. Repeat on the other
side. 6. Reposition the sun visors.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257

Closing The Sunrider
1. Remove the straps from the side bows.
2. Unclip and move the sun visors to the side.
3. Grasp the front header and pull it to the front of thevehicle.
4. Hook the header latches to the loops on the wind- shield frame, close latches, and return the sun visors to
their original positions.
5. Slide the plastic sleeve rearward over the Sunrider link.
SOFT TOP — FOUR-DOOR MODELS
Please visit the Owners Manual on your DVD for
instructional videos.
CAUTION!
The soft top is not designed to carry any additional
loads such as roof racks, spare tires, building, hunting,
or camping supplies, and/or luggage, etc. Also, it was
not designed as a structural member of the vehicle, and
thus cannot properly carry any additional loads other
than environmental (rain, snow, etc.).
If the temperature is below 72°F (24°C) and/or the top
has been folded down for a period of time, the top will
appear to have shrunk when you raise it, making it
difficult to put up. This is caused by a natural contraction
of the vinyl coating on the fabric top.
Place the vehicle in a warm area. Pull steadily on the top
fabric. The vinyl will stretch back to its original size and
the top can then be snapped into place. If the tempera-
ture is 41°F (5°C) or below, do not attempt to put the top
down or roll the rear or side curtains.
258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
•Do not run a fabric top through an automatic car
wash. Window scratches and wax buildup may
result.
• Do not lower the top when the temperature is
below 41°F (5°C). Damage to the top may result.
• Do not lower the top when the windows are dirty.
Grit may scratch the window.
• Do not move your vehicle until the top has been
either fully attached to the windshield frame, or
fully lowered.
• Do not lower the top with the windows installed.
Window and top damage may occur.
• Refer to “Appearance Care for Fabric Top Models”
in “Maintaining Your Vehicle” for further informa-
tion. It contains important information on cleaning
and caring for your vehicle’s fabric top.
(Continued)
CAUTION! (Continued)
•Do not use any tools (screwdrivers, etc.) to pry or
force any of the clamps, clips, or retainers securing
the soft top. Do not force or pry the soft top
framework when opening or closing. Damage to
the top may result.
WARNING!
• Do not drive the vehicle with the rear window
curtain up unless the side curtains are also re-
moved. Dangerous exhaust gases could enter the
vehicle causing harm to the driver and passengers.
• The fabric upper doors and fabric top are designed
only for protection against the elements. Do not
(Continued)
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259

WARNING!(Continued)
rely on them to contain occupants within the ve-
hicle or to protect against injury during an acci-
dent. Remember, always wear seat belts.
• Make sure hands and fingers are clear of all pinch
points when installing and removing the soft tops.
The zippers and side bows may cause serious
injury if fingers or hands get caught in between.
CAUTION!
Failure to follow these cautions may cause interior
water damage, stains or mildew on the top material:
• It is recommended that the top be free of water
prior to opening it. Operating the top, opening a
door or lowering a window while the top is wet
may allow water to drip into the vehicle’s interior.
(Continued)
CAUTION! (Continued)
•Careless handling and storage of the soft top may
damage the seals, causing water to leak into the
vehicle’s interior.
• The soft top must be positioned properly to ensure
sealing. Improper installation can cause water to
leak into the vehicle’s interior.
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:Do not remove any of the three attachment knobs
unless you are planning on installing the hard top.Quick Steps For Lowering The Soft Top
1. Remove the side windows.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261

2. Remove the back window.
NOTE:Start zipper from the right side to remove back
window. 3. Release header latches from the windshield frame.
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
